Усовершенствованный маленький гидравлический редуктор 300
- Категория: Gearboxes >>>
- Поставщик: Shandong,Aberdeen,Power,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.96 $* | 0.49 $* |
| Aug-15-2025 | 0.91 $* | 0.30 $* |
| Jul-15-2025 | 0.24 $* | 0.71 $* |
| Jun-15-2025 | 0.3 $* | 0.68 $* |
| May-15-2025 | 0.13 $* | 0.31 $* |
| Apr-15-2025 | 0.92 $* | 0.48 $* |
| Mar-15-2025 | 0.9 $* | 0.26 $* |
| Feb-15-2025 | 0.7 $* | 0.44 $* |
| Jan-15-2025 | 0.56 $* | 0.47 $* |
Характеристики
Products Description
The HC series of marine gearboxes independently developed by the company have a power range of 10kW～3000kW, a speed ratio range of 1.5～24:1, complete product specifications, and a high market share. They are widely used in various heavy-duty ships such as transport ships, fishing boats, and work boats.
Product Paramenters
Advance small hydraulic gearbox 300 marine gearbox
Model | 300 | HC300 | J300 | D300A | T300 | T300/1 | |||||
Input speed (r/min) | 750-2500 | 700-2500 | 750-2000 | 1000-2500 | 1000-2300 | 1000-2300 | |||||
Reduction ratio (i) | 1.87 2.04 2.54/ 3.00/3.53/ 4.10 4.47 4.61/4.94/ 5.44/ | 1.50 1.87 2.04 2.23 2.54 3.00 3.53/ 4.10 4.47/ 4.61/ 4.94/5.44 | 2.04 2.54 3.0 3.47/ 3.95 | 4.00/4.48/5.05/5.52 5.90 6.56/ 7.06/ 7.63 | 4.73 4.95 5.51 6.03 6.65 7.04/ 7.54 8.02/ 8.47 | 8.94 9.45 | |||||
Transmission capacity (kW/r/min) | 0.257/ 0.243/ 0.221/ 0.184/ 0.147/ 0.125 | 0.257/ 0.2/ 0.184/ 0.147/ 0.13 | 0.280/ 0.257 | 0.257/ 0.243/ 0.221/ 0.184/ 0.147/ 0.125 | 0.243/ 0.221/ 0.200 | 0.196 | |||||
Rated thrust (kN) | 50 | 60 | 70 | ||||||||
Center distance (mm) | 264 | 264 | 355 | ||||||||
Length * width * height (mm) | 786*930*864 | 680*930*880 | 786*930*864 | 786*1010*1041 | 772*980*1106 | ||||||
Net weight (kg) | 740 | 680 | 740 | 940 | 1120 | ||||||
Manipulation form | Push-pull flexible shaft electric control air control | ||||||||||
Link flywheel | 12V135 12V150 SAE18 16 14 | ||||||||||
Link cover | 12V135 12V150 SAE0 1 | 12V135 SAE0 1 | SAE0 1 | ||||||||
Input and output steering when downhill | on the contrary | ||||||||||
Our factory
Our factory
Shandong Aberdeen Power Equipment was founded in 2015 and is committed to the R&D and manufacturing of engine generator sets. The company has nearly 100 skilled engineers and service teams.
Packaging & Shipping
Our Services
FAQ
