High Quality Vacuum Lumber Drying Kiln Vacuum Dryer Wood Vacuum Drying Kiln Equipment Price For Sale
Steam heating wood drying kilin uses the recycle steam as the heat source that keeps on decomposing evaporating water content rate and lipid of the materials or the inner part of the products that need drying treatment so that the target of cleaning, drying and figuration can be achieved. The structure of kin body. Aluminum alloy structure, brick building structure. The control system of drying kiln: Full automatic computer control.
Aluminum alloy structure configuration:
1.Aluminum alloy shell, stainless steel joint bolts.
2. Stainless steel tubes are used for internal pipelines for drying kiln.
3. Bimetal composite radiating pipes are used for radiator The base tubes are made of stainless steel.
4. High temperature and high humidity durable motors. Aluminum alloy casting impellers and frames are used for recycle fan.
5. Originally imported electric heating valves, spraying steam electromagnetism valves and dehumiditying motors.
6. Imported controlling instruments and the sensors.
2. Stainless steel tubes are used for internal pipelines for drying kiln.
3. Bimetal composite radiating pipes are used for radiator The base tubes are made of stainless steel.
4. High temperature and high humidity durable motors. Aluminum alloy casting impellers and frames are used for recycle fan.
5. Originally imported electric heating valves, spraying steam electromagnetism valves and dehumiditying motors.
6. Imported controlling instruments and the sensors.
Full automatic control system feature:
1.The whole drying process is automatic control with computer.
2.To realize automatic program control on heating, steam infection, dehumidifying, fan positive inversion.
3.It real-time display and alarm of the drying process, drying parameters and drying fault.
4.It prepares and stores 99 drying process benchmark program according to the thickness of the different species.
2.To realize automatic program control on heating, steam infection, dehumidifying, fan positive inversion.
3.It real-time display and alarm of the drying process, drying parameters and drying fault.
4.It prepares and stores 99 drying process benchmark program according to the thickness of the different species.
Semi-automatic control system feature
Semi-automatic control system feature:
1-The control system has complete functions
1-The control system has complete functions
2-To realize the heating, steam injection dehumidiliying, fan positive inversion in stage of automatic control
3-It reai-time display the drying process & drying parameter
4-It sets the drying benchmark by stages
Specification
Type | valume in theory m2 | The size of piling wood ( WxLxH)mm | The size of external kiln (WxLxH)mm | Motor quantity | Total power(kw) | Drying source | ||||||
Aluminum alloy structure | ||||||||||||
MYHG-60 | 30 | 4000x3600x4200 | 4400x5000x5500 | 2 | 6 | Steam | ||||||
MYHG-80 | 40 | 4000x4600x4200 | 4400x6200x5500 | 2 | 6 | |||||||
MYHG-100 | 50 | 6000x3800x4200 | 6400x5000x5500 | 3 | 9 | |||||||
MYHG-120 | 60 | 6000x4600x4200 | 6400x6200x5500 | 3 | 9 | |||||||
MYHG-160 | 80 | 8000x4600x4200 | 8400x6200x5500 | 4 | 12 | |||||||
NYHG-200 | 100 | 8000x6000x4200 | 8400x8000x5500 | 5 | 15 | |||||||
MYHG-240 | 120 | 10000x6000x4200 | 10500x8000x5500 | 6 | 18 | |||||||
MYHG-300 | 150 | 12000x6000x4200 | 12600x8000x5500 | 8 | 24 | |||||||
MYHG-400 | 200 | 12000x7000x4200 | 12600x9200x6100 | 10 | 30 | |||||||
Related Equipments
1.Features of Rotary Dryer Machine
1)The use of high-frequency heating solves the rapid heating and drying of wood.
2) the wood is heated inside and outside at the same time, the heating is uniform, the quality is good, and the natural color of the wood can be maintained.
3)The use of vacuum water absorption reduces the temperature of the wood drying process, makes the wood vaporize at a low temperature, and is not easy to crack and improves the dehydration speed of the wood.
2.Introduction Continuous carbonization furnace :
Carbonization furnace is use the material through the gasification furnace combustion, produce flue gas, after the flue gas
purification system concerns out of wood tar and other gas impurities, the flue gas into the carbonization machine for combustion, to a certain temperature, carbonization machine need to add Carbonized materials, through the pipeline transmission, the material in the carbonization machine combustion.
purification system concerns out of wood tar and other gas impurities, the flue gas into the carbonization machine for combustion, to a certain temperature, carbonization machine need to add Carbonized materials, through the pipeline transmission, the material in the carbonization machine combustion.
