Мини-машина для сбора хлопка
US $470.00-$498.00
Маленький комбинированный рисоуборочный аппарат машина для сбора соевых бобов
- Категория: Harvesters >>>
- Поставщик: Shenzhen,Yishitong,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-15-2025 | 672.62 $* | 685.22 $* |
| Jul-15-2025 | 545.38 $* | 556.95 $* |
| Jun-15-2025 | 661.7 $* | 674.1 $* |
| May-15-2025 | 656.59 $* | 669.88 $* |
| Apr-15-2025 | 524.16 $* | 534.18 $* |
| Mar-15-2025 | 645.95 $* | 658.76 $* |
| Feb-15-2025 | 640.24 $* | 653.62 $* |
| Jan-15-2025 | 635.98 $* | 648.40 $* |
Характеристики
Products Description
Mini walking tractor harvester machine
Mini walking tractor are low price and easy for driving.
Farm walking tractors have high ground clearance ,wide wheel tread and stable.
This two wheel tractors adopt multi working land,such as muddy land,mountaainous ,plain ,terrace field.
Walking tractor can be matched with all kinds of implements.
This two wheel tractors adopt multi working land,such as muddy land,mountaainous ,plain ,terrace field.
Walking tractor can be matched with all kinds of implements.
Overall Dimensions(mm) | 2680*960*1100（mm） | ||
Wheel Tread(mm) | 680-1000mm | ||
Min. Ground Clearance(mm) | 241 | ||
Min. use weight(kg) | 465 | ||
Gear | Forward/reverse, 6/2 | ||
Tyre | 6 - 14 | ||
Speed(km/h) | Forward | 2.58、3.95、6.17、7.71、11.81、18.49 | |
Reverse | 1.94、5.81 | ||
Engine | Brand | Yibiyuan | |
Type | Diesel Single cylinder; horizontal; 4 stroke; water cooled | ||
Rated Power(km/hp) | 13.2/18HP | ||
Rated Speed(r/min) | 2200 | ||
Bore × Stroke (mm) | 110×115 | ||
Specific Fuel Consumption(g/kw*h) | ≤269.6 | ||
Large quality chassis: three-slot clutch, king gear, heavy-duty gearbox, thickened handle, assembled diesel engine size: length 230cm, width 75-90cm, height 95cm, equipped with 4-hole 600-12 tires, most of them are used in ordinay dry fields. It is equipped with 8-13 horsepower diesel engine with 10.8-17cm gearbox interface.
Small boutique chassis: three-slot clutch, king gear, heavy-duty gearbox, thickened handle, assembled diesel engine size: length 185cm, width 75-90cm, height 75cm, equipped with 4-hole 500-10 tires, mostly dry farms, orchards , Vegetable plots and other places with limited space. It is equipped with 8-13 horsepower diesel engine with 10.8-17cm gearbox interface.
Square handle chassis: two-slot clutch, king gear, heavy-duty gearbox, assembled diesel engine size: length 230cm, width 75-90cm, height 95cm, with 4-hole 600-12 tires, most of them are used in ordinary dry fields. It is equipped with 8-13 horsepower diesel engine with 10.8-17cm gearbox interface.
High-clutch water and dry chassis: three-slot clutch, I-beam, heavy-duty gearbox, assembled diesel engine size: length 230cm, width 75-90cm, height 110cm, with 4 hole 600-12 tires, can be used in paddy and dry fields . It is equipped with 8-13 horsepower diesel engine with 10.8-17cm gearbox interface.
The 121 chassis is an upgraded version of the 101 square-handle chassis: three-slot clutch, I-beam, malleable steel heavy-duty gearbox, assembled diesel engine size: length 230cm, width 75-130cm, height 100cm, with malleable steel 5-hole 600-12 or 600- 14 tires, mostly used in dry fields. It is equipped with 8-18 horsepower diesel engine. (Note: The track can be customized, and the tire model can be customized). Transmission interface 10.8-17cm.
The 151 chassis: four-slot clutch, I-shaped gear, heavy gearbox, assembled diesel engine Dimensions: length 268cm, width 96cm, height 110cm, with big four-hole 600-12 tires, can be used in paddy and dry fields. It is equipped with 15-28 horsepower diesel engine. This model is Dachai's conversion chassis, and the gearbox interface is 14-14cm.
Small boutique chassis: three-slot clutch, king gear, heavy-duty gearbox, thickened handle, assembled diesel engine size: length 185cm, width 75-90cm, height 75cm, equipped with 4-hole 500-10 tires, mostly dry farms, orchards , Vegetable plots and other places with limited space. It is equipped with 8-13 horsepower diesel engine with 10.8-17cm gearbox interface.
Square handle chassis: two-slot clutch, king gear, heavy-duty gearbox, assembled diesel engine size: length 230cm, width 75-90cm, height 95cm, with 4-hole 600-12 tires, most of them are used in ordinary dry fields. It is equipped with 8-13 horsepower diesel engine with 10.8-17cm gearbox interface.
High-clutch water and dry chassis: three-slot clutch, I-beam, heavy-duty gearbox, assembled diesel engine size: length 230cm, width 75-90cm, height 110cm, with 4 hole 600-12 tires, can be used in paddy and dry fields . It is equipped with 8-13 horsepower diesel engine with 10.8-17cm gearbox interface.
The 121 chassis is an upgraded version of the 101 square-handle chassis: three-slot clutch, I-beam, malleable steel heavy-duty gearbox, assembled diesel engine size: length 230cm, width 75-130cm, height 100cm, with malleable steel 5-hole 600-12 or 600- 14 tires, mostly used in dry fields. It is equipped with 8-18 horsepower diesel engine. (Note: The track can be customized, and the tire model can be customized). Transmission interface 10.8-17cm.
The 151 chassis: four-slot clutch, I-shaped gear, heavy gearbox, assembled diesel engine Dimensions: length 268cm, width 96cm, height 110cm, with big four-hole 600-12 tires, can be used in paddy and dry fields. It is equipped with 15-28 horsepower diesel engine. This model is Dachai's conversion chassis, and the gearbox interface is 14-14cm.
Application
Product packaging
Company Profile
Workshop & product line
We have excellent R&D and sales team, professional technicians provide one-to-one service to solve all your worries.
Carefully selected products with reliable quality control.
Carefully selected products with reliable quality control.
We offers a full selection of products from small to large-sized tractors for diverse applications and scales. Moreover, our tractor-mounted implements are designed for plowing, harrowing and many other tasks.
Our high levels of performance and reliability have helped the company establish a strong reputation in China.
The company has 100 employees and 15 technicians, covering an area of 15000 square meters, with a registered capital of 1.2 million and an annual sales of 50 million. The company mainly produces sand screening machine, coal powder machine, sand washing machine,plate saw, brick cutting machine, food machinery and so on. The company is widely sold in South America ，North America，Africa,Europe and other countries. The company has strong technical force, high quality team, strict quality management,advanced manufacturing equipment.
FAQ
Q1: Are you a manufacturer or Trader ?
A1: We are a professional manufacture , we have our own R&D team and sales team, we provide one-stop service.
A2: Generally, we pack our goods in Neutral Boxes and brown cartons.
Q3: How about delivery time?
A3: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q4: How about after-sales service?
A4: 24-hour online response, if there is any problem with the tractor, a solution will be given within 24 hours, video maintenance teaching will be provided, and damaged parts will be sent free of charge
