Характеристики

Torque Motor Controller TMA-4B 25A





Model	Panel size	Hole Size	Depth
6A-10A	160*115mm	135*105mm	130mm
15A-25A	230*105mm	195*95mm	190mm
25A-60A	300*130mm	275*100mm	210mm
80A	300*130mm	275*100mm	250mm
100A-300A	420*160mm	320*135mm	390mm



Overview
The controller is an ideal product for controlling the torque and speed of the three-phase torque motor instead of the three-phase self-coupling voltage regulator
It adopts electronic AC new technology, fully achieve AC voltage regulation, control motor output torque, in order to adapt to the requirements of time conditions, the controller five electric shock, all electronic, stable regulation, small size, light weight, high efficiency, easy installation and maintenance, long service life and other characteristics, is the current ideal energy-saving products.

Working conditions
1. Ambient temperature ranges from -25 ° C to +55 ° C
2. When in use, it is placed in the place without significant impact and vibration
3. Working voltage: three-phase AC 380V (±10%)
4. Frequency: 50 to 60 hz
5 air relative temperature ≤85% (20℃±5℃)

 Main technical performance
1. Voltage regulating range: 0-375V
2. Three-phase balance rate: ≤1%
3. Output current :2A-500A



Matters needing attention
1) Strict output short circuit
2) In use, the total current exceeds the standard current of the panel
3) The grounding wire must be in good contact
4) No water, oil, metal debris
5) When selecting the maximum thermal current value of the motor and the allowance for adaptation
