Характеристики
Self-loading concrete mixer truck, also known as self-loading and unloading mixer truck, is a device that combines the functions of existing concrete trucks and mixing stations. It automatically loads, measures, mixes to discharge, and can realize transportation and on-site construction. Operation. Self-loading mixer trucks are less widely used in China, and are more widely used in Southeast Asian countries such as India and the Philippines. They are mainly used for road paving, dams, infrastructure construction and other related projects, as well as small projects in urbanization construction.
The self-loading mixer truck has excellent traction performance and comprehensive functions. One person can operate the entire process of loading (weighing in the process), mixing, transportation, and unloading of aggregates. Therefore, it has great application advantages in the construction of small square volume concrete or the harsh working conditions that are difficult to reach by ordinary mixer trucks.
The self-loading mixer truck has excellent traction performance and comprehensive functions. One person can operate the entire process of loading (weighing in the process), mixing, transportation, and unloading of aggregates. Therefore, it has great application advantages in the construction of small square volume concrete or the harsh working conditions that are difficult to reach by ordinary mixer trucks.
Product Description
GENRON VEHICLE supply different model excavator to choose.
MODEL | GVM-1000 | GVM-1600 | GVM-2000 | GVM-2500 | GVM-3000 | GVM-3600 | GVM-4000 | ||||
Operating weight (T) | 5 | 6 | 6.2 | 6.5 | 8.3 | 8.3 | 8.5 | ||||
Output capacity (m3) | 1 | 1.6 | 2 | 2.5 | 3 | 3.6 | 4 | ||||
Bucket capacity (m3) | 0.4 | 0.4 | 0.45 | 0.45 | 0.6 | 0.6 | 0.6 | ||||
Engine model | Yunnei 495 | Yunnei 4100 | Yunnei 4102 | YUCHAI 4105 | YUCHAI 4105 | YUCHAI 6105 | CUMMINS | ||||
Rated power (kw) | 55 | 73 | 78 | 85 | 85 | 92 | 100 | ||||
Product Details
Leading product design：
1.The working device adopts high-strength steel plate, the structure is stronger; and the finite element analysis is carried out to simulate the actual working condition of the MIXER, verify the load strength, and eliminate design defects
2.The front and rear supports of the boom and the stick are made of cast steel, and the strength is greatly improved according to the direction and size of the force in the work.
2.The front and rear supports of the boom and the stick are made of cast steel, and the strength is greatly improved according to the direction and size of the force in the work.
Original imported engine:
1. The original imported equipment that meets the three-stage emission standards Engine to achieve high operating efficiency at the same time When reducing fuel consumption.
2. Standard with original large oil and water
The separator extends the service life of the engine.
The separator extends the service life of the engine.
3.Cummins, Isuzu engine can be customized.
Optimize hydraulics ：
1.Main pump power control system，
Adopting a world-class hydraulic system, the flow can be adjusted automatically with the manipulation of the handle, and the speed of the actuator can be controlled proportionally to reduce power loss.
Adopting a world-class hydraulic system, the flow can be adjusted automatically with the manipulation of the handle, and the speed of the actuator can be controlled proportionally to reduce power loss.
2. The main pump flow is increased, and the work efficiency is increased by 10%
Digging power increased by 8%, more suitable for hard rock mining.
Safe and comfortable driving experience :
1. Operator comfort and convenient control
Work comfortably and safely in a spacious and quiet cab which provides superb visibility from the operator seat to keep you aware
of surroundings. An adjustable suspension seat can increase comfort and reduces operator fatigue.
Work comfortably and safely in a spacious and quiet cab which provides superb visibility from the operator seat to keep you aware
of surroundings. An adjustable suspension seat can increase comfort and reduces operator fatigue.
2. Standard ROPS anti-rolling cab, which improves the safety factor of the cab, and optional cab protective nets and anti-collision side beams make it more suitable for harsh operating environments
Product Specifications
* High strength steel plate, which enhances the load capacity and high stability of vehicle.
* The material of rolling ring and mixing drum adopts 16mn high strength steel which uses
* Mixing blade is designed with varying pitching angles, which simplifies the feeding device, ensures the speed faster and mixing
performance
* The material of rolling ring and mixing drum adopts 16mn high strength steel which uses
forging normalizing manufacturing
* Mixing blade is designed with varying pitching angles, which simplifies the feeding device, ensures the speed faster and mixing
performance
Name | Item | Specification | |||||
Net | 8300 KG | ||||||
Transmission | Full Hydraulic 4 WD | ||||||
Brake | Air Brake | ||||||
Chassis | Off-road | ||||||
Tread | 1880mm | ||||||
Wheelbase | 2250mm | ||||||
Loader bucket | capacity | 0.6m3 Hydraulic Control | |||||
Tilt angle | 30% | ||||||
Speed | High | 0-25KM/H | |||||
Low | 0-9KM/H | ||||||
MAX drum capacity | 6.2M3 | ||||||
Tyre model | 16/70-20 construction tyres | ||||||
Engine | Type | COMMINS (have after sales service in Ghana) | |||||
Rated Power/RPM | 129HP /2200RPM | ||||||
Max.Torque/RPM | 460N.M/1400RPM | ||||||
Cylinder | 4 | ||||||
Starter | Electric | ||||||
Cooling type | water cooling | ||||||
Maxing Drum | Output capacity | 4 M3 | |||||
Bank Angle | 16 ° | ||||||
Rotation Angle | 19-21R/min | ||||||
Chute | Swing Angle | ≥60° | |||||
Angle control | Hydraulic | ||||||
Weighing model | computer control | ||||||
Concrete Standard | C15.C20.C25 C30 | ||||||
Accuracy | Cement | ≤±2%/time | |||||
Relative Error | ≤±3%/time | ||||||
water | ≤±1%/time | ||||||
Additive | ≤±1%/time | ||||||
Admixture | ≤±2%/time | ||||||
Loader control | Hydraulic 4 way stick | ||||||
Size | 7500x2700x3380mm | ||||||
