EPS Low Price Recycling Granulator Machine For Plastic Pellet Making
The scientific name of foam is: Polystyrene, referred to EPS, it is a kind of light high molecular polymer. The polystyrene resin to be add a foaming agent, and at the same time to be heated then soften it to generate gas, forming a rigid closed-cell structure plastic foam, mainly used for building walls, roof insulation, composite board insulation; fish boxes, the preservation of agricultural and fishery products; the heat preservation of cold storage, air conditioners, vehicles, ships, floor heating,decoration , carving and etc. The usage is very widely.
Aceretech Recyclable Plastics Include:
* LLDPE/LDPE/HDPE/PE/EPE film, crushed material, lithium battery film, foamed pearl cotton
* PP/OPP/BOPP/CPP film, woven bag,non-woven fabric (melt blown)
* PA66 fishing net, silk, factory trim, carpet
* PET/BOPET bottle flakes, film, silk, waste cloth, foam,optical film
* PTT wire
* EPS/XPS crushed material, cold briquetting foam, hot melt foam, insulation board
* HIPS/PC/ABS home appliance housing, electronic waste, factory plastic
* PVB crushed material, flakes
* PU
* PA66 fishing net, silk, factory trim, carpet
* PET/BOPET bottle flakes, film, silk, waste cloth, foam,optical film
* PTT wire
* EPS/XPS crushed material, cold briquetting foam, hot melt foam, insulation board
* HIPS/PC/ABS home appliance housing, electronic waste, factory plastic
* PVB crushed material, flakes
* PU
Product Paramenters
SPECIFICATIONS | ||
Machine Model | EPS | |
Final Product Shape | Particles | |
System composition | Belt Conveyor, Air Exhausting Device, Sliding Gate, Cutting Compactor with Inverter, Single Screw Extruder, Filtration first, Vacuum Degassing, Pelletizer, Water Cooling Device, Dehydration Section, Conveyor Fan, Product Silo. | |
Output Range | 320kg/h-2100kg/h | |
Feeding Device | Belt Conveyor (Standard), Roll Hualing off device (Optional) | |
Compactor Volume | 300L-1600L | |
Diameter of screw | 100mm-180mm | |
Material of screw | Bimetal | |
L/D of screw | 36/ 1 | |
Heater of barrel | Ceramic heater or Far-infrared heater | |
Cooling of Barrel | Air cooling of fans through blowers | |
Vacuum deashing exhaust | Two Double-zone vacuum degassing system (Standard) | |
Pelletizing type | Water-ring pelletizing/ water-strands pelletizing/ Under-water pelletizing | |
Voltage Standard | According to the Voltage of the Customer's Location | |
Optioanl device | Metal detector, Roll hualing off device, Masterbatch and additives feeder | |
Warranty | 13 months from the date of bill of lading | |
Technical services | project design, factory construction, installation and recommendations, commissioning | |
Application
Recycling Process
Products Description
Equipment process principle
1. Foam pre-treatment equipment
The density of foam board is generally 10-45kg/m3. Since it is light, there are two problems. One problem is the transportation cost greatly increased. Another problem is the feeding efficiency be lower during pelletizing, the capacity cannot be achieved.
According to our rich experience, we need to pre-treat the foam in advance. There are two ways: one is to use a compress for cold pressing, the compression ratio is generally 1:50, another is to use a hot melt machine for hot melt treatment, to melt the foam and then cool it into a block, so as to achieve the change of bulk density.
1. Foam pre-treatment equipment
The density of foam board is generally 10-45kg/m3. Since it is light, there are two problems. One problem is the transportation cost greatly increased. Another problem is the feeding efficiency be lower during pelletizing, the capacity cannot be achieved.
According to our rich experience, we need to pre-treat the foam in advance. There are two ways: one is to use a compress for cold pressing, the compression ratio is generally 1:50, another is to use a hot melt machine for hot melt treatment, to melt the foam and then cool it into a block, so as to achieve the change of bulk density.
2. Pelletizing equipment
The blocks which be compressed or hot-melted, since the volume is large, when pelletizing, material need to be shreddered to make it be small piece. The size is generally less than 12mm.
The blocks which be compressed or hot-melted, since the volume is large, when pelletizing, material need to be shreddered to make it be small piece. The size is generally less than 12mm.
Shredder
The blocks which be compressed or hot-melted, since the volume is large, when pelletizing, material need to be shreddered to make it be small piece. The size is generally less than 12mm.
Belt
The foam after being shredded is conveyed into the compactor through a belt. The belt is equipped with a metal detection device to detect whether the foam contains metal.
Rotary Knives
After the material entering into the compactor, the motor will drive the rotary knives at the bottom of the compactor running. To cut the material be small piece , the friction heat makes the foam to be shrinked, then to feed material into the extruder under the centrifugal force of knife disc.
Dust&moisture Remove Device
The top of the compactor is equipped with exhaust holes and connected to the dust&moisture remove device. The moisture and dust generated during the cutting and compaction process of the foam in the compactor will be collected by this device.
Sliding Gate With Servo Motor
There is a sliding gate beside the compactor and to control the foam feeding volume.
Frequency Converter
For better operation and protection of the motor from compactor, we will be equipped with a frequency converter to control the speed of the compactor.
Single Screw Extruder
The L/D of the special design of single screw extruder from ACERETECH is generally 32~36/1. The screw with the function of melting, mixing, plasticizing, and venting. Our standard screw material is bi-metal, to ensure the wear resistance, corrosion resistance and service life of the screw. After that, material will be transported to the filtration system.
Gearbox
The high-torque gearbox adopts German integrated casting technology and liquid nitrogen assembly technology, to make sure that the equipment with the characteristics of high speed, low noise, and long service life.
Heating System
The heating system of the main engine adopts ceramic heating system for heating, the electric control system adopts imported solid state relays for controlling, and fans for cooling.
The heating system of the main engine adopts ceramic heating system for heating, the electric control system adopts imported solid state relays for controlling, and fans for cooling.
The vacuum degassing system adopts a double vacuum design, which can effectively separate small molecule volatiles and moisture in the melt. The special designed vacuum tank will collect dust and moisture to ensure the cleanliness of the recycling workshop and the emission of VOC.
Melt Filtration
According to the output and the cleanliness of the material, the filtration system is equipped with plate type or piston type.
The plate type is widely used in plastic recycling applications because of its short flow path and convenient filter replacement.
The piston type solves the problems of high output, particularly dirty materials, frequent screen changes and etc.
The plate type is widely used in plastic recycling applications because of its short flow path and convenient filter replacement.
The piston type solves the problems of high output, particularly dirty materials, frequent screen changes and etc.
Pelletizing
After the foam melt passes through the filtration system, we have different pelletizing methods to choose , such as water ring pelletizing system, with high automation, labor saving, small footprint, avoiding material waste and etc.
Vibration Dry And Packing System
Advanced dewatering vibration sieve combining with horizontal- type centrifugal dewatering present high-performance dried pellets and lower energy consumption.
Production Silo
The final materials will be sent to the silo through the air conveying system for collection.
