Строительная машина YG дорожная маркировочная удобное оборудование для маркировки дорожной
- Категория: Road Marking Machines >>>
- Поставщик: Henan,Yugong,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-15-2025 | 1086.72 $* | 1108.30 $* |
| Jul-15-2025 | 881.64 $* | 899.84 $* |
| Jun-15-2025 | 1069.37 $* | 1090.54 $* |
| May-15-2025 | 1060.33 $* | 1081.15 $* |
| Apr-15-2025 | 846.37 $* | 863.19 $* |
| Mar-15-2025 | 1043.65 $* | 1064.91 $* |
| Feb-15-2025 | 1035.87 $* | 1056.86 $* |
| Jan-15-2025 | 1026.78 $* | 1047.54 $* |
Характеристики
Automatic cold paint road surface line marking machine
Product Description
Henan Yugong Machinery Co.Ltd. specializes the road machinery, especially the road marking machine, including the hot melt road machine and cold paint road marking machine.
Mainly used for marking urban roads, expressways, factory buildings, parking lots, garages, plazas and airport runways, sports playground. Pavement construction machinery with different restrictions, guidelines and warnings on the level ground is delineated.
Technical Parameters
| Model | YG-6L Single Gun Road Marking Machine | YG-8L Double Gun Road Marking Machine |
| Engine Power | 4.3HP | 7HP |
| Unloading flow | 6L/min | 8L/min |
| Output pressure | 25mpa | 30mpa |
| Nozzle | 517(15cm below) | 0.027 |
| High pressure tube strength | 35mpa | 40mpa |
| High pressure tube length | 6*10m | 6*2 10*10m |
| Weight | 72kg | 130kg |
| Max spray width | 20cm | 45cm |
Application
Line marking machine plays a great role in urban planning and highway construction with its advantages of fast, efficient and accurate, which greatly saves the construction period and economic investment of pavement construction.
This product is suitable for colouring agent, varnish, enamel paint, latex paint with medium viscosity. It is recommended to use standard ambient temperature marking paint, which is easy to clean.
1. City road line marking, residential road, municipal country road, highway traffic sign, traffic safety convex line, zebra crossing line, sidewalks, lanes paint marking machine.
2. Garage, parking lots, warehouse, park line paint machine, squares, airport line marking machine.
3. Runways, football,sports ground road marking machine.![]()
![Cold-Spray-Linelizer_03]()
This product is suitable for colouring agent, varnish, enamel paint, latex paint with medium viscosity. It is recommended to use standard ambient temperature marking paint, which is easy to clean.
1. City road line marking, residential road, municipal country road, highway traffic sign, traffic safety convex line, zebra crossing line, sidewalks, lanes paint marking machine.
2. Garage, parking lots, warehouse, park line paint machine, squares, airport line marking machine.
3. Runways, football,sports ground road marking machine.
Structures
1. Pump body: adopt full-oil invasive lubrication, hydraulic power, reduce wear and tear. The service life can reach more than 40,000 hours. (Diaphragm pump)
2. Sealing gasket: carefully designed and cast. Super wear resistance, whether in winter or in summer can be used freely, acid and alkali resistance, fatigue resistance, simple and convenient replacement.
3. Suction pipe network: vertical body, suction pipe easy to clean, one person can move independently and easy to operate. Stainless steel processing anti-corrosion, the inner wall does not fall off without blockage. The suction filter solves the problems of small inlet level and easy blockage, increases the inlet area and reduces the space. Built-in enlarged filter.
4. Valve body: The inlet and outlet valves adopt spherical ceramic beads with super wear resistance, which exceed the service life of traditional steel balls by tens of times. Face and sit.
5. Frame: Vertical design is compact, practical, convenient to move and disassemble. Frame can easily wrap 30m high-pressure hose, and the whole equipment is easy to handle.
How To Choose Road Marking Machine?
1. Do you need the cold spraying road marking machine or the thermoplastic road marking machine?
2. If you need the cold paint type, do you need the single gun or the double guns road marking machine?
Company Information
Henan Yugong Machinery Co., Ltd, located in Zhengzhou,Henan province,China.Its a large engineering machinery manufacturing enterprise which focus on research and development, production and sale kinds of drilling rigs.Our drilling rigs are widely applicable for water well, farm irrigation, geological prospecting, small pile foundation, geothermal air-conditioner and so on.
We insist on the strategy of technology research and development. Technical design, material purchasing, precised manufacturing and strict quality inspection are all processed according to the ISO9001 standard.
Certifications
