Automatic L bar sealer shrink tunnel machine with conveyors

Performance features

•FQL450S is fully automatic L bar sealer which is widely used in mass production packaging line with high efficiency.
•With movable type punching device, you can switch the punching position and control the pinholes number.
•Sealing knife uses the special steel knife with Daikin Teflon which is anti-stick coating & anti-high temperature. So the sealing will not have cracking, coking and smoking with zero pollution.
•Using digital temperature controller which built-in PID function. Sealing blade temperature is extremely sensitive and accurate which can be set arbitrarily.
•Imported photoelectric sensor, positioning accuracy, fast response.
•Adopt Panasonic PLC programmable controller and WEINVIEW 7-inch man machine interface, simple operation.
• Manual adjustment film-guide system and feeding conveyor platform make the machine suitable for different width and height items.
•Equipped with automatic scrap recycling mechanism, built-in film broken alarm function.
•The sealing blade itself is also quipped with automatic protection function which effectively prevent from accidental cutting.
•Automatic mode and manual mode can be switched at any time which convenient to replace the shrink film.
•The entire machine realizes unmanned operation with the production line connecting.
•Apply to daily necessities, food, cosmetics, pharmaceutical, hardware and other industries shrinking packaging.

•BS4522N shrink tunnel adopts the design of internal double recycling air fan, so that the hot air in the tunnel is even, constant temperature.
•The machine uses stainless steel finned heating tube which has a long service life and high heating efficiency.
•Chain bar conveying , using hollow steel covered with durable imported silicone tube, each bar can rotate freely.
•Suitable for POF, PVC, PP, PET heat shrinkable film.

L bar sealer

Heat shrink tunnel

Applies to software, food, cosmetics, printing, pharmaceutical, flooring, ceramic, beverages, hardwareother industries large quantities of shrink wrap.

Packaging Details: Standard Export Wooden Box
Delivery Detail: Common specifications are available in stock

1. We can customize machine according to your requirements and your products.

2. One year Warranty. We will replace the spare parts for free within one year which are non-man made damage except the wearing parts. After the guarantee, we will offer you the most favorable lifelong spare parts.

Q1: How do we test your machine?
When the machine complete manufactured, we will send video for you check , you can also come to our factory to test and learn how to operate it.

Q2: What information shall I provide you when I need your offer?
Normally, please tell us what product you plan to pack and please send me your product weight(L*W*H) with weight then we can quote exactly what you need.

Q3: More questions or information please feel free to contact us at any time!
