Паровой бойлер для горячей воды с защитой окружающей среды
US $4000-$5000
Низкий уровень загрязнения окружающей среды сгорания 10 тонн работающий на угле паровой котел для питья
- Категория: Boilers >>>
- Поставщик: Taishan,Group,Taian,Boao,International,Trade,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.90 $* | 0.46 $* |
| Aug-16-2025 | 0.42 $* | 0.36 $* |
| Jul-16-2025 | 0.88 $* | 0.42 $* |
| Jun-16-2025 | 0.79 $* | 0.44 $* |
| May-16-2025 | 0.22 $* | 0.40 $* |
| Apr-16-2025 | 0.45 $* | 0.50 $* |
| Mar-16-2025 | 0.63 $* | 0.47 $* |
| Feb-16-2025 | 0.31 $* | 0.64 $* |
| Jan-16-2025 | 0.23 $* | 0.95 $* |
Характеристики
SPECIFICATION
BOILER MODEL | SZS6-1.25-AIII | SZS6-1.6-AIII | SZS8-1.25-AIII | SZS8-1.6-AIII | SZSIO-1.25-AIII | SZS10-1.6-AIII | SZS15-1.25-AIII | SZS20-1.25-AIII | SzS20-1.6-AIII | ||||||||
RATED HEAT POWER (t/h) | 6 | 6 | 8 | 8 | 10 | 10 | 15 | 20 | 20 | ||||||||
RATED OUTLET PRESSURE(MPa) | 1.25 | 1.6 | 1.25 | 1.6 | 1.25 | 1.6 | 1.25 | 1.25 | 1.6 | ||||||||
STEAM TEMPERATURE(℃) | 193,3 | 204,2 | 193,3 | 204.2 | 193.3 | 204,2 | 193,3 | 193,3 | 204.2 | ||||||||
FEEP WATER TEMPERATURE(℃） | 105 | 105 | 105 | 105 | 105 | 105 | 105 | 105 | 104 | ||||||||
SUITABLE FUEL | Ⅲ soft pulverized coal | ||||||||||||||||
DESIGN HEAT EFFICIENCI(%) | 90.91 | 90.76 | 90.91 | 90.76 | 91.49 | 90.76 | 90.91 | 90.91 | 90.49 | ||||||||
FUEL COMSUMPTION(kg/h) | 536.77 | 540.09 | 715.7 | 720.12 | 933.13 | 900.15 | 1341.92 | 1789.24 | 1895.5 | ||||||||
SUITABLE PONER(AC) | 380V/50Hz | ||||||||||||||||
PROPER DIMENSION(m)L×B×H | 10.9*2.9*3.6 | 10.9*2.9*3.6 | 11.8*3.2*3.7 | 11.8*3.2*3.7 | 13.2*4.1*4.9 | 12.6*3.4*3.8 | 13.6*3.7*3.8 | 14.7*4.1*3.9 | 13.2*5.4*4.8 | ||||||||
TEMPERATURE OF DRAIN GAS(℃) | 137 | 140 | 137 | 140 | 134 | 140 | 137 | 137 | 158 | ||||||||
MAIN OUTLET DN | 150 | 150 | 150 | 150 | 150 | 150 | 200 | 200 | 200 | ||||||||
MAIN BLOW DOWN PIPE(DN) | 50 | 50 | 50 | 50 | 50 | 40 | 50 | 50 | 50 | ||||||||
FEED WATER DN | 40 | 40 | 40 | 40 | 50 | 50 | 65 | 65 | 65 | ||||||||
SAFETYVALYE DN | 80 | 80 | 80 | 80 | 80 | 80 | 100 | 100 | 100 | ||||||||
WATER LEVEL MONITOR | electrode,floating ball,balance vessel | ||||||||||||||||
COMBUSTION MONITOR | the photosensitive element | ||||||||||||||||
PRESSURE MONITOR | the pressure controler | ||||||||||||||||
PRODUCT DISPLAY
PRIDUCT ACESSORIES
COAL FIRED PARTS
APPLICATION
MORE PRODUCTS
COMPANY PROFILE
FAQ
1. How to get a boiler price?
Pls tell us below information to confirm the boiler model first, and then offer the right boiler price:
1.1 Which fuel you prefer for the boiler, coal, biomass, gas & oil, or others?
1.2 The boiler capacity
1.3 The boiler pressure
1.4 The boiler application
2. How long is the product warranty period ?
Our boilers have one year warranty period or depending on your requirements.
3. What about after-sale service?
We will supply professional after-sale service team as soon as we receiving your problem feedback, and dispatch our engineers to your country and solve your problems right now.
4. What's the advantages of your company?
4.1 Reasonable heat surface and burning device, heat efficiency is 4%~5% higher than national standard.
4.2 Reasonable flue gas speed, heating surface without ash deposition and no abrasion, under the condition of no soot-blowing, the boiler can work full-load, high-efficiency and safety in long term.
4.3 The big and tall boiler furnace can be designed according to the different fuel to improve the burning rate of fuel and remove black smoke.
4.4 All independent loop and reasonable coal boiler injected circulation are specially designed and adopted for the hot water boilers. The medium speed in loop of heat surface is higher than national standard
4.5 1-20T/H & 0.7-14MW boiler adopt big and high strength grate, add rolling device improves the boilers’ 4.6 Over 20T/H & 14MW boiler adopt flake type or beam type chain grate, less coal leakage, convenient burning adjustment. Closed soot cleaning avoid second pollution and save time and labor.
4.7 Dust inertia separation at the furnace outlet can reduce exhaust gas concentration and lessen abrasion of rear heat surface.
4.8 Compact structure makes its installation volume smaller than other types of boilers, it will shorten installation period and lower boiler room cost.
4.9 Big water volume benefits for power-off protection, high ability suitable for load changing.
