Производитель highTorque Электрический BLDC мотор для ручки робота водонепроницаемый редуктор 24V 48V DC бесщеточный электродвигатель поезда bldc
- Категория: DC Motor >>>
- Поставщик: Changzhou,Holry,Electric,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 29.62 $* | 30.9 $* |
| Aug-15-2025 | 28.48 $* | 29.2 $* |
| Jul-15-2025 | 24.49 $* | 25.13 $* |
| Jun-15-2025 | 28.15 $* | 29.87 $* |
| May-15-2025 | 24.95 $* | 25.35 $* |
| Apr-15-2025 | 27.51 $* | 28.38 $* |
| Mar-15-2025 | 27.9 $* | 28.12 $* |
| Feb-15-2025 | 27.91 $* | 28.57 $* |
| Jan-15-2025 | 27.83 $* | 28.55 $* |
Характеристики
Why Choose Us
Products Description
Product Paramenters
motor model | 60BLDC21030A-01 | 60BLDC22030A-01 | 60BLDC43030A-01 | 60BLDC44030A-01 | |||||
Phase | 3 | ||||||||
Number of poles | 8 | ||||||||
Winding connection | Y | ||||||||
Hall electrical angle | 120 | ||||||||
Rated voltage DC（V） | 24 | 24 | 48 | 48 | |||||
Rated power Pn (W) | 100 | 200 | 300 | 400 | |||||
Rated torque Tn (N.m) | 0.318 | 0.636 | 0.955 | 1.27 | |||||
Rated speed n (rpm) | 3000 | 3000 | 3000 | 3000 | |||||
Rated current In (A) | 5.08 | 9.8 | 7.37 | 9.8 | |||||
Maximum instantaneous torque Tm (N.m) | 0.954 | 1.9 | 2.86 | 3.81 | |||||
Instantaneous maximum current Im (A) | 15.16 | 29.4 | 22.11 | 29.4 | |||||
Back EMF constant e (V/kr pm) | 4.3 | 4.3 | 4.3 | 4.3 | |||||
Torque constant Tt (N.m/A) | 0.48 | 0.48 | 0.48 | 0.48 | |||||
Line resistance RL(Ω) | 6.41 | 8.02 | 6.41 | 8.02 | |||||
Line inductance LL(Mh) | 13.04 | 16.3 | 13.04 | 16.3 | |||||
Moment of inertia Jm (Kgcm) | 0.3 | 0.37 | 0.45 | 0.51 | |||||
Insulation class | B | ||||||||
Bearing radial force Fr (N) | 180 | 180 | 180 | 180 | |||||
Bearing radial force Fr (N) | 90 | 90 | 90 | 90 | |||||
Weight (Kg) | 1.3 | 1.8 | |||||||
cooling method | Fully enclosed, self-cooling | ||||||||
Protection level | IP54 | ||||||||
Use environment | temperature | -25~+40℃ (no freezing) | |||||||
humidity | Below 95%RH (no condensation) | ||||||||
surroundings | Keep away from corrosive, flammable gas, oil drop, dust | ||||||||
altitude | The highest altitude is 4000 meters, and the altitude is more than 1000 meters. For every additional 100 meters, the power is reduced by 1.5% | ||||||||
Rated condition | Temperature rise | When the ambient temperature is 40℃, the surface temperature of the case rises by 60K | |||||||
Company Profile
Certifications
Exhibition
Product packaging
FAQ
1. Do you have online contact info?
A1: Yes, whatsapp is +86 15961199768
2. How can we know the product quality?
A2: We suggest you to order a sample. Also, you can send us email for detail photos for checking if you cannot get enough information in the product page.
3. Is this your final price? May i have the discount?
A3: Our price is the factory price, and if your quantity is larger, we will allow the discount for you.
4.Is there cheap shipping cost to import to our country?
A4: Yes, we have our regular shipping company, they have very good price.
5. Can we visit your factory?
A5: Yes welcome warmly. No. 295, Fumin Road, Lucheng Town, Qishuyan, Changzhou City, Jiangsu Province, China.
6.What is the Warranty for your products?
A6: All products product warranty for one year, free service for 10 years.
A1: Yes, whatsapp is +86 15961199768
2. How can we know the product quality?
A2: We suggest you to order a sample. Also, you can send us email for detail photos for checking if you cannot get enough information in the product page.
3. Is this your final price? May i have the discount?
A3: Our price is the factory price, and if your quantity is larger, we will allow the discount for you.
4.Is there cheap shipping cost to import to our country?
A4: Yes, we have our regular shipping company, they have very good price.
5. Can we visit your factory?
A5: Yes welcome warmly. No. 295, Fumin Road, Lucheng Town, Qishuyan, Changzhou City, Jiangsu Province, China.
6.What is the Warranty for your products?
A6: All products product warranty for one year, free service for 10 years.
