Инвертор солнечной энергии 500 Вт 1000 1500 2000 3000 модифицированный синусоидальный сигнал эффективность
Инвертор солнечной энергии 500 Вт 1000 1500 2000 3000 модифицированный синусоидальный сигнал эффективность
Инвертор солнечной энергии 500 Вт 1000 1500 2000 3000 модифицированный синусоидальный сигнал эффективность
Инвертор солнечной энергии 500 Вт 1000 1500 2000 3000 модифицированный синусоидальный сигнал эффективность
Инвертор солнечной энергии 500 Вт 1000 1500 2000 3000 модифицированный синусоидальный сигнал эффективность
Инвертор солнечной энергии 500 Вт 1000 1500 2000 3000 модифицированный синусоидальный сигнал эффективность
Инвертор солнечной энергии 500 Вт 1000 1500 2000 3000 модифицированный синусоидальный сигнал эффективность

Инвертор солнечной энергии 500 Вт 1000 1500 2000 3000 модифицированный синусоидальный сигнал эффективность


Поделиться:


Цена:2 953,63 ₽ - 3 828,77 ₽*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Aug-15-2025 3750.93 $* 3825.27 $*
Jul-15-2025 3042.54 $* 3103.39 $*
Jun-15-2025 3691.66 $* 3765.81 $*
May-15-2025 3662.65 $* 3735.15 $*
Apr-15-2025 2923.76 $* 2981.67 $*
Mar-15-2025 3603.98 $* 3675.30 $*
Feb-15-2025 3573.75 $* 3644.30 $*
Jan-15-2025 3544.40 $* 3615.1 $*

Характеристики








Features:


1:Real power 1000W rated power 2:1100W work 180 Sec,1200W work 10 Sec
3:High surge power up to 2000w
4:High efficiency up to 90%
5:With 11 protection function
6:Smart cooling fan intelligent adjustment
7:Standby saving mode 8:Power ON/OFF switch
9:Warranty 1 Years(replacement service)
10:80cm 10㎡ wire cable with 100A terminal




11 Protection Functions
Soft start /low voltage shut down / over current protection




Smart Cooling Fan




More Than 20 Years Experience Engineers Team






Accessories




Scene












Specification


MODEL
KS-1000-112
KS-1000-124
KS-1000-148
KS-1000-212
KS-1000-224
KS-1000-248









OUTPUT
RATED POWER
1000W
MAXIMUM OUTPUT POWER
1100W for 180 sec. / 1200W for 10 sec. / surge power 2000W for 2 sec
AC VOLTAGE
Factory Setting set at 110V AC
Factory Setting set at 110V AC
100/110/115/120VAC (Option)
220/230/240VAC Option
FREQUENCY
Factory Setting set at 60Hz (50/60Hz Option)
Factory Setting set at 50Hz (50/60Hz Option)
WAVE FORM
Modified sine wave
AC REGULATION
10%
STANDARD RECEPTACLES
Schuko/UK/Australia/Universal/USA/France/JP/Brazil
FRONT PANEL INDICATOR
Operation and Fault status





INPUT
BAT. VOLTAGE
12V
24V
48V
12V
24V
48V
VOLTAGE RANGE
10.5 - 15VDC
21-30VDC
42 〜60VDC
10.5 - 15VDC
21-30VDC
42 〜60VDC
DC CURRENT
100A
50A
25A
100A
50A
25A
FUSE
35A*4
20A*4
10A*4
35A*4
20A*4
10A*4
NO LOAD CURRENT DRAW
0.4A
0.2A
0.1A
0.4A
0.2A
0.1A
EFFICIENCY
87%
87%
90%
86%
87%
91%
BATTERY TYPES
Recommend use Open & sealed lead acid battery

BATTERY INPUT PROTECTION
BAT.LOW ALARM
10.5+/-0.5V
21+/-1V
42+/-2V
10.5+/-0.5V
21+/-1V
42+/-2
BAT.LOW SHUTDOWN
10+/-0.5V
20+/-1V
40+/-2V
10+/-0.5V
20+/-1V
40+/-2V
BAT.OVER SHUTDOWN
15+/-0.5V
30+/-1V
60+/-2V
15+/-0.5V
30+/-1V
60+/-2V
REVERSE POLARITY
Built in fuse


OUTPUT
OVER TEMPERATURE
75°C
OUTPUT SHORT CIRCUIT
Protection type : Shut down o/p voltage, re-power on to recover
OVER LOAD
120% Rated power / Protection type : Shut down o/p voltage, re-power on to recover within 10 times.


