Product Description
Luminescent Alignment Screens for Laser Lidar, Rangefinder, Special Equipment
Currently, laser systems with large-aperture beams are actively developing. These systems are used in range finders, geodetic instruments, lidars, and special equipment. Visualizers with a large active area must be used for their alignment. EL series luminescent screens have an active area of more than 1 m2 and are able to work in various weather conditions.
Features:
- High moisture resistance and high mechanical characteristics;
- Screens are able to work in the field under various weather conditions;
- A wide temperature range of operation from -40 оC to more than +50 оC;
- The broad spectral range of 0.75 - 2.1+ μm allows to visualize the radiation of different commercial lasers (laser diode, fiber laser, YAG: Nd, YAG: Er, YLF: Tm, YAG: Ho and others);
- High spectral sensitivity;
- Custom sizes are available.
- Screens are able to work in the field under various weather conditions;
- A wide temperature range of operation from -40 оC to more than +50 оC;
- The broad spectral range of 0.75 - 2.1+ μm allows to visualize the radiation of different commercial lasers (laser diode, fiber laser, YAG: Nd, YAG: Er, YLF: Tm, YAG: Ho and others);
- High spectral sensitivity;
- Custom sizes are available.
EL2 series luminescent screens make it possible to visualize infrared laser radiation from systems with large-aperture beams in the visible spectral range. Due to the polymer base, the EL2 luminescent screens can work in the field under various types of precipitation.
Features
- High moisture resistance and high mechanical characteristics;
- Screens are able to work in the field under various weather conditions;
- A wide temperature range of operation from -40 оC to more than +50 оC;
- The broad spectral range of 0.75 - 2.13+ μm allows to visualize the radiation of different commercial lasers;
- High spectral sensitivity;
- Custom sizes are available.
Specification
Brand Name | Photonic Technology Systems |
Model Number | EL2 |
Screen area, m2 | >1 |
Absorption Spectral Ranges, μm | 0,75-2,13+ |
Damage Threshold, mW/cm2 | >700 |
Spectral Sensitivity, μW/cm2 | <20 (@808 nm), <20 (@960 nm), <2 (@1550 nm), <500 (@1940 nm) |
Color of Emission | Red |
Charging Required for Emission | Yes |
Customized support | OEM, ODM |
Place of Origin | Russia, Mordovia republic, Saransk city |
Packing & Delivery
Each Laser Beam Visualizer is packed into plastic envelope.
We deliver orders with help of these International shipping services:
FAQ
1. Can I get samples?
Yes, we will send test samples. Sending a test batch is under discussion.
2. Can I have my own customized product?
Yes, we will send test samples. Sending a test batch is under discussion.
2. Can I have my own customized product?
We can custom-design products. We can discuss all the conditions with you, just write to us.
3. How long does it take to calculate the shipping cost?
The average shipping cost estimate takes 1 to 3 business days.
3. How long does it take to calculate the shipping cost?
The average shipping cost estimate takes 1 to 3 business days.
