Deye SUN-12K-SG04LP3-EU Гибридные солнечные инверторы 12 кВт 10 8 6 3 фазы
- Категория: Solar Energy Products >>>
- Поставщик: Lovsun,Tek,Co.Ltd
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-20-2025 | 215340.5 $* | 219647.80 $* |
| Jul-20-2025 | 174646.83 $* | 178139.49 $* |
| Jun-20-2025 | 211949.15 $* | 216188.78 $* |
| May-20-2025 | 210253.50 $* | 214458.95 $* |
| Apr-20-2025 | 167863.80 $* | 171220.25 $* |
| Mar-20-2025 | 206862.31 $* | 210999.67 $* |
| Feb-20-2025 | 205166.41 $* | 209269.98 $* |
| Jan-20-2025 | 203471.17 $* | 207540.1 $* |
Характеристики
Recommend Product
Product Description
Specification
Model | Sun-8K-SG04LP3 | SUN-10K-SG04LP3 | SUN-12K-SG04LP3 | |||
Battery Input Data | ||||||
Battery Type | Lead-acid or Li-Ion | |||||
Battery Voltage Range (V) | 40-60V | |||||
Max. Charging Current (A) | 190A | 210A | 240A | |||
Max. Discharging Current (A) | 190A | 210A | 240A | |||
Charging Curve | 3 Stages / Equalization | |||||
External Temperature Sensor | Optional | |||||
Charging Strategy for Li-Ion Battery | Self-adaption to BMS | |||||
PV String Input Data | ||||||
Max. DC Input Power (W) | 10400W | 13000W | 15600W | |||
PV Input Voltage (V) | 550V(150V~800V) | |||||
MPPT Range (V) | 200V-650V | |||||
Start-up Voltage (V) | 160 V | |||||
PV Input Current (A) | 13A+13A | 26A+13A | 26A+13A | |||
No.of MPPT Trackers | 2 | |||||
No.of Strings Per MPPT Tracker | 1+1 | 2+1 | 2+1 | |||
AC Output Data | ||||||
Rated AC Output and UPS Power (W) | 8000W | 10000W | 12000W | |||
Max. AC Output Power (W) | 8800W | 11000W | 13200W | |||
Peak Power (off grid) | 2 times of rated power, 10 S | |||||
AC Output Rated Current (A) | 12A | 15A | 18A | |||
Max. AC Current (A) | 18A | 23A | 27A | |||
Max. Continuous AC Passthrough (A) | 50A | |||||
Output Frequency and Voltage | 50/60HZ； 230/400Vac (Three phase) | |||||
Grid Type | Three Phase | |||||
Current Harmonic Distortion | THD<3% (Linear load<1.5%) | |||||
Efficiency | ||||||
Max. Efficiency | 97.60% | |||||
Euro Efficiency | 97.00% | |||||
MPPT Efficiency | 99.90% | |||||
Certifications and Standards | ||||||
Grid Regulation | IEC61727, IEC62116, IEC60068, IEC61683, NRS 097-2-1 | |||||
Safety EMC / Standard | IEC62109-1/-2, IEC61000-6-1, IEC61000-6-3, IEC61000-3-11,1EC61000-3-12 | |||||
Weight (kg) | 36.8 | |||||
Size (mm) | 422Wx658Hx281D | |||||
Protection Degree | IP65 | |||||
Warranty | 5 years | |||||
