Цементный инструмент J-slot механическая подвеска для обшивки

Цементный инструмент J-slot механическая подвеска для обшивки

Категория: Oil Field Equipment >>>
Поставщик: Shandong,Yacheng,Petroleum,Technology,Co.,Ltd.

Цена:8 000,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-20-2025	9520.2 $*	9996.82 $*
Aug-20-2025	9440.66 $*	9912.71 $*
Jul-20-2025	7920.76 $*	8316.34 $*
Jun-20-2025	9280.63 $*	9744.24 $*
May-20-2025	8080.44 $*	8484.6 $*
Apr-20-2025	9120.56 $*	9576.43 $*
Mar-20-2025	9040.46 $*	9492.81 $*
Feb-20-2025	8960.53 $*	9408.47 $*
Jan-20-2025	8880.65 $*	9324.99 $*

Характеристики

Product Overview

The liner hanger is used to realize liner cementing, reduce the casing weight of deep well once running, improve the load of the drilling rig lifting system when running casing, and reduce the flow resistance of cement slurry for injection and replacement, which is conducive to safe construction. Through liner tieback, the problem of drilling operation affected by upper casing wear can be solved; The use of liner suspension cementing technology can also reduce casing consumption and save drilling costs

FEATURES AT A GLANCE

1 A J-slot guides the guiding pin for hanger setting. The liner hanger can be set simply by picking up the drill string, using
right hand rotation to achieve 1/2 turn at the hanger position and lowering the drill string.
2 The liner hanger system does not require a cylinder or a setting ball. Therefore, it is suitable for a liner string with several
hydraulically activated tools.
3 The setting tool can be easily released just by slacking off certain weight and using right hand rotation.
4 Retrievable Pack-off Bushing can be retrieved with setting tool, eliminating drill-out.

PRODUCT SPECIFICATIONS

Size (Csg x Liner)	Casing Weight			Max O.D.
in.	kg/m	lb/ft	mm	in.
10-3/4 x 7-5/8	67.71	45.50	240	9.449
		75.90			51.00
		82.59			55.50
9-5/8 x 7	59.53	40.00	215	8.465
		64.74			43.50
		69.94			47.00
8-5/8 x 6-5/8	65.48	44.00	185	7.283
7-5/8 x 5-1/2	44.20	29.70	165	6.496
		50.15			33.70
		58.04			39.00
7 x 5	38.69	26.00	152	5.984
		43.16			29.00
		47.62			32.00
6-5/8 x 4-3/4	47.62	32.00	137	5.394
