Настенный Кондиционер Настенный Сплит Кондиционер
US $500.00-$520.00
AMPSOL Aire Acondicionado Solar 7000Btu 9000Btu 12000Btu Ac Dc инвертор солнечный мини-кондиционер с
- Категория: Air Conditioners >>>
- Поставщик: Taizhou,Haishang,Imp.&Exp.,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 652.8 $* | 685.52 $* |
| Aug-19-2025 | 647.84 $* | 679.73 $* |
| Jul-19-2025 | 543.62 $* | 570.87 $* |
| Jun-19-2025 | 636.46 $* | 668.60 $* |
| May-19-2025 | 553.5 $* | 581.6 $* |
| Apr-19-2025 | 625.45 $* | 656.86 $* |
| Mar-19-2025 | 619.89 $* | 650.41 $* |
| Feb-19-2025 | 614.76 $* | 645.23 $* |
| Jan-19-2025 | 608.48 $* | 638.38 $* |
Характеристики
Products Description
Model | Unit | DGWA2-ACDCBLW-12K | DGWA1-ACDCBLW-18K | DGWA1-ACDCBLW-24K | ||
Climate Type | Tropical | T3/T1 | T3/T1 | T3/T1 | ||
Application area | m2 | 12-20 | 20-30 | 30-42 | ||
Power Supply | AC Power | Ph-V-Hz | 1Ph 208V-240V/50-60HZ | 1Ph 208V-240V/50-60HZ | 1Ph 208V-240V/50-60HZ | |
DC Power (PV in Series) | V | 80-380V | 80-380V | 80-380V | ||
DC Power Current | A | |||||
Adviced Solar Panel | Pcs | (3-4)*330W in series | (3-6)*330W in series | (3-8)*330W in series | ||
Rated Cooling | Capacity(T1) | W | 3510(900-3900) | 5070(1200-6000) | 6450(1800-7900) | |
BTU | 12000(3000-13300) | 17300(4100-20400) | 22000(6100-27000) | |||
Power input(T1) | W | 940(190-1270) | 1400(220-2100) | 1790(300-3200) | ||
Capacity(T3) | W | 2910 | 4290 | 5130 | ||
BTU | 9900 | 14700 | 17500 | |||
Power input(T3) | W | 1050 | 1630 | 1940 | ||
Rated Heating | Capacity | W | 4100(1000-4500) | 6100(1200-6800) | 7800(1800-9100) | |
BTU | 14000(3000-15300) | 20800(4100-23000) | 26600(6100-31000) | |||
Power input | W | 1170(190-1700) | 1770(220-2500) | 2290(300-3500) | ||
T1 EER (W/W)/ (BTU/W) | / | 3.75/12.75 | 3.60/12.35 | 3.60/12.30 | ||
T3 EER (W/W)/ (BTU/W) | / | 2.75/9.45 | 2.65/9.00 | 2.65/9.00 | ||
COP (W/W)/ (BTU/W) | / | 3.50/11.95 | 3.45/11.75 | 3.40/11.60 | ||
Dehumidification capacity | L/h | 1.3 | 1.7 | 2.5 | ||
Compressor | Model | / | WHP04200 | WHP05600 | 5RD198 | |
Type | / | 2xRotary Inverter | 2xRotary Inverter | 2xRotary Inverter | ||
Brand | / | Highly | Highly | Panasonic | ||
Indoor fan motor | Model | BLDC-15W | BLDC-45W | BLDC-45W | ||
Speed(Turbo/Hi/Mi/Lo) | r/min | 1300/1200/1100/950 | 1050/950/850/750 | 1350/1250/1150/1000 | ||
Indoor air flow(Turbo/Hi/Mi/Lo) | m3/h | 540/485/435/350 | 980/880/740/620 | 1290/1180/1070/900 | ||
Indoor noise level (Turbo) | dB(A) | ≤42.5 | ≤46 | ≤50 | ||
Indoor unit | Dimension(W×H×D) | mm | 840×205×295 | 1080×330×237 | 1080×330×237 | |
Packing (W×H×D) | mm | 920×290×360 | 1140×300×382 | 1140×300×382 | ||
Net weight/Gross weight | Kg | 9.0/12.5 | 15.0/18.5 | 15.0/18.5 | ||
Outdoor fan motor | Model | / | BLDC-40W | BLDC-55W | BLDC-75W | |
Speed | r/min | 880 | 880 | 850 | ||
Outdoor air flow | m3/h | 2100 | 2200 | 3300 | ||
Outdoor noise level | dB(A) | ≤52 | ≤55 | ≤58 | ||
Outdoor unit | Dimension(W×H×D) | mm | 802×564×323 | 802×564×323 | 900×700×337 | |
Packing (W×H×D) | mm | 910×622×405 | 910×622×405 | 1006×755×418 | ||
Net/Gross weight | Kg | 33.5/37.5 | 37/42.0 | 50/54.5 | ||
Refrigerant type | / | R410A | R410A | R410A | ||
Max Design pressure | MPa | 4.3/1.5 | 4.3/1.5 | 4.3/1.5 | ||
Refrigerant copper pipe | Gas side/Liquid side (inch) | inch | 3/8 1/4 | 1/2 1/4 | 1/2 1/4 | |
Max. refrigerant pipe length | m | 15 | 20 | 25 | ||
Max. difference in level | m | 8 | 10 | 10 | ||
Drain pipe size | mm | 16 | 16 | 16 | ||
Refrigerant connction copper pipe length | m | 3 | 4 | 4 | ||
Connection wire length | m | 4 | 5 | 5 | ||
Electronic Expansion Valve | / | Yes | Yes | Yes | ||
Loading QTY 40" Hq/ 20"GP | Sets | 200/85 | 165/75 | 130/60 | ||
