XR220D Прямая поставка с китайской фабрики вращающаяся буровая установка на продажу для

XR220D Прямая поставка с китайской фабрики вращающаяся буровая установка на продажу для

Категория: >>>
Поставщик: Maxizm,Construction,Machinery,(Qingdao),Co.,Ltd.

Цена:21 381 438,00 ₽ - 24 122 648,00 ₽*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-20-2025	25443911.2 $*	26716107.11 $*
Aug-20-2025	25230097.24 $*	26491602.49 $*
Jul-20-2025	21167624.32 $*	22226005.93 $*
Jun-20-2025	24802468.35 $*	26042591.88 $*
May-20-2025	21595252.64 $*	22675015.42 $*
Apr-20-2025	24374839.79 $*	25593581.78 $*
Mar-20-2025	24161025.33 $*	25369076.75 $*
Feb-20-2025	23947211.85 $*	25144572.80 $*
Jan-20-2025	23733396.75 $*	24920066.28 $*

Характеристики

Phone Number: (+86) 13008115626
Wechat: Today_isWendy_
QQ:1970971306
Whatsapp: (+86) 13008115626
Skype:(+86)13008115626
Our Website:www.maxizm.com
Linkedin: claire(@)maxizm.com
Ins: fanyilin70
Contact
ME

Product Overview

XR220DⅡ XR Series Rotary Drilling Rig

1. It adopts the dedicated hydraulic retractable crawler chassis and large diameter slewing bearing to provide extraordinary stability and transport convenience.
2. It adopts the top brand electric control turbo-supercharged engine to provide strong power and conformity with Euro III emission standard.
3. With the hydraulic pressure system adopted threshold power control and negative flow control,the system acquired high efficiency and higher energy conservation.
4. Using single rope winding, effectively solve the steel wire rope wear problem, improve the life of wire rope; And drill deep detection device is setted in main winding,single rope to make deep inspection more accurate.
5. The whole machine design meet the requirements of the CE directive, safety guarantee, construction safer.

PRODUCT SPECIFICATIONS

Description			Unit	Parameter value
Max. drilling diameter			mm	2000
Max. drilling depth			m	67,standard configuration
					(5-section friction Kelly bar)
					52,optional configuration
					(4-section-locking Kelly bar)
Allowable luffing scope (from center of drill rod to slewing center)			mm	3905~4800
Drilling rig dimension in working condition (L × W × H)			mm	8968×4400×22180
Drilling rig dimension in transport condition (L × W × H)			mm	16360×3250×3535
Weight of overall unit (standard configuration, excluding drilling tool)			t	76
Engine	Model		QSL-325
Engine		Rated power/speed	kW	242/(2200r/min)
Max. working pressure of hydraulic system			MPa	35
Rotary drive	Max. torque	kN •m	220
Rotary drive		Rotational speed(Standard configuration)	r/min	7~25
Crowd cylinder	Max. Pushing force	kN	200
		Max. Pulling force	kN	200
		Max. stroke	mm	5000
Main winch	Max. pulling force	kN	230
		Max. single-rope speed	m/min	70
		Diameter of the steel wire rope	mm	30
Auxiliary winch	Max. pulling force	kN	80
		Max. single-rope speed	m/min	60
		Diameter of the steel wire rope	mm	20
Drilling mast	Left/right inclination of mast	°	4/4
Drilling mast		Front/back inclination of mast	°	5/15
Rotary table slewing angle			°	360
Traveling	Max. traveling speed of the overall unit	km/h	1.5
Traveling		Max. climbable gradient of the overall unit	%	35
Crawler	Width of crawler plate	mm	800
		External width of crawler (min.-max.)	mm	3250~4400
		Center distance between two longitudinal wheels of crawler	mm	4750
		Average ground pressure	kPa	108
