Factory price50 100m Portable hydraulic water well drill rig diesel engine track-type drilling rigs machine for
- Категория: Mine Drilling Rig >>>
- Поставщик: Shanghai,Yingyong,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 1190.13 $* | 1250.0 $* |
| Aug-15-2025 | 1180.15 $* | 1239.83 $* |
| Jul-15-2025 | 990.50 $* | 1040.41 $* |
| Jun-15-2025 | 1160.30 $* | 1218.34 $* |
| May-15-2025 | 1010.11 $* | 1061.79 $* |
| Apr-15-2025 | 1140.52 $* | 1197.30 $* |
| Mar-15-2025 | 1130.58 $* | 1187.42 $* |
| Feb-15-2025 | 1120.45 $* | 1176.78 $* |
| Jan-15-2025 | 1110.87 $* | 1166.35 $* |
Характеристики
Product Description
HW series hydraulic drilling machine
Is a wide range of uses of portable drill. Suitable for railway, water conservancy, bridge, dam foundation and other buildings of well drilling, geological survey, geological core drilling, small grouting hole, blasting hole, according to the different formation of the selection of diamond, composite pieces and alloy drill.
Product Case
Strengths describe
1.Widely used · Meet demand
2.Practical wear resistant, safe and reliable
3.Save time save effort save time
4.Precision machining and accurate positioning
5.High quality material and durable
2.Practical wear resistant, safe and reliable
3.Save time save effort save time
4.Precision machining and accurate positioning
5.High quality material and durable
Product Parameters
Model | HW-160/160YY | HW-190YG/19YYG | HW-230/230YY |
Drilling depth（m） | 160 | 190 | 230 |
Opening diameter（mm） | Soil, rock500，220 | Soil, rock500，220 | Soil, rock500，273 |
Final pore diameter（mm） | 75 | 75 | 75 |
Drill pipe diameter（mm） | 42，50 | 42，50 | 42，50，50 |
Inclination of borehole（°） | 90-75 | 90-75 | 90-75 |
Auxiliary power（kw） | 13.2 | 13.2 | 15 |
Weight（kg） | 600/740 | 600/750 | 880/97 |
Drilling rig size（m） | 2.4x0.8x1.3 | 2.4x0.8x1.4 | 2.7x0.9x1.5 |
Speed （r/min） | 142/285/570 | 130/300/480/730/830/1045 | 64/124/287/557 |
Stroke（mm） | 450 | 450 | 450 |
Single rope lifting forc（kg） | 2000 | 2100 | 2500 |
Wire rope capacity | 27 | 27 | 35 |
Rated load（ton） | 18 | 18 | 18 |
Flow（L/min） | 95 | 95 | 95 |
Pressure （MPa） | 1.2 | 1.2 | 1.2 |
Outlet pipe diameter（mm） | 32 | 32 | 38 |
Diameter of suction pipe（mm） | 51 | 51 | 51 |
