SRNE серия ASF 48 в 10 кВт 120 В/240 сплит-фазный гибридный солнечный несетевой
- Категория: Solar Energy Products >>>
- Поставщик: Srne,Solar,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 134817.79 $* | 141558.87 $* |
| Aug-19-2025 | 133685.8 $* | 140369.83 $* |
| Jul-19-2025 | 112159.11 $* | 117767.2 $* |
| Jun-19-2025 | 131419.74 $* | 137990.16 $* |
| May-19-2025 | 114425.71 $* | 120146.90 $* |
| Apr-19-2025 | 129153.12 $* | 135611.63 $* |
| Mar-19-2025 | 128020.33 $* | 134421.63 $* |
| Feb-19-2025 | 126887.24 $* | 133231.41 $* |
| Jan-19-2025 | 125754.54 $* | 132042.2 $* |
Характеристики
Products Description
Efficient
* Dual MPPT with up to 99.9% efficiency
* Up to 22A PV input current perfect for high power modules
* Up to 22A PV input current perfect for high power modules
Reliable
* Outputs high quality pure sine wave AC power
* 8-10kW load power to meet the needs of most households
* 8-10kW load power to meet the needs of most households
User-friendly
* Industrial design with a modern aesthetic look
* Easy to install and simple to use
* Easy to install and simple to use
Safety
* 360 degrees of security from hardware to software
* EU、IEC safety approvals
* EU、IEC safety approvals
All-in-one
* Solar Charger Controller up to 200A charging current
* Support for Li-ion battery BMS communication
* Support for Li-ion battery BMS communication
Intelligent
* Exclusive Li-ion battery BMS dual activation
* Time-slot function to save cost with peak-valley tariff
* Time-slot function to save cost with peak-valley tariff
Specification
Model | ASF4880U180-H | ASF48100U200-H | ||
INVERTER OUTPUT | ||||
Rated Output Power | 8,000W | 10,000W | ||
Max.Peak Power | 16,000W | 20,000W | ||
Rated Output Voltage | 120/240Vac（L1/L2/N/PE split phase） | |||
Load Capacity of Motors | 5HP | 6HP | ||
Rated AC Frequency | 50/60Hz | |||
Waveform | Pure Sine Wave | |||
Switch Time | 10ms（typical） | |||
BATTERY | ||||
Battery Type | Li-ion / Lead-Acid / User Defined | |||
Rated Battery Voltage | 48Vdc | |||
Voltage Range | 40-60Vdc | |||
Max.MPPT Charging Current | 200A | |||
Max.Mains/Generator Charging Current | 100A | 120A | ||
Max.Hybrid Charging Current | 180A | 200A | ||
PV INPUT | ||||
Num. of MPP Trackers | 2 | |||
Max.PV array power | 11,000W | |||
Max.input current | 22/22A | |||
Max.Voltage of Open Circuit | 500Vdc | |||
MPPT Voltage Range | 125-425Vdc | |||
EFFICIENCY | ||||
MPPT Tracking Efficiency | 99.9% | |||
Max. Battery Inverter Efficiency | 92% | |||
GENERAL | ||||
Dimensions | 620*435*130mm（2*1.4*0.4ft） | |||
Weight | 20kg（44lb） | 21kg（46.3lb） | ||
Protection Degree | IP20，Indoor Only | |||
Operating Temperature Range | -15~55℃,>45℃ derated （5~131℉，>113℉ derated） | |||
Cooling Method | Internal Fan | |||
Warranty | 2 Years | |||
CERTIFICATION | ||||
Safety | IEC62109-1, IEC62109-2,UL1741 | |||
EMC | EN61000-6-1, EN61000-6-3, FCC 15 class B | |||
RoHS | Yes | |||
