Egg holder production line

Product Description

1. Pulping system

(1) Put the raw material into the pulping machine and add an appropriate amount of water for a long time to stir the waste paper into pulp and then store it in the pulp storage pool. (2) Put the pulp in the pulp storage pool into the mixing pool, adjust the pulp concentration in the mixing pool, and further stir the white water in the back pool and the concentrated pulp in the pulp storage pool through the homogenizer. After adjusting to suitable pulp, put it into the pulp pool to be used in the forming system. Equipment: pulping machine, pulping machine, pulping pump, vibrating screen, pulping machine.

2. Forming system

(1) The pulp in the pulp supply pool is fed into the molding machine, absorbed by the vacuum system, and the pulp is left in the mold through the mold on the equipment to form, and the white water is absorbed and driven back to the pool by the vacuum pump. (2) After the mold is adsorbed, the transfer mold is positively pressed by the air compressor to air out, and the molding product is blown from the forming mold to the rotary mold, and is sent out by the transfer mold. Equipment: molding machine, mold, vacuum pump, negative pressure tank, pump, air compressor, mold cleaning machine.

3. Drying system

(1) Natural drying: the product is dried directly by the weather and natural wind. (2) traditional drying: brick tunnel kiln, heat source can choose natural gas, diesel, coal, dry wood, liquefied petroleum gas and other heat sources. (3) New multi-layer drying line: 6-layer metal drying line can save more than 30% energy compared with transmission drying. The main heat source is natural gas, diesel, liquefied petroleum gas, methanol and other clean energy.

4. Auxiliary packaging of finished products

(1) automatic stacking machine (2) baling machine (3) transfer conveyor

Model	RB-1000P	RB-1500P	RB-2000P	RB-2500P
Capacity	1000P/H	1500P/H	2000P/H	2500P/H
Application	EGG TRAY/FRUIT TRAY/SHOES HOLDER/WINE HOLDER
Voltage	220/380v
Power	34kw	37kw	53kw	57kw



Remarks:

Ⅰ.Delivery time: 7 days after receive clients payment.

Ⅱ.Payment term: 100% payment by T/T

III. Valid time : This quotation is valid for one month.

IV .Quality Guarantee Terms: Quality guarantee term is for one year. Malfunctions

which are caused by machine-self and quality will be responsible for our

manufacturer. Other malfunctions which are caused by operation mistakes,

man-made problems, etc will be responsible for clients-self.