ENVIRONMENT
WORKING TEMP.
0 〜+40°C @100% Load; 60 °C @ 50% Load
WORKING HUMIDITY
20%-90% RH non-condensing
STORAGE TEMP
-30-+70 °C /-22~+158° F
STORAGE HUMIDITY
10-95% RH non-condensing


SAFETY
CE
Compliance to EN61000-3-2,3
LVD
Compliance to EN60950-1
ROHS
Compliance to EN1122B:2001-1



LED BUZZER
LOW BAT ALARM
Buzzer sound 2 times and Red light blink 2 times every 8 Sec
LOW BAT SHUT DOWN
Buzzer sound 3 times and Red light blink 3 times every 8 Sec
OVER BAT SHUT DOWN
Buzzer sound 4 times and Red light blink 4 times every 8 Sec
OVER TEMP
Buzzer sound 5 times and Red light blink 5 times every 8 Sec
OVER LOAD
Light Blink Constantly



OTHER
COOLING
Load and Temp control the Fan
CONTROL WIRING
RJ11
DIMENSION
210*150*70mm (L*W*H)
PACKING
11.5KG;6PCS/15.4KGS/CARTON
APPLICATION
Home and office appliances, Power Tools and Portable Equipment, Vehicle,Yacht and Solar System
NOTE
1 .Volue test by input voltage at 13V,26V,48V. 2 .All parameters are measured at rated load, 2 5 °C of ambient temperature. 3.The
specifications are subject to change w辻hout prior notice for further improvement of products


Highly Recognized Market:

*Germany Market
*France Market
*Netherland Market
*Colombia Market
*Peru Market
*Mexico Market
*Brazil Market
*Argentina Market
*Turkey Market


Factory








Exhibition








Ningbo Kosun New Energy Co., Ltd. is a new and high-tech enterprise specialized in the design, research and development,
manufacture and sales of Power inverters,Power inverter with charger, Solar controllers, etc.
We have strictly quality control system, there are 10 QC staff to in charge of the IQC, IPQC, FQC, OQC, and engineer working in
this line for 20 years, this can promise all the products will be in good condition from start to reach the customer,and your
technical problem can be solved in 24hours.

We always carry out the policy of "Creativity, Quality First, Credit, Surpass".


Recommend Type




FAQ
1. who are we?
We are based in Zhejiang, China, start from 2011,sell to
Europe(50.00%),America(20.00%),Oceania(15%),Asia(5.00%)Africa(5.00%),Domestic Market(5.00%). There are more than 120 staff in our
office.

2. how can we guarantee quality?
2 years warranty for pure sine wave products;1 Year warranty for modified sine wave products.
our 24 - hour after - sale service mechanism to ensure and expand the market of our customer
3.what can you buy from us?
Power inverters,Power inverter with charger, Solar controllers,smart charger.

4. why should you buy from us not from other suppliers?
*Sufficient power inverter supplier
*all the PCB lines and mould are original and self-existent from our 20 years certificated engineers team to ensure the
quality，and all your technical problem can be solved in 24hours.
*We use ERP software to manage the quality and trace after sale,each inverter has a unique number recorded each steps in producing
*Our branch company supported by the government in the new energy industry (6000m2 free plant), it makes save cost
*Warranty 2 years and we support replacement for free,Our 24 - hour after - sale service mechanism to ensure and expand the market
of our customer

5. what services can we provide?
Provide free consultation
Provide OEM ODM service
Reliable product performance
Professional shipping service
Secure after-sales service
