Паровой бойлер для горячей воды с защитой окружающей среды
US $4000-$5000
Промышленный паровой котел высокого
- Категория: Boilers >>>
- Поставщик: Henan,Yuji,Boiler,Vessel,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 3570.0 $* | 3749.77 $* |
| Aug-15-2025 | 3540.56 $* | 3717.95 $* |
| Jul-15-2025 | 2970.93 $* | 3119.24 $* |
| Jun-15-2025 | 3480.52 $* | 3654.97 $* |
| May-15-2025 | 3030.73 $* | 3182.39 $* |
| Apr-15-2025 | 3420.72 $* | 3591.92 $* |
| Mar-15-2025 | 3390.93 $* | 3560.46 $* |
| Feb-15-2025 | 3360.46 $* | 3528.1 $* |
| Jan-15-2025 | 3330.32 $* | 3497.60 $* |
Характеристики
Product Overview
Oil Gas Fired Boiler is a safe, efficient and fully automatic heating equipment. This series of equipment is horizontal, fire tube,three return, wet back structure, with high efficiency, small volume, convenient installation, simple operation, stable operation,wide range of application and other characteristics.
Important note: this series of boilers can be hoisted as a whole, convenient for mobile transportation, and suitable for oilfield heating and other field operations.
* Steam volume: 0.5t/h-20t/h (hot water: 0.35mw-14mw)
* Steam pressure: 0.4MPa ~ 2.5MPa (optional as required)
* Fuel: oil field, field equipment heating. Construction site heating, outdoor heating and other special needs.
Important note: this series of boilers can be hoisted as a whole, convenient for mobile transportation, and suitable for oilfield heating and other field operations.
* Steam volume: 0.5t/h-20t/h (hot water: 0.35mw-14mw)
* Steam pressure: 0.4MPa ~ 2.5MPa (optional as required)
* Fuel: oil field, field equipment heating. Construction site heating, outdoor heating and other special needs.
FEATURES AT A GLANCE
1. Large-diameter, save fuel and reduce costs
2. High-safety&intelligent automatic operation
3. Limit water level sensor safety device
4. Short installation time&small space occupation
5. Reasonable structure, easy maintenance
WNS Oil Gas Steam Boiler
CWNS Oil Gas Fired Hot Water Boiler
PRODUCT SPECIFICATIONS
WNS Series Steam Boiler Main Technical Parameters | ||||||||||||||||
Rated steam | Rated steam | Steam temperature(℃) | Thermal efficiency | Oil | Gas | Dimension | Weight | |||||||||
capacity (t/h) | pressure (Mpa) | (%) | (kg/h) | (Nm³/h) | (m) | (t) | ||||||||||
WNS1-0.7/1.0-Y(Q) | 1 | 0.7/1.0 | 194 | ≥98.36 | 61 | 73 | 3.2×1.9×2.2 | 4.9 | ||||||||
WNS2-1.0/1.25-Y(Q) | 2 | 1.0/1.25 | 194 | ≥98.36 | 121 | 145 | 4.2×2.3×2.5 | 8 | ||||||||
WNS3-1.0/1.25-Y(Q) | 3 | 1.0/1.25 | 194 | ≥98.36 | 182 | 217 | 4.5×2.1×2.4 | 9 | ||||||||
WNS4-1.0/1.25-Y(Q) | 4 | 1.0/1.25 | 194 | ≥98.36 | 243 | 289 | 5.0×2.3×2.6 | 11 | ||||||||
WNS6-1.25/1.6-Y(Q) | 6 | 1.25/1.6 | 194 | ≥98.36 | 367 | 435 | 5.4×2.4×2.7 | 18.6 | ||||||||
WNS10-1.25/1.6-Y(Q) | 10 | 1.25/1.6 | 194 | ≥98.36 | 601 | 735 | 6.3×2.7×3.2 | 20.5 | ||||||||
WNS15-1.25/1.6-Y(Q) | 15 | 1.25/1.6 | 194 | ≥98.36 | 906 | 1101 | 8.9×3.4×3.6 | 42 | ||||||||
WNS20-1.25/1.6-Y(Q) | 20 | 1.25/1.6 | 194 | ≥98.36 | 1211 | 1467 | 7.8×3.6×4.0 | 52 | ||||||||
CWNS Series Main Technical Parameters of Hot Water Boiler | ||||||||||||||||
Project | Model | CWNS0.35 | CWNS0.7 | CWNS1.05 | CWNS1.4 | CWNS2.1 | CWNS2.8 | |||||||||
Size | M | 2.9*1.5*1.7 | 2.7*1.6*1.9 | 3.2*1.6*1.9 | 3.4*2.2*2.4 | 3.4*2.2*2.6 | 4.3*2.3*2.6 | |||||||||
Weight | T | 2.5 | 3.75 | 5.6 | 7.7 | 8.9 | 10.1 | |||||||||
Power | MW | 0.35 | 0.7 | 1.05 | 1.4 | 2.1 | 2.8 | |||||||||
Pressure | Mpa | 0 | ||||||||||||||
Outlet Water Temperature | ℃ | 85 | 85 | 85 | 85 | 85 | 85 | |||||||||
Return Water Temperature | ℃ | 60 | 60 | 60 | 60 | 60 | 60 | |||||||||
Boiler Efficiency | / | ≥96％ | ||||||||||||||
Applicable Fuel | / | Natural Gas, liquefied Natural Gas, City gas, Light Oil | ||||||||||||||
