Вентилятор конденсатор 3 5 мкФ cbb60 производитель долгий срок службы хорошее качество
- Категория: Passive Components >>>
- Поставщик: Smiler,Electronic,Industrial,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.47 $* | 0.21 $* |
| Aug-15-2025 | 0.11 $* | 0.37 $* |
| Jul-15-2025 | 0.89 $* | 0.89 $* |
| Jun-15-2025 | 0.35 $* | 0.45 $* |
| May-15-2025 | 0.5 $* | 0.48 $* |
| Apr-15-2025 | 0.97 $* | 0.12 $* |
| Mar-15-2025 | 0.61 $* | 0.22 $* |
| Feb-15-2025 | 0.67 $* | 0.9 $* |
| Jan-15-2025 | 0.61 $* | 0.75 $* |
Характеристики
Model Number: | CBB60 motor capacitor | |||
Type | Polypropylene film capacitor | |||
Safety approvals: | CQC/UL/VDE/TUV/CE | |||
Approval standard | GB/T3667,UL810,EN60252 | |||
Climatic category | 25/70/21,25/85/21 | |||
Rated voltage | 150VAC~600VAC(50-60Hz) | |||
Capacitance range | 1uf~80uf | |||
Capacitance tolerance | +_5%(J),+_10%(K),+10%(U),-5%(U) | |||
Testing voltage | ||||
Between terminals | 2*Un(VAC)/5s | |||
Between terminals and case | 2*Un+1000(VAC)/5s(>=2000VAC) | |||
Insulation Resistance(20℃) | ||||
Between terminals | >=2000MΩ,UF(500VDC,5s) | |||
Tangent of loss angle(20℃) | <=0.002(100Hz) | |||
Class of safety protection | S0/S3 | |||
Place of Origin | CHINA | |||
Packing | More pieces in one inner box or polybag as customer request. | |||
Color | accept customization | |||
Supplier type | OEM factory | |||
Capacitor(uf) | 250/300VAC | 300VAC | 400-450VAC | 500VAC | ||||||||
D | H | D | H | D | H | D | H | |||||
6uf | 30 | 50 | / | / | 30 | 60 | / | / | ||||
8uf | 30 | 60 | / | / | 35 | 60 | / | / | ||||
10uf | 30 | 60 | / | / | 40 | 60 | 40 | 70 | ||||
12uf | 30 | 60 | 35 | 60 | 40 | 60 | / | / | ||||
15uf | 35 | 60 | / | / | 40 | 70 | / | / | ||||
18uf | 35 | 60 | / | / | 45 | 70 | / | / | ||||
20uf | 40 | 60 | 40 | 70 | 45 | 70 | 45 | 80 | ||||
25uf | 40 | 60 | 45 | 70 | 45 | 80 | / | / | ||||
30uf | 40 | 70 | 45 | 80 | 45 | 90 | 50 | 90 | ||||
35uf | / | / | / | / | 50 | 90 | / | / | ||||
40uf | 45 | 70 | 45 | 90 | 50 | 100 | 55 | 110 | ||||
The products are made of electrical class polypropylene film,zinc-aluminum metallized electrode dry fabric aluminum shell,and enveloped with epoxy resin.They have the characteriscs of high cost performance,high pressure-resistant,long life and soon.
Dish-washing machine,Fan motor,exhaust fan motor,air conditioning fan,lampblack machine,bread machina and so on many household appliances.
