Термопластичный лист ПВХ ПЭТ Вакуумная формовка машины для производства пластиковых лотков/Термоформовочная
- Категория: Plastic Vacuum Forming Machines >>>
- Поставщик: Shenyang,Jiahua,De-Long,Science,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 2368.36 $* | 2486.37 $* |
| Aug-19-2025 | 2348.58 $* | 2465.46 $* |
| Jul-19-2025 | 1970.92 $* | 2069.3 $* |
| Jun-19-2025 | 2308.5 $* | 2423.9 $* |
| May-19-2025 | 2010.44 $* | 2111.88 $* |
| Apr-19-2025 | 2269.34 $* | 2382.34 $* |
| Mar-19-2025 | 2249.21 $* | 2361.91 $* |
| Feb-19-2025 | 2229.83 $* | 2340.38 $* |
| Jan-19-2025 | 2209.61 $* | 2319.34 $* |
Характеристики
Product Description
Specification
Model | KAWALONG 1224 |
Working area(mm)(L*W) | 1200*2400 |
Forming area(mm)(L*W) | 1040*2240 |
Function | Suction & Blow |
Max. suction forming depth(mm) | 300 |
Oven open style | Automatic open |
Heating area | 1 |
Suction holes | 1 |
Vacuum pump output | 63m³/h |
Total power(kw) | 20.5 |
Working Voltage | AC380V/50HZ/3P |
Net Weight (kgs) | 950 |
Overall size (mm) (L*W*H) | 2870*1550*1650 |
Machine Feature
Fearture
1)For flashing signs with relievo surface!
Good cost effective.Ineasy and fast operation! The new comer in acrylic moulding field of Vaccum-Thermoform,with multi-functions
in moulding process,may shap acrylic and heat meltable materials into the shapes of 3-D relief in just 8 minutes.
2) in small locating area: Not more than 4 sqm for the largest model 1325.
3) With light weightness: Less than 0.5 ton for the largest model 1325.
4) Low power consumption: 0.9kwh-2.5kwh for each turn of forming opertation.
5) Simpe operation with reasonable design: Easy and convenient operation, few waste or faults of materials.
6) High shaping speed: To heat and soft the acrylic materials by light-engergy, it only needs 6-8 minutes for froming up the
signs, from put the material into it till the surface has been shaped.
7) Wide scope of application: No limits to the thickness of arcylic material, and no influence to the environmental temperature,
even cold climate does not affect the production.
8)Manpower saving: One person can process the operation from the begin to finish.
9) In easy mold making: May make shaping mold without engraving machine. It can shape acrylic sheet into surfaces such as flat,
ball-like, curved, and relievo freely by just a single manual carved mold of flat surface with hardwood or high-density plate.
10) With fine sense of 3-dimensional characteristics for the curved surface: Flashing signs formed by the machine not only have
strong stereoscopic sense under day light, but also have well raising lighting uniformity in the night.
11) Good market and good benefit: The cost of signs with curved relievo surface produced by the machine, is obviously lower than
signs produced by other analogous vacuum forming machine, but in higter selling price.
12) Good quality and wasy maintenance: Especially manufacture in export standard for oversea customers, the export models of 1313
and 1325 mormally undertake varied strict performance tests before sale, also with shake-proof packing for transportation.
13)The Acrylic Moulding Machine For 3-D Reliefing, we normally call it Acrylic Shaping Machine, It is a new comer of
three-dimensional raising machine in Vacuum-Thermoform industry, it has the functions of both melting and moulding the materials
once during the process of signs. And the shaping speed is 2-3 times faster than normal arcylic process, further more it can save
over 30% of electric energy. It can shape up signs with special beautiful relief of 3-10cm on the surface, and has a strong three
dimension in the raising shape. The moulding cost is lower than tranditional blister moulding machines, and this equipment is
cheaper, the speed is faster, the investing cost is lower, the application range is larger, the benefit is higher, etc..
All these advantages will make it a wider market in the future.
1)For flashing signs with relievo surface!
Good cost effective.Ineasy and fast operation! The new comer in acrylic moulding field of Vaccum-Thermoform,with multi-functions
in moulding process,may shap acrylic and heat meltable materials into the shapes of 3-D relief in just 8 minutes.
2) in small locating area: Not more than 4 sqm for the largest model 1325.
3) With light weightness: Less than 0.5 ton for the largest model 1325.
4) Low power consumption: 0.9kwh-2.5kwh for each turn of forming opertation.
5) Simpe operation with reasonable design: Easy and convenient operation, few waste or faults of materials.
6) High shaping speed: To heat and soft the acrylic materials by light-engergy, it only needs 6-8 minutes for froming up the
signs, from put the material into it till the surface has been shaped.
7) Wide scope of application: No limits to the thickness of arcylic material, and no influence to the environmental temperature,
even cold climate does not affect the production.
8)Manpower saving: One person can process the operation from the begin to finish.
9) In easy mold making: May make shaping mold without engraving machine. It can shape acrylic sheet into surfaces such as flat,
ball-like, curved, and relievo freely by just a single manual carved mold of flat surface with hardwood or high-density plate.
10) With fine sense of 3-dimensional characteristics for the curved surface: Flashing signs formed by the machine not only have
strong stereoscopic sense under day light, but also have well raising lighting uniformity in the night.
11) Good market and good benefit: The cost of signs with curved relievo surface produced by the machine, is obviously lower than
signs produced by other analogous vacuum forming machine, but in higter selling price.
12) Good quality and wasy maintenance: Especially manufacture in export standard for oversea customers, the export models of 1313
and 1325 mormally undertake varied strict performance tests before sale, also with shake-proof packing for transportation.
13)The Acrylic Moulding Machine For 3-D Reliefing, we normally call it Acrylic Shaping Machine, It is a new comer of
three-dimensional raising machine in Vacuum-Thermoform industry, it has the functions of both melting and moulding the materials
once during the process of signs. And the shaping speed is 2-3 times faster than normal arcylic process, further more it can save
over 30% of electric energy. It can shape up signs with special beautiful relief of 3-10cm on the surface, and has a strong three
dimension in the raising shape. The moulding cost is lower than tranditional blister moulding machines, and this equipment is
cheaper, the speed is faster, the investing cost is lower, the application range is larger, the benefit is higher, etc..
All these advantages will make it a wider market in the future.
Sample
Company Profile
Shenyang Jiahua De-long Science *Technology Development Co.,Ltd is located in Shenyang in Liaoning Province ,is one of the biggest leading company for sign equipment & media in China.Our company is is a professional CNC router manufacturer, focusing on producing high quality machines and providing the best service. We specialize in manufacturing CNC routers, laser engraving/cutting machines, plasma cutting machines and cutting plotters. Our products are widely used in various industries such as arts and crafts processing, advertising, clothing, leather processing, model- and printed-hectograph making, woodworking and stone working.Since 2001, Jiahua has begun targeting the foreign market. Now our product has been sold to Europe, USA, South America, North America, and Africa, totally more than 50 countries.. We pay much more attention on the quality than price, we believe quality is the base of survival and growth.We welcome all the customers all around the world to make great business and share the success together
