Трансформатор

Категория: Transformers >>>
Поставщик: Tianjin,Sitong,Electronic,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-16-2025	0.57 $*	0.5 $*
Aug-16-2025	0.40 $*	0.94 $*
Jul-16-2025	0.2 $*	0.81 $*
Jun-16-2025	0.58 $*	0.1 $*
May-16-2025	0.63 $*	0.41 $*
Apr-16-2025	0.69 $*	0.66 $*
Mar-16-2025	0.3 $*	0.98 $*
Feb-16-2025	0.17 $*	0.43 $*
Jan-16-2025	0.84 $*	0.41 $*

Характеристики

Details Images

Electrical Characteristics:

Storage temperature:-40 to 70

Switching frequency:1KHz to 200KHz

Operating Temperature range:-20 to +45

Dielectric Strength:AC 2KV 50Hz 5mA. between primary&secondary.

Product Paramenters

Name	Instructure type	Frequency	Temperature
high frequency transformer	vertical or horizontal	500khz max	-25 to 45℃

Applications:

High frequency transformer is the power transformer whose working frequency exceeds the medium frequency (10kHz). It is mainly
used as high frequency switching power transformer in high frequency switching power supply, but also used as high frequency
inverter power supply and high frequency inverter welding machine.According to the working frequency, it can be divided into
several grades: 10khz-50khz, 50khz-100khz, 100kHz~500kHz, 500kHz~1MHz, 1MHz or above.In the case of large transmission power, IGBT
is generally used for power devices. IGBT has a phenomenon of turn-off current trailing, so its operating frequency is relatively
low.The transmission power is relatively small, can use MOSFET, the operating frequency is relatively high
