Высокоскоростная оцинкованная стальная листовая металлическая напольная машина для
- Категория: Building Material Machinery >>>
- Поставщик: Sussman,Modular,House,(wuxi),Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 61285.80 $* | 64349.89 $* |
| Aug-19-2025 | 60770.69 $* | 63809.32 $* |
| Jul-19-2025 | 50985.80 $* | 53534.25 $* |
| Jun-19-2025 | 59740.54 $* | 62727.37 $* |
| May-19-2025 | 52015.38 $* | 54616.56 $* |
| Apr-19-2025 | 58710.78 $* | 61646.25 $* |
| Mar-19-2025 | 58195.20 $* | 61105.55 $* |
| Feb-19-2025 | 57680.6 $* | 60564.65 $* |
| Jan-19-2025 | 57165.70 $* | 60023.42 $* |
Характеристики
Item NO | Description | Unit\\Type | RF-DF |
1 | Steel Thickness | mm | 0.75mm-1.5mm |
2 | Forming Speed | m/min | 0-20 |
3 | Roller stands | stand | 28-30 |
4 | Roller Material | high-grade 45# steel | |
5 | Shaft diameter | Ф90 | |
6 | Main Motor Power | Kw | 18.5kw |
7 | Hydraulic cutting Power | Kw | 7.5 |
8 | Hydraulic pressure | Mpa | 12 |
9 | Power Supply | 380V, 50HZ,3 phase | |
10 | Tolerance | mm | 1.5 |
11 | Material of cutting | Cr12mov | |
12 | Control system | PLC with touch screen | |
13 | DRIVE system | Chain | 1.6 inches |
No | Name | quantity |
1 | 10 tons hydraulic de-coiler with coil car | 1 set |
2 | Main roll forming machine with embossing | 1 set |
3 | Control box | 1 unit |
4 | Hydraulic station | 1 unit |
5 | Hydraulic cutting device | 1 unit |
6 | Passive Out tables | 2 units |
Working Flow:
Uncoiling—Feeding&Leveling ---Roll forming—Cutting—Products collecting
