Кварцевая высокотемпературная прозрачная кварцевая трубка
US $5.00-$8.00
Производитель предоставляет прямую капиллярную кварцевую трубку боросиликатную
- Категория: Quartz Tubes >>>
- Поставщик: Lianyungang,Shengfan,Quartz,Products,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-19-2025 | 4.24 $* | 4.5 $* |
| Jul-19-2025 | 3.43 $* | 3.48 $* |
| Jun-19-2025 | 4.88 $* | 4.67 $* |
| May-19-2025 | 4.55 $* | 4.29 $* |
| Apr-19-2025 | 3.27 $* | 3.81 $* |
| Mar-19-2025 | 4.81 $* | 4.22 $* |
| Feb-19-2025 | 4.18 $* | 4.19 $* |
| Jan-19-2025 | 4.71 $* | 4.41 $* |
Характеристики
Products Description
Features of quartz tube/quartz glass tube:
1.High purity: 99.99%-99.999% SiO2.
2.Strong Hardness: Moh's hardness 5.3-6.5.
3.High temperature resistance: can work under 1200°C continuously,
4. Acid and Alkali resistance:except hydrofluoric acid, quartz glass does not react with any acid and base. Its stability is 30
times of the ceramic, and 150 times of stainless steel
4. Electric insulation: 10000 times of usual glass.
5. High light transmittance: 85%-95%, depends on different spectrum.
6.Excellent thermal shock stability: Small thermal expansion coefficient, 5.5×10-7/℃.
2.Strong Hardness: Moh's hardness 5.3-6.5.
3.High temperature resistance: can work under 1200°C continuously,
4. Acid and Alkali resistance:except hydrofluoric acid, quartz glass does not react with any acid and base. Its stability is 30
times of the ceramic, and 150 times of stainless steel
4. Electric insulation: 10000 times of usual glass.
5. High light transmittance: 85%-95%, depends on different spectrum.
6.Excellent thermal shock stability: Small thermal expansion coefficient, 5.5×10-7/℃.
Compressive strength | >1100Mpa | Coefficient of thermal expansion | 5.5x10-7cm/cm. ℃ |
Bending Strength | 67Mpa | Melting temperature | 1750~1800℃ |
Tensile Strength | 48.3Mpa | The temperature for a short time | 1500℃ |
Poisson's Ratio | 0.14~0.17 | The temperature for a long time | 1200°℃ to 1300 ℃ |
Elastic Modulus | 71700Mpa | Resistivity | 7x107.2.cm |
Shearing Modulus | 31000Mpa | Dielectric Strength | 250~400Kvicm |
Moh's Hardness | 5.3~6.5(Moh's Scale) | Dielectric Constant | 3.7~3.9 |
Deformation Point | 1650℃ | Dielectric absorption coefficient | <4x104 |
Specific Heat(20~350°℃) | 670J/kg℃ | Dielectric loss coefficient | <1x104 |
Thermai Conductivity | 1.4W/m℃ | Property of quartz tube |
Details Images
production flow
packing and shipping
product uses
Company Introduction
Lianyungang Shengfan Quartz Products Co., Ltd.
Lianyungang Shengfan Quartz Product Factory is a professional manufacture specialized in research and development of quartz
plate,quartz tube,quartz flange,quartz ring,cuvette and quartz instrument. The company is located in China Crystal Capital -
Donghai City, Jiangsu Prov., China. 70 km far from Lianyungang port, convenient transportation. Covering an area of 1000 square
meters,we now have over 30 employees,an annual sales figure exceeding USD 5.2 million. With the philosophy of Technology
Orientation, Quality First,Integrity and Responsibility,Sustainable Operation, the company dedicates to establish an international
enterprise with standard and sustainable operation capability.
plate,quartz tube,quartz flange,quartz ring,cuvette and quartz instrument. The company is located in China Crystal Capital -
Donghai City, Jiangsu Prov., China. 70 km far from Lianyungang port, convenient transportation. Covering an area of 1000 square
meters,we now have over 30 employees,an annual sales figure exceeding USD 5.2 million. With the philosophy of Technology
Orientation, Quality First,Integrity and Responsibility,Sustainable Operation, the company dedicates to establish an international
enterprise with standard and sustainable operation capability.
FAQ
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the delivery time?
A:Within 15 days after receiving deposit.
Q3. Do you have any MOQ limit?
A: Low MOQ, 1pc for sample checking is available
Q4. How to proceed an order in your factory?
A: Firstly let us know your requirements or application. Secondly We quote according to your
requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange
the production.
Q5. How do you ship the goods and how long does it take to arrive? DHL, UPS, FedEx or TNT are optional for small
order. It usually takes 3-5 days to arrive. Airline and sea shipping are also available.
Q2. What about the delivery time?
A:Within 15 days after receiving deposit.
Q3. Do you have any MOQ limit?
A: Low MOQ, 1pc for sample checking is available
Q4. How to proceed an order in your factory?
A: Firstly let us know your requirements or application. Secondly We quote according to your
requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange
the production.
Q5. How do you ship the goods and how long does it take to arrive? DHL, UPS, FedEx or TNT are optional for small
order. It usually takes 3-5 days to arrive. Airline and sea shipping are also available.
