Автоматическая машина для упаковки термоусадочной

Описание и отзывы

Трекер стоимости

Характеристики



Model	SF-1230R
Power	12kw
Power Supply	AC 380V 3PH 50/60Hz
Max Packing Size Dia.×H	120×300mm
Tunnel Size L×W×H	1250×200×400mm
Packing Speed	20-40m/min
Shrink Film	PET/PVC
Machine Size L×W×H	2640×520×1400mm
Table Height	520±50mm
G./N. Weight	380/350kgs
Air Temperature	0-300℃



l  SF-1230R Semi-auto Label Shrink Tunnel is mainly for bottle shaped, jars, goblet product labels shrink which can shrink the bottle neck, body, bottom and overall;

l  The frequency inverter controls transmission speed and has variable speed;

l  The shrinking temperature is intelligently controlled by digital temperature controller and can be adjusted;

l  The molds can rotate 360 degrees to ensure smooth transportation;

l  The conveyor with protective cover to avoid the operator’s fingers get caught in the moving parts, so that it can pass CE safety standards;

l  The bottle nipping stations can be adjusted without changing the molds;

l  Adopt double hot air circulation system;

l  It is widely used in food, pharmaceuticals. Cosmetics and other industries.







Spare Parts	Brand	Country
Temperature Controller	Autonics	Korea
Circulation Motor	SURFON	Taiwan
Gear Motor	GPG	Taiwan
All Switches	Siemens	Germany
Intermediate Relay	Siemens	Germany
Switching Power Supply	Schneider	France
Overload Relay	Schneider	France
Frequency Inverter	Schneider	France
Electrical Breaker	Schneider	France
