HD горячая Распродажа полностью автоматическая металлическая крыша панель рулон
- Категория: Building Material Machinery >>>
- Поставщик: Botou,Haide,Machinery,Manufacturing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 10115.54 $* | 10621.87 $* |
| Aug-18-2025 | 10030.47 $* | 10532.13 $* |
| Jul-18-2025 | 8415.92 $* | 8836.43 $* |
| Jun-18-2025 | 9860.90 $* | 10353.17 $* |
| May-18-2025 | 8585.66 $* | 9014.81 $* |
| Apr-18-2025 | 9690.52 $* | 10175.71 $* |
| Mar-18-2025 | 9605.28 $* | 10085.40 $* |
| Feb-18-2025 | 9520.11 $* | 9996.12 $* |
| Jan-18-2025 | 9435.6 $* | 9907.27 $* |
Характеристики
Application
16 year production factory, providing the best price
Working Flow
Uncoiling — Sheet guiding — Roll forming — Measure length — Pressure pattern — Cutting — Panels to product stand
Uncoiling — Sheet guiding — Roll forming — Measure length — Pressure pattern — Cutting — Panels to product stand
Machine part parameters | ||
Name | Galzed floor color coated tile making machine sheet machinery | |
Suitable Material | Colored or galvanized steel coil, HRB60 or equivalent | |
Thickness Range | 0.3-0.8 mm | |
Coil Width Range | 914, 1000, 1220 or 1250 mm. According to your actual drawing. | |
Electric Power | 380V, 50 Hz, 3 phase or according to your need. | |
Dimension | About 7.2*1.3*1.1m(L*W*H), as per the drawing | |
Cutting | Automatically stop and cutting when it comes to the set length. | |
Length of the Sheet | You can set the length according to your need. It is controlled by PLC length accuracy: ±1mm. | |
Details Images
IBR trapezoidal roof sheet machine
Corrugated roof sheet roll forming machine
Glazed tile roof sheet roll forming machine
Double layer roll forming machine
Detailed description
The company has vigorously introduced the German professional roller design software COPRA, which can design various rollers according to customer needs
Manual uncoiler
The coil inner diameter: φ450-550mm;
Max. outer coil diameter: φ1000mm-1250mm
The max capacity: 5T
Max. outer coil diameter: φ1000mm-1250mm
The max capacity: 5T
Machine shaft
Shaft hardness 58-60
Hardening depth 0.8mm
Surface roughness ra0.1m-0.35m
High quality shaft with a service life of over 15 years
Hardening depth 0.8mm
Surface roughness ra0.1m-0.35m
High quality shaft with a service life of over 15 years
Machine Cr12 roller
2 years of free maintenance
Lifetime maintenance
Solve your usage difficulties
More product choices
Click to inquire about more machine prices
Company Profile
Customer Photos
Product packaging
FAQ
1. Does your company can customized my needed profile?
Yes sir/Madam. Our machines are all customized according to customers' requests. Just provided me your needed profile drawing and we can give you our professional machine design solution.
2. If i don't have profile drawing, but i want to buy one machine, can you help me?
Yes sir/ Madam. If you don't have profile drawings, the solutions have:
2.1 : Provide me with your profiles' pictures ;
2.2 : Tell me your country and i will check if we sell similar / related profile machines to your there. I will recommend you related profile drawings.
2.3 : Tell me any information you have and it will be helpful for me to clear your needed profiles. and then quote you.
3. What your company advantages?
Yes sir/Madam. Our advantages have :
3.1: We are a 15 years big factory. We have abundant machine designing and making experience. We can give you the best machine solution.
3.2: We have completed production system. And more than 20 sets of CNC machines which can support lots of machine orders' making and guarantee the delivery.
3.3 : We have 20 years foreign trade exported experience. Our sellers abundant experience can guarantee you will have a pleasant purchase and use of the machine and after-sales experience. And cooperated with us , you can get more details about the machine, including those problems that you can't think of but we can think of, we can tell you to ensure that you can buy the most suitable machine for you.
3.4 : We are a golden integrity roll forming machine company.
About the after-sale services, no worries, we will responsible for you.
4. Will i receive a good machine ? Same Like I wanted to?
Yes sir/Madam. We will do the machine according to your profile drawing . About the profile drawing, we will confirm with you again before producing your machine. Then, after the machine finished, we will test the machine and guarantee the machine you received is a good machine. Because after you satisfied with the machine, and then you pay balance.
5. What is the machine minimum quantity?
One machine is okay.
6. What is your payment terms?
6.1 : We accept 30% T/T as deposit and 70% T/T as balance before shipping.
6.2 : We accept 100% L/C at sight
6.3: We accept Western Union payments.
6.4 : Other payment terms you want to pay, please let me know and i will check and reply you.
2. If i don't have profile drawing, but i want to buy one machine, can you help me?
Yes sir/ Madam. If you don't have profile drawings, the solutions have:
2.1 : Provide me with your profiles' pictures ;
2.2 : Tell me your country and i will check if we sell similar / related profile machines to your there. I will recommend you related profile drawings.
2.3 : Tell me any information you have and it will be helpful for me to clear your needed profiles. and then quote you.
3. What your company advantages?
Yes sir/Madam. Our advantages have :
3.1: We are a 15 years big factory. We have abundant machine designing and making experience. We can give you the best machine solution.
3.2: We have completed production system. And more than 20 sets of CNC machines which can support lots of machine orders' making and guarantee the delivery.
3.3 : We have 20 years foreign trade exported experience. Our sellers abundant experience can guarantee you will have a pleasant purchase and use of the machine and after-sales experience. And cooperated with us , you can get more details about the machine, including those problems that you can't think of but we can think of, we can tell you to ensure that you can buy the most suitable machine for you.
3.4 : We are a golden integrity roll forming machine company.
About the after-sale services, no worries, we will responsible for you.
4. Will i receive a good machine ? Same Like I wanted to?
Yes sir/Madam. We will do the machine according to your profile drawing . About the profile drawing, we will confirm with you again before producing your machine. Then, after the machine finished, we will test the machine and guarantee the machine you received is a good machine. Because after you satisfied with the machine, and then you pay balance.
5. What is the machine minimum quantity?
One machine is okay.
6. What is your payment terms?
6.1 : We accept 30% T/T as deposit and 70% T/T as balance before shipping.
6.2 : We accept 100% L/C at sight
6.3: We accept Western Union payments.
6.4 : Other payment terms you want to pay, please let me know and i will check and reply you.
