5g Роутер со слотом для sim-карты vpn модем с большим радиусом действия 13 км промышленные
- Категория: Wireless Routers >>>
- Поставщик: Hongdian,Corporation
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.45 $* | 0.96 $* |
| Aug-18-2025 | 0.16 $* | 0.89 $* |
| Jul-18-2025 | 0.8 $* | 0.80 $* |
| Jun-18-2025 | 0.22 $* | 0.19 $* |
| May-18-2025 | 0.28 $* | 0.77 $* |
| Apr-18-2025 | 0.41 $* | 0.41 $* |
| Mar-18-2025 | 0.93 $* | 0.46 $* |
| Feb-18-2025 | 0.64 $* | 0.37 $* |
| Jan-18-2025 | 0.98 $* | 0.14 $* |
Характеристики
Hongdian H8922S Wifi Router Dual Band Wireless Router Wifi High Quality 4G 5G MaxStatus Power Antenna
H8922S 4G router is designed and manufactured by Hongdian, it is based on 4G cellular network technology, industrial class quality. With its embedded cellular module, it has been widely used in finance, transportation, telecom, electricity, security system and other industries. This document introduced how to use H8922S and its functional features.
Product Description
Features
H8922S Feature
Dual SIM cold/hot backup, cellular/land line backup
Support RS-232/RS-485 port
4 LAN ports & 1 WAN port
5-36VDC Wide range power supply
VPN
Support GRE/L2TP/PPTP/IPSec/OpenVPN
GRE over IPSec, IPSec over PPTP/L2TP
Network Flexubility
Support 4G+/4G/3G/2G network, cover most area of the world
Support WAN, PPPoE, Static IP, DHCP client
Support 802.11b/g/n
Advance Feature
Static routing, RIPv2, OSPF, BGP and policy routing
Support OSPF, RIP, BGP (optional)
Support DNS proxy and Dynamic DNS (DDNS)
LCP/ICMP/flow/heartbeat check, ensure network usability
Support hardware and software Watch Dog
Management
Hongdian Wedora Cloud management
Support WEB, CLI, SSH, multiple parameter management
Support IPfix
Support local/remote firmware and patch upgrade
Support parameter backup and import
Local/Remote log for easy debug
Support SNMP network management, NTP, GPS (optional)
Specification
Specifications | Descriptions | Remarks |
Product name | H8922S | V40 |
Network Type | 4G | Supported bands depend on the module selected |
Interfaces | Antenna interface | 3*Antenna interfaces (SMA-K) |
| SIM card | 1.8V/3.0V |
| Serial data port (6 pins terminal) | RS-232 by default, optional for RS-485 |
| Serial data rate | RS-232:300-230400 bps (115200bps by default) |
| Button | 1* reset button |
| LAN | 4* 10/100 BASE-T |
| WAN | 1*10/100 BASE-T |
Power supply | Operating Voltage | +5V~ +36V DC |
Working power consumption | During Idle | Approx. 200mA@12V DC |
| During Working | Approx. 550mA@12V DC |
Others | Weight | Approx. 540g |
| Size (without power connector and bracket) | Length * width * height(mm): 176*105*25 |
| Operating temperature | -30℃~+75℃ |
| Storage temperature | -40℃~ +85℃ |
| Relative humidity | <95℃(Non-condensing) |
