Цена спиральный прецизионный прямой Электрический гибочный станок для арматуры из нержавеющей стали cnc
- Категория: Rebar Cutting Machine >>>
- Поставщик: Shandong,Jiaxin,Machinery,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 0.50 $* | 0.12 $* |
| Aug-20-2025 | 0.73 $* | 0.65 $* |
| Jul-20-2025 | 0.8 $* | 0.64 $* |
| Jun-20-2025 | 0.97 $* | 0.50 $* |
| May-20-2025 | 0.31 $* | 0.14 $* |
| Apr-20-2025 | 0.32 $* | 0.47 $* |
| Mar-20-2025 | 0.99 $* | 0.54 $* |
| Feb-20-2025 | 0.72 $* | 0.99 $* |
| Jan-20-2025 | 0.28 $* | 0.65 $* |
Характеристики
Product Description
1, combine with horizontal and vertical straightening wheels, drive by Big 18.1kw Vector brand servo motor,make sure best accuracy when straightening rebar
2, bending spindle could rotating and telescope in high speed, could cut rebars very quick to get high bending precision.
2, bending spindle could rotating and telescope in high speed, could cut rebars very quick to get high bending precision.
3, large storage capacity can save many processing graphics,
4, FATEK PLC control system, WECON touchscreen, VECTOR servo motor. 5, straightening, measure length, bending, shear at same time, processing in high efficiency.
Functions of machine
This Automatic Steel wire rebar Stirrup bender use FATEK or Simens control system with touchscreen, could automatically accomplish processing of feeding, straighten, bending and cutting on rebars.
Max bending diameter of rebar is 12mm,widely used in construction industry and rebar
Max bending diameter of rebar is 12mm,widely used in construction industry and rebar
manufacturing enterprise;
Detailed Images
Two payoffs, to feed steel wires
Maximum carrying capacity 2,000Kg each. Automatic braking system (pneumatic) and buffering system.
Emergency stop.Inner diameter adjustable
Wires Straightening rollers
Could impact wires aromatically, pneumatic impact wire.
Wire cutting tools
Mobile blade driven by an electric brake motor.
Plug type fixed blade and mobile blade, convenient to replace and save spare parts cost.
Plug type fixed blade and mobile blade, convenient to replace and save spare parts cost.
Bending axis
Driven by 7.5KW servo bending motor, could
bending ±180°;
and retractable and rotating smoothly. Bending axis could be replaced conveniently.
bending ±180°;
and retractable and rotating smoothly. Bending axis could be replaced conveniently.
Product Paramenters
Automatic steel bar bending machine | ||
Processing range of a single steel | Level I round steel 4-12mm | |
Level III thread steel 5-12mm | ||
Processing range of double steels | Level I round steel 5-10mm | |
Level III thread steel 5-8mm | ||
Processing efficiency | 1440 pcs/hour | |
Max. Bending angel | ±180° | |
Max. Feeding speed | 2000mm/s | |
Max. Bending speed | 1000 (°/s) | |
Ground clearance of bending spindle | 1120mm | |
Stirrup side length | 130--1800mm | |
Average electric power consumption | 6kw/h | |
Total capacity | 32.35kw | |
Exhibition
Customer Photos
Packing & Delivery
Company Profile
Our services
1.We provide you the friendly English User manual and Testing Video for free.
2.24 hours technical support by email or calling.
2.24 hours technical support by email or calling.
3.12Months warranty Quality guarantee and Charge free technical support forever.
4.Free training to make sure you master the operating of automatic stirrup bending machine, not including programming training.
4.Free training to make sure you master the operating of automatic stirrup bending machine, not including programming training.
5.Videos of operating the machine are available.
FAQ
Q: What's the delivery time?
A: 10-15 working days to delivery port.
Q: What's the usually delivery terms?
A: FOB, CNF, CIF, Exworks will be OK.
Q: What's the MOQ?
A: 1 set.
Q: What’s the payment term?
A: We accept T/T, L/C or Credit Card.
Q: What's your delivery port?
A: Usually Qingdao port, Shanghai port.
Q: What's the packing?
A: Iron Pallet and Plywood cases or carton or depending on your requires.
A: 10-15 working days to delivery port.
Q: What's the usually delivery terms?
A: FOB, CNF, CIF, Exworks will be OK.
Q: What's the MOQ?
A: 1 set.
Q: What’s the payment term?
A: We accept T/T, L/C or Credit Card.
Q: What's your delivery port?
A: Usually Qingdao port, Shanghai port.
Q: What's the packing?
A: Iron Pallet and Plywood cases or carton or depending on your requires.
Q: Can you place OEM orders?
A: Yes,OEM orders are acceptable. We can manufacture machines according to your requirement with your design,logo,color,materials or brand information
A: Yes,OEM orders are acceptable. We can manufacture machines according to your requirement with your design,logo,color,materials or brand information
Q:Where is your factory located? How can I visit there?
A:Our factory is located in Jining City, Shandong Province, China, about 2 hours from Beijing, 3 hours from Shanghai.
A:Our factory is located in Jining City, Shandong Province, China, about 2 hours from Beijing, 3 hours from Shanghai.
