Display Technology
|
DLP chip × 1,0.67"DMD
|
Light Source
|
New SLPL Laser module
|
Brightness
|
8500 ANSL Lumens(12000 lumens market brightness )
|
Resolution
|
1920*1200
|
Dynamic Contrast
|
15000:1
|
Color Wheel
|
Fluorescent color wheel+Glass color wheel 7200 rpm/min
|
Color Space
|
>115% REC709
|
Uniformity
|
0.9
|
Aspect Ratio
|
16:9 / 4:3\\16:10\\16:6(Compatible)
|
Projection Lens
|
F:1.0-1.7,1.7X optical zoom,f=22-35mm
|
Optional Lens
|
LA030C:0.3:1\\LA054C:0.54:1\\LA065C:0.65:1\\LA080C:0.8:1\\LA120C:0.7-1.2:1\\SLA240C:1.5-2.4:1\\LA300C:1.5-3.0:1 \\L2043-7211 360degree
|
Lens Shift
|
10%(Transverse electrical),50%(Vertical electrical)
|
Keystone Correction
|
Vertical keystone correction ±30°
|
Screen Size
|
40inch~400inch
|
Input Interface
|
VGA Computer Input 1 (15 Pin)× 1,DVI-I× 1,HDMI (v1.4 with audio)× 2
|
Output Interface
|
Display output (15 Pin)× 1
|
Control Port
|
RS232 serial interface(9 Pin,male) input× 1,RS232 serial interface(9 Pin,male) output× 1,USB (Type mini B)× 1,Network Interface (RJ45)× 1
|
Computer Compatibility
|
VGA SVGA XGA SXGA WXGA UXGA Mac
|
Video Compatibility
|
PAL,SECAM,NTSC 4.43,PAL-M,N,HDTV(480i,480p,575i,575p,720p,1035i,1080i and 1080P)
|
Horizontal Scanning Frequency
|
15-100 KHz
|
Vertical Sanning Frequency
|
48-85 Hz
|
Power Consumption
|
440W/Standby<0.5W
|
Power Supply
|
100-240V AC
|
Loudspeaker
|
1*10W
|
Light Source Life
|
Bright mode:20000 hours;ECO mode:25000 hours
|
Dimension (LxWxH)
|
501*369*169mm
|
Weight
|
<8KG
|
Noise Level
|
<37dB@33℃
|
Projection Ways
|
Front projection/Rear projection,Desk/Lifting
|
Appearance Colour
|
Black,White
|
Working Temperature
|
5-35℃
|
Storage Temperature
|
-10-60℃
|
Menu language
|
3 languages(Chinese,English,Traditional Chinese)
|
Standard Accessories
|
Power Cord, Remote Control, VGA Cable, HDMI, Warranty card, Qualified card
|
Qualification File
|
3C\\CECP\\Machine performance test report(Commissioned test)
|
