Шаньдун древесный уголь из бука мельница для древесных гранул
- Категория: Woodworking Machinery >>>
- Поставщик: Jinan,Minglun,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 2689.40 $* | 2823.39 $* |
| Aug-19-2025 | 2667.86 $* | 2800.37 $* |
| Jul-19-2025 | 2237.49 $* | 2349.53 $* |
| Jun-19-2025 | 2622.63 $* | 2753.14 $* |
| May-19-2025 | 2283.37 $* | 2397.21 $* |
| Apr-19-2025 | 2576.27 $* | 2705.43 $* |
| Mar-19-2025 | 2554.89 $* | 2682.83 $* |
| Feb-19-2025 | 2531.3 $* | 2658.50 $* |
| Jan-19-2025 | 2509.30 $* | 2634.42 $* |
Характеристики
Product Overview
Raw material and working principle
Biomass pellet raw materials from a wide range of sources, wood processing and wood-based panel produced in the sawdust, shavings,bark, sanding powder, waste wood, branches;All kinds of stalks produced after the harvest of crops;Other kinds of combustible biomass as raw material, do not need to add adhesive, through the equipment processing, can be biomass pellet fuel.
Wood pellet machine is a belt and worm gear two - stage transmission, smooth rotation, low noise.It is a pelletizing machine popular with consumers.The wood pellet motor drives the main shaft through the reducer, and the main shaft drives the press wheel.The press wheel revolves around the main shaft and rotates around the grinding disc.Biomass, when the particles are processed raw material is fed into flat die machine feeding chamber, under the common role of distributor and scraper evenly on the flat die,driven spindle roller continuous rolled material layer, squeezing material into the die, material in the die hole forming type,such as process, after a certain time in cylindrical form being squeezed out, rotating knife cutting the material, the formation of particles, particles composed sweep plate will send out. Wood fuel pellet production process
Raw material collection, raw material crushing, raw material drying, mechanical granulation molding, bagging sales.According to the different harvest period of crops, raw materials should be stored in time, and then crushed and shaped.When forming, pay attention to not immediately bagging, because of the principle of heat expansion and cold contraction to be cooled for 40 minutes,and then bagging transportation.
Main performance and characteristics
1. Vertical feed, directly in place.
2. The grinding disc is stationary, the pressure wheel rotates, the material is centrifugal, and the distribution is uniform.
3. Double layer grinding tools, positive and negative dual use, reduce costs, high production and energy saving.
4.The main force parts are made of high alloy wear-resistant materials, and the life of the vulnerable parts is twice as long as that of similar products.
5. 24 hours operation, automatic lubrication.
6.High output, low energy consumption, low noise, low fault, machine fatigue resistance, economic and durable.
PRODUCT SPECIFICATIONS
Unit type | Motor power（KW) | Output(KG/H) | Size(MM) | Weight(KG) | Contain equipment |
ML-250 | 15 | 100-200 | 1120*440*1060 | 400 | Main engine，electric control box |
ML-300 | 22 | 200-300 | 1280*560*1220 | 700 | Main engine, electric control box, automatic circulating oil pump |
ML-350 | 30 | 300-400 | 1300*620*1300 | 800 | Main engine, electric control box, automatic circulating oil pump |
ML-450 | 45 | 500-700 | 1620*700*1600 | 1500 | Main engine, electric control box, frequency converter, automatic circulating oil pump |
ML-550 | 55 | 700-900 | 1700*700*1600 | 1600 | Main engine, electric control box, frequency converter, automatic circulating oil pump |
_______________________________________________________________________________________________________________________
STRUCTURE OF EQUIPMENT
_______________________________________________________________________________________________________________________
SHOW DETAILS
_______________________________________________________________________________________________________________________
1.Super thick seamless steel tube body.
Strong and beautiful, durable and not breakable.
2.Famous brand electronic control system and reinforcement base device.
Ensure the safety and stability of equipment.
3.Automatic circulating oil pump.
Equipped with no butter, automatic lubrication system, free of maintenance.
4. Motor reducer integrated machine design.
Pure copper wire motor, high quality motor reducer, after tens of thousands of hours of work intensity test, the equipment is stable and reliable.
5.Double-sided grinding tool.
Using 20 chromium manganese titanium material, After carburizing quenching, low temperature tempering, greatly increase the
durability of the grinding tools.
durability of the grinding tools.
6.Star triangle buck start and inverter control system.
Ensure the safety and stability of the motor and accurate control of the blanking speed.
_____________________________________________________________________
DISPLAY OF FINISHED PARTICLES
_____________________________________________________________________
WOOD PELLET FUEL VERSUS COAL
_____________________________________________________________________
Biomass pellet fuel | Conventional coal fuel | |
VOLUME | It compresses the volume, reduces the storage space, facilitates transportation, and reduces transportation costs. | Large volume, large space, high transportation cost. |
Combustion efficiency | High combustion efficiency, easy to burn out, less residual carbon. | Not easy to ignite, high ash content, high ignition point. |
environmental protection | The combustion does not produce harmful gases such as sulfur dioxide and phosphorus pentoxide, which has environmental protection benefits. | When burning, sulfur dioxide and other harmful gases are produced, which pollute the atmosphere and lead to acid rain, which pollutes the environment and is not easy to protect the environment. |
our factory
____________________________________________________________________________
FAQ
What are the requirements of biomass fuel pellet machine for raw materials?
Particle size within 5mm, 10-18 water is the most appropriate.
What is the size of the fuel pellet?
Standard diameter 8 mm, can be customized according to the need of 6-10 mm diameter.Length 2-6 cm, can be manually adjusted.
Please explain the process in a simple and clear way。
In addition to sawdust shavings, raw materials need to be first crushed into powder (such as scraps, density board, straw, branches, etc and then put into the granulator warehouse processing molding, peanut shell can be crushed or not crushed, can be directly processed into particles.Sticks and animal waste do not need to be finely pulverized to be processed directly.
