Высококачественный и недорогой алюминиевый электролитический конденсатор 10 мкФ 200 в 20000 180 400 В для аккумуляторов 470
- Категория: Passive Components >>>
- Поставщик: Dongguan,Zhixu,Electronic,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 0.26 $* | 0.41 $* |
| Aug-20-2025 | 0.65 $* | 0.7 $* |
| Jul-20-2025 | 0.63 $* | 0.71 $* |
| Jun-20-2025 | 0.77 $* | 0.55 $* |
| May-20-2025 | 0.4 $* | 0.89 $* |
| Apr-20-2025 | 0.63 $* | 0.17 $* |
| Mar-20-2025 | 0.9 $* | 0.29 $* |
| Feb-20-2025 | 0.31 $* | 0.91 $* |
| Jan-20-2025 | 0.69 $* | 0.97 $* |
Характеристики
Product parameters
| Item | Performance Characteristics | ||||||||||||||||||||||||||||||||
| Operating Temperature Range | -40~+105C | -25~+105C | |||||||||||||||||||||||||||||||
| Rate Voltage Range | 10~100VDC | 160~450VDC | |||||||||||||||||||||||||||||||
| Capacitance Range | 330~68000μF | 33~22000μF | |||||||||||||||||||||||||||||||
| Capacitance Tolerance | ±20% ( 120Hz ,+20C) | ||||||||||||||||||||||||||||||||
| Leakage current (+20C,max. ) | 1 ≤0.02CVAfter 5 minutes with rated working voltage applied. | ||||||||||||||||||||||||||||||||
| Dissipation factor (tgδ) | Less than the value under table (%) | ||||||||||||||||||||||||||||||||
| Uf\\VDC | 10-16 | 25-35 | 50-63 | 80-100 | 160-250 | 315-450 | |||||||||||||||||||||||||||
| 47~390 | - | - | - | 15 | 15 | 20 | |||||||||||||||||||||||||||
| 470~3900 | 25 | 20 | 20 | 20 | 15 | 20 | |||||||||||||||||||||||||||
| 4700~8200 | 35 | 30 | 30 | 25 | - | - | |||||||||||||||||||||||||||
| 10000~22000 | 40 | 35 | 30 | - | - | - | |||||||||||||||||||||||||||
| 27000~47000 | 45 | 40 | 35 | - | - | - | |||||||||||||||||||||||||||
| 56000~68000 | 50 | 45 | - | - | - | - | |||||||||||||||||||||||||||
| Low Temperature Characteristics (120Hz) | Impedance ratio max. | ||||||||||||||||||||||||||||||||
| Rated voltage (V) | 10 | 16 | 25 | 35 | 50 | 63 | 100 | 160 | 200-250 | 400-450 | |||||||||||||||||||||||
| Z-25C/ Z+20C | 5 | 5 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |||||||||||||||||||||||
| Z-40C/ Z+20C | 15 | 15 | 15 | 12 | 12 | 12 | 12 | - | - | - | |||||||||||||||||||||||
| Load Life | Test conditions Duration time Ambient temperature Applied voltage | : 2000Hrs : +105C : Rated DC | working voltage | ||||||||||||||||||||||||||||||
| After test requirement at +20C | |||||||||||||||||||||||||||||||||
| Capacitance change Dissipation factor Leakage current | : ≤±20% of the initial measured value : ≤200% of the initial specified value : ≤The initial specified value | ||||||||||||||||||||||||||||||||
| Shelf Life | Test conditions Duration time : 1000Hrs Ambient temperature : +105C Applied voltage : None After test requirement at +20C : The same limits as Load life Pre-treatment for measurements shall be conducted after application of DC working voltage for 30 minutes | ||||||||||||||||||||||||||||||||
Application scenario
Structure Image
Certifications
About us
Exhibition
Buyers praise
FAQ
Q: How about your after-sale service?
1. 365 day warranty
2. 20 days refund without reason
3. If the customer has any questions, we will provide technicalsupport timely.
Q: What are the advantages of your products?
1. We have all models of material, save you time looking fort And recommend materials for you if you need.
2. With the same quality products, we can give you best priceInquiries to after-sale, we will provide good service, such asupdate product status, technical support etc (24 hour online)
3. We have many stocks, and the delivery time usually is short.
Q: What is your MOQ?
A: No MOQ. we accept small orders. Because we believe thatsmall orders may become big orders in the future.
Q: If I place an order, how long will it take to deliver?
A: It usually takes about only 7-14 days after receiving thepayment, depends on the quantity ordered and the stock status.