Natural Gas | NM³/h | 37 | 73 | 109 | 145 | 212 | 286 | |||||||||
Liquefied Petroleum Gas | Kg/h | 29 | 57 | 85 | 115 | 172 | 229 | |||||||||
City Gas | NM³/h | 79 | 155 | 232 | 302 | 463 | 601 | |||||||||
Light Oil | Kg/h | 31 | 61 | 92 | 118 | 185 | 235 | |||||||||
Gas supply pressure | Natural Gas | Mbar | 70-100 | 100-150 | 100-150 | 100-150 | 150-200 | 150-200 | ||||||||
City Gas | Mbar | 100-200 | 100-200 | 100-200 | 100-200 | 150-200 | 150-200 | |||||||||
Rated Water Circulation | M³/h | 12 | 24 | 36 | 48 | 72 | 96 | |||||||||
Boiler Water Volume | M³ | 1.1 | 3.05 | 5.2 | 5.9 | 13.1 | 15.8 | |||||||||
SIMILAR PRODUCTS
Company Profile
Henan Yuji Boiler Vessel Co., Ltd. is the general administration of quality supervision, inspection and quarantine of the People’s Republic of China approved the boiler and pressure vessel designated manufacturing enterprise, The company passes ISO 9001 international quality system certification, and gains the EU CE and other international certification ect.
We ensure the quality of our products with our life. Quality assurance systems are set, include the design production, technology management, material experiment, welding control, inspection and audit, measurement and production management. The technology center has enterprise cooperation relationship with Many famous universities in China, leading the industry with innovation and new technology, and building a strong research and development system.
We ensure the quality of our products with our life. Quality assurance systems are set, include the design production, technology management, material experiment, welding control, inspection and audit, measurement and production management. The technology center has enterprise cooperation relationship with Many famous universities in China, leading the industry with innovation and new technology, and building a strong research and development system.
FAQ
Q. Are you manufacturer?
A: Yes, we are professional manufacturer of boiler and pressure vessels in Henan, China.
Q: Do you have any Certificate?
A: Yes. Our boiler have got China GB ISO certificates and CE certificate of EU. We also can provide ASME, GHOST and other necessary certificates if you need.
Q: How can I pay you?
A: T/T, Western Union, Money Gram and Ali Trade Assurance is better.
Q: What about the delivery time?
A: 5-10 working days for single machine, and 30-40 working days for bulk order and door to door delivery service is also
available.
Q. What about the warranty?
A: We provide 1 year warranty for free and life-long time maintenance
Q. What about installation?
A: We provide 1 or 2 technicians overseas services for installation, debugging and training.
Q. What about the boiler fuel?
A: We provide boiler can use coal, charcoal, wood, rice husk, straw, biomass pellet, diesel, light oil, natural gas, city gas,
liquefied gas etc.
A: Yes, we are professional manufacturer of boiler and pressure vessels in Henan, China.
Q: Do you have any Certificate?
A: Yes. Our boiler have got China GB ISO certificates and CE certificate of EU. We also can provide ASME, GHOST and other necessary certificates if you need.
Q: How can I pay you?
A: T/T, Western Union, Money Gram and Ali Trade Assurance is better.
Q: What about the delivery time?
A: 5-10 working days for single machine, and 30-40 working days for bulk order and door to door delivery service is also
available.
Q. What about the warranty?
A: We provide 1 year warranty for free and life-long time maintenance
Q. What about installation?
A: We provide 1 or 2 technicians overseas services for installation, debugging and training.
Q. What about the boiler fuel?
A: We provide boiler can use coal, charcoal, wood, rice husk, straw, biomass pellet, diesel, light oil, natural gas, city gas,
liquefied gas etc.
