Product Description
C300 Italian Manufacturer and technology CE Certification combine universal multi-function woodworking machine
Funcions show
Planer
Thicknesser
Mortister
(Sliding table saw)
Circular saw
(Spindle moulder)
Shaper
Specification
Planer | ||
Working table | 300x1500mm | |
Cutterblock diameter | 70mm | |
Cutterblock rotation speed | 5700r.p.m. | |
Straight cutters number | 3pcs | |
Cutter dimensions | 300x20x3(300x25x3)mm | |
Max table adjustment | 4mm | |
Thicknesser | ||
Working table | 300x660mm | |
Feed speed | 7m/min | |
Max. working height | 4-220mm | |
Cutterblock rotation speed | 5700r.p.m. | |
Max. cutting depth | 4mm | |
Mortiser | ||
Working table | 250x500mm | |
Travelling distance | 205/95/90mm | |
Chuck(M18*1.5-S) | 0-16mm | |
Churck rotation speed | 5700r.p.m. | |
(Sliding table saw) Circular saw | ||
Working table | 220x1000mm | |
Shaft rotation speed | 4500/7000r.p.m. | |
Blade diameter | 250*30mm | |
Cutting height 45°/90° | 50/80mm | |
Max. distance between blade and fence | 500mm | |
Scoring saw diameter | 90*22mm | |
(Spindle moulder) Shaper | ||
Working table | 220x1000mm | |
Shaft rotation speeds | 2000/3100/4400/7000r.p.m. | |
Standard shaft diameter | 30/35/50mm | |
Spindle lenght | 105mm | |
Shaft vertical stroke | 115mm | |
Max. tool diameter | 160mm | |
Max. tenoning depth | 55mm | |
Whole machine | ||
Motor power | 2.2kw(3HP) | |
Voltage | can be customized | |
Machine size | 2200*1590*875mm | |
Machine weight | 560kg | |
Packing size | 1676x1130x1065 mm | |
Packing Weight | 750kg | |
Package | Plywood box | |
