180 градусов ОСВЕЩЕНИЕ Ra 90 3000k 4000k 6000k линейная Светодиодная лента Cob для
- Категория: >>>
- Поставщик: Shenzhen,Led,Home,Opto-Electronics,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.95 $* | 0.36 $* |
| Aug-16-2025 | 0.10 $* | 0.37 $* |
| Jul-16-2025 | 0.92 $* | 0.37 $* |
| Jun-16-2025 | 0.83 $* | 0.36 $* |
| May-16-2025 | 0.55 $* | 0.78 $* |
| Apr-16-2025 | 0.61 $* | 0.39 $* |
| Mar-16-2025 | 0.57 $* | 0.62 $* |
| Feb-16-2025 | 0.14 $* | 0.71 $* |
| Jan-16-2025 | 0.3 $* | 0.49 $* |
Характеристики
Newest Dots-free 180 Degree Lighting Ra 90 Led Farm Light
CCT 24v 12v IP20 Flexible Cob Strip Light Led
Specification
Electrical technical data | ||||||
Nominal input voltage | 24V DC | Voltage range | 24V DC | |||
LED types | cob | Product dimension | ||||
LED QTY/m | 160led/m | PCB dimension | 8mm x 2oz | |||
IP rating (optional) | IP20 (IP65,IP67,IP68) | Cut points | 50mm | |||
Beam angle | 180° | Material of coating | N/A | |||
Bend radius | R<50mm | Customized length/reel | 0.1 to 30meters | |||
Dimming function | PWM/ 0-10V/ DALI | Standard length/reel | 5meters | |||
Connection | 2 x 0.5MM2 / 20AWG wire / DC connector | Installation. | 3M 300LSE adhesive tape | |||
Light technical data | ||||||
Part number | FLWCOB-24V160-8 | |||||
W:24=2400K/W 27=2700K/ W30=3000K/ W40=4000K/W 50=5000K/ W57=5700K/ W65=6500K | ||||||
FL= Flexible Strip; COB= COB/2835/3528/5050; 9W= Power per meter; P8= 8mm PCB | ||||||
Power consumption/m | 15W | 10W | 7.2W | |||
CCT | 2400~6500K | 2400~6500K | 2400~6500K | |||
Lumen output/m | 1350~1605Lm | 930~1100LM | 705~828LM | |||
Efficacy | 90~107Lm/w | 93~110Lm/w | 98~115Lm/w | |||
MAXRUN in series | 15m (4.7A) | 17m (3.5A) | 20m (3A) | |||
Binning tolerance & code | SDCM<3 | SDCM<3 | SDCM<3 | |||
CRI (White) | Ra+92;R9+68 | |||||
TM30 | Rf=90 Rg=99 | |||||
TLCI(Qa) | 90 | |||||
Warranty | 5 years | |||||
Dimension
Basic Parameter
LED Strip Solution
Recommend Products
More product
Customization
Installation
Accessories
Applications
Our Company
Packaging & Shipping
QTY per Carton | 60pcs | Carton size | Carton size | 40*40*23cm | 40*40*23cm | ||
G.W. per reel (5m) | 0.15Kg | G.W per Carton | 9.50Kg | 9.50Kg | |||
Quantity | Country | Delivery method | Lead time | Freight cost | Note | ||
500m | France, Spain, Italy, Germany, Belguim ect | TNT Door to door service | 4-7days | USD165 | This is only for reference, the freight cost will be different with real order and real situation | ||
door to door service | |||||||
500m | Australia, New Zealand | TNT Door to door service | 4-7days | USD175 | |||
500m | American | DHL door to door service | 2-4days | USD220 | |||
FAQ
Q1. Can I have a sample order?
Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
Sample needs 7-10 days, mass production time needs 3-4 weeks
Q3. Do you have any MOQ limit ?
Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order?
Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo?
Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
Yes, we offer 2-5 years warranty to our products.
Q8: How to deal with the faulty?
Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
Sample needs 7-10 days, mass production time needs 3-4 weeks
Q3. Do you have any MOQ limit ?
Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order?
Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo?
Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
Yes, we offer 2-5 years warranty to our products.
Q8: How to deal with the faulty?
Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
