Настенный Кондиционер Настенный Сплит Кондиционер
US $500.00-$520.00
ZERO Z-MAX 24000 Btu внутренней секреции зоны Сплит Кондиционеры тепловой насос с передачей тепла от инвертор кондиционер
- Категория: Air Conditioners >>>
- Поставщик: Zero,Technologies,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 64198.56 $* | 67408.63 $* |
| Aug-17-2025 | 63659.38 $* | 66842.15 $* |
| Jul-17-2025 | 53409.6 $* | 56079.73 $* |
| Jun-17-2025 | 62580.56 $* | 65709.9 $* |
| May-17-2025 | 54487.92 $* | 57211.0 $* |
| Apr-17-2025 | 61501.32 $* | 64576.93 $* |
| Mar-17-2025 | 60961.66 $* | 64009.38 $* |
| Feb-17-2025 | 60422.20 $* | 63443.72 $* |
| Jan-17-2025 | 59882.35 $* | 62876.36 $* |
Характеристики
Multi Zone Outdoor Condenser
| Multi Zone ODU TeHnical Specifications | ODU 1 drive 2 | ODU 1 drive 3 | ODU 1 drive 4 | ||
| Z2U20607000143 | Z2U20607000144 | Z2U20607000145 | |||
| Model No. | ZMZB-18HVT-USO | ZMZB-2HVT-USO | ZMZB-36HVT-USO | ||
| Type | cooling&heating | cooling&heating | cooling&heating | ||
| Power supply | 208-230V~/60Hz/1P | 208-230V~/60Hz/1P | 208-230V~/60Hz/1P | ||
| Rated heating capacity 95°F /35℃ | Btu/h | 17000 | 24000 | 32000 | |
| Rated heating capacity 47°F /8.33℃ | Btu/h | 19600 | 26000 | 35000 | |
| SEER | Btu/W.h | 22.0 | 22.0 | 21.5 | |
| EER 95°F /35℃ | Btu/W.h | 12.5 | 12.5 | 12.5 | |
| HSPF4 | Btu/W.h | 10.0 | 10.0 | 10.0 | |
| HSPF5 | Btu/W.h | 8.0 | 8.0 | 8.0 | |
| COP 47°F /8.33℃ | W/W | 3.5 | 3.5 | 3.5 | |
| COP 5°F /-15℃ | W/W | 1.75 | 1.75 | 1.75 | |
| Condensor | Rows*Diameter | 2-φ9.52 | 2-φ7 | 3-φ7 | |
Length(L)xHeight(H)xWidth(W) | mm | 623x660x223 | 764x756x303 | 926x882x40 | |
| Noise level | dB(A) | 56 | 58 | 63 | |
| Connecting Pipe | Gas | inches | 3/8 | 3/8 | 3/8 |
| Liquid | inches | 1/4 | 1/4 | 1/4 | |
| Throtting mode Capalliary/EEV. | EEV | EEV | EEV | ||
| Refrigerant quntity | OZ | 65.26 | 77.6 | 123.46 | |
| Net dimensions(WxHxD) | mm | 960x430x750 | 1028x475x865 | 1040x440x1000 | |
| Net weight | kg | 44 | 56 | 75.5 | |
| Packing dimensions(WxHxD) | mm | 960x430x750 | 1028x475x865 | 1040x440x1000 | |
| inches | 37.79x16.92x29.53 | 40.47x18.7x34.06 | 40.95x17.32x39.37 | ||
| Gross weight | kg | 47.5 | 60.5 | 84.5 | |
| Factory PreHarge Line | m | 7.5 | 7.5 | 7.5 | |
| Total length of liquid pipe | m | 30 | 45 | 60 | |
| MXimum Line Length | m | 20 | 20 | 20 | |
| MXimum Height Difference Between Indoor And Outdoor | m | 10 | 10 | 10 | |
| Room temperature | indoor(cooling/heating) | ℃ | 16℃~30℃ | 16℃~30℃ | 16℃~30℃ |
| Outdoor(cooling/heating) | ℃ | -15~50℃~-20~30℃ | -15~50℃~-20~30℃ | -15~50℃~-20~30℃ | |
| Loading Capacity(ODU | 40' HC/ 40'GP/ 20'GP | 189/188/89 | 143/96/44 | 114/114/54 | |
