Характеристики



Product Description




Mppt solar charging controller 12v 24v 48v 36v solar panel controller (12v 24v 48v automatic Identification)
MPPT (Maximum Power Point Tracking)Solar Charge Controller offer an efficient, safe, multi-stage recharging process that prolongs battery life and assures peak performance from a solar array. Each Charge Controller allows customized battery recharging.


Model
50A
60A
70A
Charging Mode
MPPT Automatic Maximum Power Point Tracking
Charging Method
Three stages : Constant Current ( MPPT), Balanced Charging, Floating Charge
System Type
12 V/ 24 V/ 48 V
Automatic Identification/ Manual Setting


System Identification Voltage Range
12 V System
DC 9 V- DC 15 V
24 V System
DC 18 V- DC 30 V
48 V System
DC 36 V- DC 60 V
Soft Start Time
12 V/ 24 V/ 48 V
≤10 s
Dynamic Response Recovery Time
12 V/ 24 V/ 48 V
≤500 us
Static Power
12 V/ 24 V/ 48 V
≤2 W
Machine Efficiency
12 V/ 24 V/ 48 V
≥96 . 5 %
PV Module Utilization
12 V/ 24 V/ 48 V
≤99 . 97 %
Input Characteristics
Input Characteristics Detailed Info as bellow


MPPT Operating Voltage Range
12 V System
DC 18 V- DC 150 V
24 V System
DC 34 V- DC 150 V
48 V System
DC 65 V- DC 150 V


Input Low Voltage Protection Point
12 V System
DC 16 V
24 V System
DC 30 V
48 V System
DC 60 V


Input Low Voltage Recovery Point
12 V System
DC 18 V
24 V System
DC 34 V
36 V System
DC 65 V
Limit Input Voltage
12 V/ 24 V/ 48 V
DC 160 V
Over voltage Protection
12 V/ 24 V/ 48 V
DC 150 V
Over voltage Recovery
12 V/ 24 V/ 48 V
DC 145 V
Output Characteristics
Output Characteristics Datasheet as bellow (12 V/ 24 V/ 48 V)
Optional Battery Type (Default is lead - acid maintenance- free battery)
Lead- acid maintenance- free Battery, G e l Battery, Liquid Battery, Lithium Battery ( Can also be customized for other types of
battery)


Our Advantages


1.Supply Support
we ensures the product with good quality,sufficient quantity and diversification.
2.Quality Safety
We own professional quality management and process inspecion team.
3.Unique Design Concept
Provide the most excellent products,the most excellent products.
4.Service Team
We have a professional customer service team to answer your doubts at any time.


Product Diplay




Details Images


Features:
GUOMAO MPPT controller is an advanced, efficient and versatile photovoltaic product.
1. It uses innovative maximum power point tracking technology to significantly improve the energy efficiency of solar energy systems with a conversion efficiency of 97%.
2. The controller adopts intelligent battery charging management and has temperature compensation function to effectively manage the battery and extend the battery life.
3. The controller integrates RS485 communication interface, which can provide communication protocol, which is convenient for customers to integrate and manage.
4. Intelligent maximum power tracking technology High precision and high efficiency with DSP chip control The widely PV range voltage input , three stage charging technology
5. The photovoltaic/battery connection reverse protection short-circuit protection /over current protection Display technology parameter with 7 inch touch screen Rs485 remote communication and data transmission(optional)




Company Profile






GUOMAO is a manufacturer of solar power system with well-equipped testing facilities and strong technical force.It is located in Jingjiang. GUOMAO, specialized in R&D.We are concentrated on on-grid system,off-grid system and intergrated solar system.The main products including Mono-crystalline PV panel,Poly-crystalline PV panel,Storage battery,solar charge controller,solar inverter and so on.We have our own factory to product solar mounting and PV modules.
GUOMAO has introduced advanced automatic production equipment from Germany,Italy and Japan.Our products are global and trusted by users. GUOMAO provide one-stop service for design, production, sales and installation.We are looking forward to cooperating with you sincerely.


Packing & Delivery




To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.


FAQ


1.Why choose us?
A: We are absolutely excellent quality, reasonable price, as well as the entire team to customers for a full
range of services to ensure the interests and satisfaction of customers, we always take integrity and respect as the foundation.
2.What are the price terms?
A: The prices listed are ex-factory. There may be additional shipping costs depending on the forwarder and method of
transportation. Prices may fluctuate due to changes in material cost/labor cost/exchange rate. Please consult our sales staff confirm the order.
3.How's about the packing?
A: To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
4.What are the terms of payment?
A: Telegraphic transfer 30% as deposit, before delivery telegraphic transfer 70%. We'll show you a picture of the product and packaging before you pay.
5.What's your delivery time?
A: For the products in stock, we can deliver them to you in 5-10 days. The normal lead time for mass production is 20-45 days. Specific also depends on destination port and decide.
6.How to place and pay?
A: You can contact our Sales Manager to draw up your π or Transaction Guarantee Order, or you can press the "Order Start" button on Alibaba.
