850 + 900 1800 2100 2300 2600MHz-40dBm (смнн) 6 Группа прямого соединения волоконно-оптический усилитель повторитель
- Категория: Repeaters >>>
- Поставщик: Shenzhen,ZD,Tech,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 1428.74 $* | 1499.74 $* |
| Aug-16-2025 | 1416.97 $* | 1487.21 $* |
| Jul-16-2025 | 1188.69 $* | 1247.36 $* |
| Jun-16-2025 | 1392.3 $* | 1462.91 $* |
| May-16-2025 | 1212.10 $* | 1273.36 $* |
| Apr-16-2025 | 1368.5 $* | 1436.77 $* |
| Mar-16-2025 | 1356.0 $* | 1424.48 $* |
| Feb-16-2025 | 1344.14 $* | 1411.84 $* |
| Jan-16-2025 | 1332.17 $* | 1399.38 $* |
Характеристики
Electrical Data | ||||||
Item | Uplink | Downlink | ||||
Frequency Range (MHz) | L850 Band | 824 ~ 842.5 | 869 ~ 887.5 | |||
L900 Band | 890.5 ~ 915 | 935.5 ~ 960 | ||||
L1800 Band | 1710 ~ 1785 | 1805 ~ 1880 | ||||
L2100 Band | 1920 ~ 1980 | 2110 ~ 2170 | ||||
L2300 Band | 2300 ~ 2400 | |||||
L2600 Band | 2496 ~ 2690 | |||||
Max. Total Output Power(dBm) | - 10±2(per band) | 40±2(per band) | ||||
Max. Gain (dB) Center Frequency at 25C @ Optical Loss=0dB | 55±3 | 55±3 | ||||
ALC control | 20 dB Overdrive Protection | |||||
Gain control range (dB) | 30 dB/ 1 dB step | |||||
Gain control Error (dB) | ≤ |±1.5| | |||||
Ripple In Band (P-P) (dB) At +25C | L850 Band | ≤ ±4.0 | ||||
L900 Band | ≤ ±4.0 | |||||
L1800 Band | ≤ ±4.0 | |||||
L2100 Band | ≤ ±4.0 | |||||
L2300 Band | ≤ ±4.0 | |||||
L2600 Band | ≤ ±3.0@EBW=18M | |||||
Noise Figure | ≤ 8 dB | --- | ||||
Spurious Emission | 9kHz~ 150kHz | ≤ -36dBm/1KHz | ≤ -36dBm/1KHz | |||
150kHz~30MHz | ≤ -36dBm/10KHz | ≤ -36dBm/10KHz | ||||
30MHz~ 1GHz | ≤ -36dBm/100KHz | ≤ - 15dBm/100KHz | ||||
1GHz~ 12.75GHz | ≤ -30dBm/1MHz | ≤ - 10dBm/1MHz | ||||
EVM (%) | ≤ 8 | ≤ 8 | ||||
VSWR(Power up, Min Gain, Pin=-30dBm) | ≤ 1.8 | ≤ 1.8 | ||||
Transmission delay (μS) | ≤ 5 | |||||
Max. non-destructive input power | ≤ - 10 dBm | |||||
Impedance | 50 Ω | |||||
Optical Specifications | Optical Connector | MU | FC/APC*4； | |||
RU | FC/APC*1； | |||||
Optical Wavelength (nm) | MU | TX：1550 / RX：1310； Single Mode； | ||||
RU | TX：1310 / RX：1550； Single Mode； | |||||
Optical Output Power (dBm) | MU | -2±3 | ||||
RU | 4.5±3 | |||||
Fiber optic path attenuation range(dB) | 0~7 | |||||
Power consumption rating | MU | ≤ 40W | ||||
RU | ≤ 350W | |||||
Power Adapter supply input /current | MU | -38.4 ~ -57.7V/DC~ 1.5A； or 176 ~ 264V/AC~0.5A ，50 ~ 60 Hz； | ||||
RU | 176 ~ 264V/AC~2.0A ，50 ~ 60 Hz； | |||||
Functions- Variable Sub-band | ||
Instantaneous Bandwidth of each band | 18.5 MHz @ L850 | |
24.5 MHz @ L900 | ||
75 MHz @ L1800 | ||
60 MHz @ L2100 | ||
70 MHz @ L2300 | ||
70 MHz @ L2600 | ||
Number of sub-band | 1 @ L850 | |
1 @ L900 | ||
1 @ L1800 | ||
1 @ L2100 | ||
1 @ L2300 | ||
1 @ L2600 | ||
Environmental Data | ||||
Operating temperature range | MU | -5°C to +45°C | ||
RU | -25°C to +55°C | |||
Storage temperature range | MU | -40°C to +85°C | ||
RU | -40°C to +85°C | |||
Relative humidity | MU | 5% - 80% | ||
RU | 5% - 95% | |||
Applications | MU | IP20 | ||
RU | IP65 | |||
Cooling | MU | Nature cooling | ||
RU | Nature cooling | |||
Monitoring and control | MU | RJ45 (Local) | ||
LTE wireless modem (Remote) | ||||
RU | RJ45 (Local) | |||
Mechanical Data | ||||
Dimensions | MU | 482*300*44mm | ||
RU | 489*409*186.5mm | |||
Weight | MU | ≤4Kg | ||
RU | ≤35Kg | |||
Connectors type | MU | N-Female | ||
RU | N-Female | |||
Mounting | MU | Rack Mounting | ||
RU | Wall Mounting | |||
Packing | MU | 1 Pce in box | ||
RU | 1 Pce in box | |||
