Gps-измерительное устройство South G2 Rover оборудование для наблюдения за Землей Gnss RTK
- Категория: Other Test Instrument >>>
- Поставщик: Tianjin,New,Starr,Technology,Trade,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 6248.30 $* | 6560.79 $* |
| Aug-16-2025 | 6195.83 $* | 6505.32 $* |
| Jul-16-2025 | 5198.14 $* | 5458.23 $* |
| Jun-16-2025 | 6090.47 $* | 6395.37 $* |
| May-16-2025 | 5303.24 $* | 5568.22 $* |
| Apr-16-2025 | 5985.64 $* | 6284.93 $* |
| Mar-16-2025 | 5933.89 $* | 6230.81 $* |
| Feb-16-2025 | 5880.57 $* | 6174.9 $* |
| Jan-16-2025 | 5828.47 $* | 6119.60 $* |
Характеристики
Product Description
Channels:965
GPS:L1, L1C, L2C, L2P, L5
GLONASS:G1, G2, G3
GALILEOS:E1, E5A, E5B, E6C, AltBOC*
SBAS:L1*
IRNSS:L5*
QZSS:L1, L2C, L5*
Hardware Performance
Dimension:130.5mm(φ) × 84mm(H)
Weight:850g (battery included)
Operating temperature:-25℃ ~ +65℃
Storage temperature:-35℃ ~ +80℃
Humidity:100% Non-condensing
Recommend Products
Details Images
Specification
GNSS Features | Channels | 965 |
GPS | L1, L1C, L2C, L2P, L5 | |
GLONASS | G1, G2, G3 | |
BDS | BDS-2: B1I, B2I, B3I | |
BDS-3: B1I, B3I, B1C, B2a, B2b* | ||
GALILEOS | E1, E5A, E5B, E6C, AltBOC* | |
SBAS | L1* | |
IRNSS | L5* | |
QZSS | L1, L2C, L5* | |
MSS L-Band (Reserve) | ||
Positioning output rate | 1Hz~20Hz | |
Initialization time | < 10s | |
Initialization reliability | > 99.99% | |
Code differential | Horizontal: 0.25 m + 1 ppm RMS | |
Positioning Precision | GNSS positioning | Vertical: 0.50 m + 1 ppm RMS |
GNSS static | Horizontal: 2.5 mm + 0.5 ppm RMS | |
Vertical: 5 mm + 0.5 ppm RMS | ||
Real-time kinematic | Horizontal: 8 mm + 1 ppm RMS | |
(Baseline<30km) | Vertical: 15 mm + 1 ppm RMS | |
SBAS positioning | Typically < 5m 3DRMS | |
RTK initialization time | 2 ~ 8s | |
IMU tilt compensation | Additional horizontal pole tip uncertainty | |
typically less than 10mm + 0.7 mm/° tilt down to 30° | ||
IMU tilt angle | 0° ~ 60° | |
Hardware Performance | Dimension | 130.5mm(φ) × 84mm(H) |
Weight | 850g (battery included) | |
Material | Magnesium aluminum alloy shell | |
Operating temperature | -25℃ ~ +65℃ | |
Storage temperature | -35℃ ~ +80℃ | |
Humidity | 100% Non-condensing | |
Waterproof/Dustproof | IP68 standard, protected from long time immersion to depth of 1m IP68 standard, fully protected against blowing dust | |
Shock/Vibration | Withstand 2 meters pole drop onto the cement ground naturally | |
Power supply | 6-28V DC, overvoltage protection | |
Battery | Inbuilt 6800mAh rechargeable, removable Lithium-ion battery | |
Battery life | Single battery: 16h (static mode), 8h (Base + UHF), 12h (Rover + UHF), 15h (Rover + Bluetooth) | |
Communications | I/O Port | 5PIN LEMO external power port + Rs232 |
Type-C interface (charge + OTG + Ethernet) | ||
1 UHF antenna interface | ||
SIM card slot (Micro SIM) | ||
Internal UHF | Radio receiver and transmitter, 1W/2W/3W switchable | |
Frequency range | 410 - 470MHz | |
Communication protocol | Farlink, Trimtalk450s, SOUTH, SOUTH+, SOUTHx, HUACE, Hi-target, Satel | |
Communication range | Typically 8km with Farlink protocol | |
Cellular mobile network | 4G cellular module standard, customizable 5G module | |
Bluetooth | Bluetooth 3.0/4.1 standard, Bluetooth 2.1 + EDR | |
NFC Communication | Realizing close range (shorter than 10cm) automatic pair between receiver and controller (controller requires NFC wireless | |
communication module else) | ||
WIFI | Modem | 802.11 b/g standard |
WIFI hotspot | Receiver broadcasts its hotspot form web UI accessing with any mobile terminals | |
WIFI datalink | Receiver can transmit and receive correction data stream via WiFi datalink | |
Data Storage/Transmission | Storage | 8GB SSD internal storage standard, extendable up to 64GB |
Automatic cycle storage (The earliest data files will be removed automatically while the memory is not enough) | ||
Support external USB storage | ||
The customizable sample interval is up to 20Hz | ||
Data transmission | Plug and play mode of USB data transmission | |
Supports FTP/HTTP data download | ||
Data format | Static data format: STH, Rinex2.01, Rinex3.02 and etc. | |
Differential data format: CMR, SCMRx, RTCM 2.1, RTCM 2.3, RTCM 3.0, RTCM 3.1, RTCM 3.2 | ||
GPS output data format: NMEA 0183, PJK plane coordinate, Binary code, Trimble GSOF | ||
Network model support: VRS, FKP, MAC, fully support NTRIP protocol | ||
Sensors | Electronic bubble | Controller software can display electronic bubble, checking leveling status of the carbon pole in real-time |
IMU | Built-in IMU module, calibration-free and immue to magnetic interference | |
Thermometer | Built-in thermometer sensor, adopting intelligent temperature control technology, monitoring and adjusting the receiver | |
temperature | ||
User Interaction | Operating system | Linux |
Buttons | Single button | |
Indicators | 5 LED indicators | |
Web interaction | With the access of the internal web interface management via WiFi or USB connection, users are able to monitor the receiver status | |
and change the configurations freely | ||
Voice guidance | It provides status and operation voice guidance, and supports Chinese/English/Korean/Spanish/Portuguese/Russian/Turkish | |
Secondary development | Provides secondary development package, and opens the OpenSIC observation data format and interaction interface definition | |
Cloud service | The powerful cloud platform provides online services like remote manage, firmware update, online register and etc. |
