Характеристики



Product Description




Specification


item
value
Condition
New
type
Column Drilling Machine
Max. Drilling Dia. (mm)
8.5mm
Range of Spindle Speed(r.p.m)
0r.p.m - 1250r.p.m
CNC or Not
CNC
Place of Origin
China
Zhejiang
Brand Name
CDK
Model Number
DSG-1000
Dimension(L*W*H)
860*610*1060mm
Weight (KG)
175KG
Warranty
1 Year
Key Selling Points
High-accuracy
Showroom Location
None
Applicable Industries
Garment Shops, Building Material Shops, Manufacturing Plant, Construction works
Marketing Type
New Product 2021
Machinery Test Report
Provided
Video outgoing-inspection
Provided
Warranty of core components
2 years
Core Components
Motor
Name
Tapping Machine
CNC yes or not
Yes
Product name
CNC Tapping Machine
Color
Blue White
Spindle travel
100mm
Taper
MT.2
Working table dimension
230*300mm
Column diameter
85mm
Main spindle to working table
510mm


Main Characteristics
1. Designed according to CNC machining center, high speed and high efficiency in the working process.
2. High-precision ball screw, no gap, high motion accuracy.
3. Intelligent control, simple operation, repeatability up to 0.02mm.
4. Easy maintenance and save cost.


Related Products




Packing & Delivery




Each piece is wrapped with stretch film or packed in a wooden case.


Company Profile








DingKe Machinery & Equipment Co.,Ltd. was established in 1996, the company manufacturing base is located in Ningbo City, Zhejiang Province,Is a professional engaged in CDK brand design and manufacture of precision automatic drilling machine, precision automatic tapping machine, precision multi axis drilling / tapping teeth, high precision power main shaft and nut tapping machine, all kinds of automatic drilling / attack teeth of various special machine and automatic assembly machine and other products R & D, design, production, manufacture and sales service in one of the well-known brand enterprises.
The company has the domestic first-class R & D and survival of technical personnel and management team, production and processing equipment and advanced testing equipment complete reliability.
Since 2008, in order to improve the company's management level and strengthen the protection of product knowledge, application and through the ISO9001 quality system certification and CE safety certification, apply "CDK" logo is a registered trademark of the company, and also apply for a dozen of utility model and appearance of the patent protection and number therein, English company domain name in order to improve the company's image and marketing category.
To better meet customer demand in supporting, operating at the same time, Japan YAMWA, OSG, YG brand silk attack, drills, die, CNC cutting tools, such as and well-known brands in Taiwan special drilling, tapping teeth, NC machining precision collet chuck, chuck and other series products. At the same time, according to customer demand for customized non-standard tools and ancillary equipment, welcome to inquire!
