Емкостный сенсорный монитор с открытой рамой 15 17 18 5 19 21 23 6 27 32 дюйма
- Категория: Touch Screen Monitors >>>
- Поставщик: Shenzhen,Mio-Lcd,Technology,Co.,Limited
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-15-2025 | 298.24 $* | 304.82 $* |
| Jul-15-2025 | 242.41 $* | 247.48 $* |
| Jun-15-2025 | 294.19 $* | 300.36 $* |
| May-15-2025 | 291.64 $* | 297.23 $* |
| Apr-15-2025 | 233.63 $* | 238.94 $* |
| Mar-15-2025 | 287.50 $* | 293.59 $* |
| Feb-15-2025 | 284.5 $* | 290.9 $* |
| Jan-15-2025 | 282.12 $* | 288.71 $* |
Характеристики
Product Description
Specification | ||
General | ||
Series | Water-proof and Open frame | |
LCD Type | 27” TFT-LCD | |
Video Input | VGA and DVI , H-DMI - optional | |
OSD controls | Allow on-screen adjustments of Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
Power Supply | Type: External brick | |
Input (line) voltage: 100-240 VAC, 50-60 Hz | ||
Output voltage/current: 12 volts at 4 amps max | ||
Mount Interface | 1)VESA 75mm and 100mm | |
2)Mount bracket, horizontal or vertical | ||
LCD Specification | ||
Resolution | 1920x1080@75Hz | |
Dot Pitch(mm) | 0.297×0.297 | |
Nominal Input Voltage VDD | +3.3V(Typ) | |
Viewing angle (v/h) | 80°/80° | |
Contrast | 1000:1 | |
Luminance(cd/m2) | 350, 1000cd/m2 - optional | |
Response Time(Rising/Falling) | 5ms/6ms | |
Support Color | 16.2M | |
Backlight MTBF(hr) | 50000 | |
Touchscreen Specification | ||
Type | Projected Capacitive touch screen | |
Resolution | 10points touch | |
Touch Life Cycle | 10 millions | |
Touch Response time | 5ms | |
Touch System Interface | USB interface | |
Power consumption | +5V@80mA | |
External AC Power Adapter | ||
Output | DC 12V /4A | |
Input | 100-240 VAC, 50-60 Hz | |
MTBF | 50000 hr at 25°C | |
Environment | ||
Operating Temp. | -10～70°C | |
Storage Temp. | -20～80°C | |
Operating RH: | 20%～80% | |
Storage RH: | 10%～90% | |
Components | ||
USB Cable 180cm*1 Pcs, | ||
VGA Cable 180cm*1 Pcs, | ||
Power Cord with Switching Adapter *1 Pcs, | ||
Bracket* 8Pcs | ||
Quality: We have a strict quality control system. All products ordered from our factory are inspected by a professional quality control team.
Open Frame 15 17 18.5 19 21.5 23.6 27 32 Inch Capacitive Touch Screen Monitor Industrial Open Frame Lcd Monitor
MOQ: We accept small orders and mixed orders. According to our customers' requirements, as a dynamic team, we want to connect with all our customers.
Experience: As a dynamic team, through our more than 10 years of experience in this market, we are still continuing to research and learn more knowledge from customers, hoping that we can become the largest and professional supplier in China in this market Business one.
OEM: Accept ODM/OEM.
Samples: We provide of this product from our source.
Production time: within 7 working days after confirming the order.
After-sales service: We provide after-sales service team, all problems and questions will be resolved by our after-sales service team.
MOQ: We accept small orders and mixed orders. According to our customers' requirements, as a dynamic team, we want to connect with all our customers.
Experience: As a dynamic team, through our more than 10 years of experience in this market, we are still continuing to research and learn more knowledge from customers, hoping that we can become the largest and professional supplier in China in this market Business one.
OEM: Accept ODM/OEM.
Samples: We provide of this product from our source.
Production time: within 7 working days after confirming the order.
Product Usage
Customer reviews
Recommend Products
Company Introduction
Shenzhen MIO-LCD Technology Co., Ltd was established in 2010 and factory located in Shenzhen. Our company covers an area of 10000 square meters, which has more than 300 employees and abundant financial resources. We have excellent OEM & ODM teams who focus on LCD Monitors, Touch Screen Monitors, CCTV Monitors, Open Frame Monitors, Android AIO PCs, Windows AIO PCs. Follow the quality control process to produce the qualified products according to the product requirements and sent them to customer on time.
Daily output : 5,000 pcs,
Anual production capacity :1,500,000 pcs.
In order to supply the satisfactory products and services, we have built a modern quality management system which is in strict accordance with international standards. Besides, because of large overseas markets, most of our products have got ISO9001 & ISO45001 & OHSA18001 & IECQQC080000 quality management system certifications. Our products which have passed CCC, FCC, CE, ROHS,CB , KC, BIS and other certifications. If you have any new ideas or concepts for the products, please contact us. We are glad to work together with you and finally bring you the satisfied products.
Certifications
Payment & Logistics
FAQ
Ⅰ. What’s your warranty policy?
1. “7 days” policy: the product from the day that received by customer within 7 days, for factory failure the consumers can choose to return, exchange or repair.2. “15 days” policy: the product since the day sold within 15 days, the occurrence of factory failure the consumers can choose to replace or repair.
3. “2 years” policy: within 2 years warranty period, for non-man-made damages we will provide repair solutions and necessary parts to solve the problem.
4. “Perpetual” policy: after the 2-year warranty period, for damages we will analyze the cause and provide solutions. We can also help the customer to purchase spare parts for repair.
Ⅱ. What’s your MOQ?
1-2 samples for test is available, small qty by EXW and bulk order by FOB Shenzhen.
*Some special products MOQ is 500 units, for more information please consult the sales specialist.
MOQ for print branding logo, boot logo, custom box and user manual etc please consult the sales specialist.
Ⅲ. What’s your lead time?
Samples: 5-7 working days.
50-100 units: 10-12 working days.
300-500 units: 16-18 working days.
More than 1k units is 22-25 working days.
*The simpler function of the product, the faster lead time, for specific lead time please consult the sales specialist.
Ⅳ. What’s your OEM & ODM services?
OEM: we can provide services of print branding logo, boot logo, custom box and user manual etc.
ODM: we can accept the entrustment from the purchaser to provide from research and development, design, production, post-maintenance of all services
Ⅴ. What’s your payment mothod?
Samples: Paypal, Credit card, Western Union and T/T.
Bulk order: T/T (30% in advance + 70% balance before shipment), L/C at sight.
For special VIP customers can support DA, DP and OA.
