Автомобильное реле 24 в 40 А 5 контактов с
- Категория: Auto Relays >>>
- Поставщик: Yueqing,Kuanghong,Electronic,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.16 $* | 0.44 $* |
| Aug-18-2025 | 0.2 $* | 0.59 $* |
| Jul-18-2025 | 0.51 $* | 0.79 $* |
| Jun-18-2025 | 0.27 $* | 0.10 $* |
| May-18-2025 | 0.41 $* | 0.15 $* |
| Apr-18-2025 | 0.96 $* | 0.64 $* |
| Mar-18-2025 | 0.7 $* | 0.68 $* |
| Feb-18-2025 | 0.29 $* | 0.77 $* |
| Jan-18-2025 | 0.41 $* | 0.79 $* |
Характеристики
Product Detail
Specification
Name | Automotive relay |
Colour | Black |
Shape | Square |
CONTACT DATA
Contact Material | AgSnO12 |
Contact Form | 1Z(1C)/1H(1A) |
Contact Ratings | NO:40A 14VDC |
Contact Resistance | 100mMax at6VDC 1A |
Max Switching Current | 40A |
Max Switching Voltage | 75VDC |
Max Switching Power | 560W |
Life Expectancy Electrical | 100,000 Operations(at 30 Operations/minute) |
Life Expectancy Mechanical | 100,000 Operations |
COIL SPECIFICATION
Nominal Voltage（VDC） | 24 | ||
Coil Resistance（Ω） | 1.8W | 320 | |
Max Operate Voltage（VDC） | 14.4~16.8 | ||
Mix Release Voltage（VDC） | 2.4~7.2 | ||
Max Applicable Voltage(VDC) | 30 | ||
CHARACTERISTICS
Temperature Range | -30℃~+80℃ | ||
Vibration Resistance | 10~55Hz，1.5mm | ||
Shock Resistance | Operations Extremes | 10g | |
Damage Limits | 100g | ||
Humidity | 40%~85% | ||
Insulation Resistance | 100mΩ Min at 500VDC | ||
Safety Standard | CCEE | ||
Dielectric Strength Between Open Contacts | 500VAC（for one minute/sec） | ||
Between Contact And Coil | 750VAC(for one minute/sec) | ||
Operate Time | 7ms | ||
Release Time | 5ms | ||
