Стандартное пневматическое скольжение API 7K для нефтяных

Стандартное пневматическое скольжение API 7K для нефтяных

Категория: >>>
Поставщик: Erui,International,Electronic,Commerce,Co.,Ltd

Цена:20 000,00 $ - 25 000,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-19-2025	23800.54 $*	24990.53 $*
Aug-19-2025	23600.33 $*	24780.67 $*
Jul-19-2025	19800.45 $*	20790.81 $*
Jun-19-2025	23200.93 $*	24360.68 $*
May-19-2025	20200.74 $*	21210.40 $*
Apr-19-2025	22800.10 $*	23940.47 $*
Mar-19-2025	22600.24 $*	23730.98 $*
Feb-19-2025	22400.77 $*	23520.55 $*
Jan-19-2025	22200.91 $*	23310.70 $*

Характеристики

Product Description

Safe and reliable: the use of one crane and one card to lift off the drill operation fundamentally avoids the occurrence of a single hoist ring accident in the operation of double elevators.
Simple operation: realizing the control in the driller's room, saving the time of starting and lowering the casing or casing string.
Strong applicability: different configurations can be used according to the scene;
Air blowing and mud removal function: the air blowing function can be added as needed to ensure the cleanliness of the wellhead during the drilling process;
Provide anti-torque: According to different models of hydraulic slip, the anti-torque can be provided is 20kN.m, 55kN.m, 75kN+m. The slipped kava can tighten the column, eliminating the need to use back pliers during the upper shackle process.

Technical Specifications:

Pneumatic slip technical parameters
Project	Specification model
Project	WQ 275 I	WQ 275 II	WQ 375 II	WQ 375 III
Applicable turntable (in)	27.1/2	27.1/2	37.1/2	37.1/2
Applicable pipe diameter (n)	2.3/8~ 9.7/8	2.3/8~ 9.7/8	2.3/8~14	2.3/8~14
Maximum working load (tons)	250	350	500	500
Maximum working load (kN)	2224	3114	4448	4448
Working pressure (MPa)	0.6~0.8

Project	Specifications
WQ275 I(The upper cover of the turntable is exposed )	WQ275 II	WQ375 IV	WQ375 V(Quick replacement for drilling)
Applicable turntable(in)	27 1/2	27 1/2	371/2	371/2
Suitable diameter(in)	2.3/8~9.7/8	2.3/8~7.5/8	2.3/8~14	2.3/8~7
Minimum working load(tons)	350	350	500	500
Maximum working load(kN)	3114	3114	4448	4448
Working pressure(MPa)	0.6 ~ 0.8
