Интегрированный тепловой насос Outes с воздушным источником коммерческий для горячей
- Категория: Heat Pump Water Heaters >>>
- Поставщик: Zhejiang,Zhongguang,Electrical,Co.,Ltd.,Ningbo,Branch
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.53 $* | 0.11 $* |
| Aug-17-2025 | 0.23 $* | 0.35 $* |
| Jul-17-2025 | 0.10 $* | 0.29 $* |
| Jun-17-2025 | 0.19 $* | 0.71 $* |
| May-17-2025 | 0.90 $* | 0.53 $* |
| Apr-17-2025 | 0.67 $* | 0.53 $* |
| Mar-17-2025 | 0.9 $* | 0.19 $* |
| Feb-17-2025 | 0.14 $* | 0.31 $* |
| Jan-17-2025 | 0.69 $* | 0.4 $* |
Характеристики
Product Overview
House Heating Heat Pump
Modes: AUTO/ECO/FAST/MULT
PRODUCT SPECIFICATIONS
Model | AHbS06D/IOP | AHbS08D/IOP | AHbS10D/IOP | |||
Outdoor Unit | AHbS06D/O | AHbS08D/O | AHbS10D/O | |||
Indoor Unit | AHbS06D/IP | AHbS08D/IP | AHbS10D/IP | |||
Power Supply | / | 220V~240V/50Hz | 220V~240V/50Hz | 220V~240V/50Hz | ||
WaterProof Level | / | IPX4 | IPX4 | IPX4 | ||
Electric Shock Proof Grade | / | Ⅰ | Ⅰ | Ⅰ | ||
Heating*（A7/W35) | Max. Heating Capacity | kW | 6.0 | 8.0 | 10.0 | |
Heating Input Power | kW | 1.51 | 1.94 | 2.48 | ||
COP | W/W | 3.97 | 4.12 | 4.03 | ||
Heating Capacity Min./Max. | kW | 2.4/6 | 3.2/8 | 4.2/10 | ||
Heating**（A7/W45) | Max. Heating Capacity | kW | 5.64 | 7.48 | 9.42 | |
Heating Input Power | kW | 1.83 | 2.43 | 3.06 | ||
COP | W/W | 3.08 | 3.08 | 3.08 | ||
Heating Capacity Min./Max. | kW | 2.25/5.64 | 3.02/7.48 | 3.98/9.42 | ||
Heating***（A2/W30) | Max. Heating Capacity | kW | 2.74 | 3.71 | 3.84 | |
COP | W/W | 3.98 | 3.94 | 3.99 | ||
Max. Cooling Capacity | kW | 4.0 | 6.0 | 7.0 | ||
Cooling Input Power | kW | 1.39 | 2.31 | 2.80 | ||
EER | W/W | 2.87 | 2.60 | 2.50 | ||
Cooling Capacity Min./Max. | kW | 1.62/4 | 2.43/6 | 2.92/7 | ||
Refigerant/Weight | / | R410A/1.5kg | R410A/1.8kg | R410A/1.8kg | ||
Max. Water Outlet Temperature | ℃ | 55℃ | 55℃ | 55℃ | ||
Heat Range Of Heating Operation | ℃ | -25~43 | -25~43 | -25~43 | ||
Heat Range Of Cooling Operation | ℃ | 15~43 | 15~43 | 15~43 | ||
Compressor | Twin Rotary/1 | Twin Rotary/1 | Twin Rotary/1 | |||
Fan | DC | DC | DC | |||
Indoor Unit | Heat Exchanger | Plate | Plate | Plate | ||
Pump Head | m | 10.5 | 10.5 | 10.5 | ||
Pump Input Power | W | 140 | 140 | 140 | ||
Rated Water Flow | m3/h | 1.03 | 1.38 | 1.72 | ||
Water Pressure Drop | kPa | 40 | 40 | 40 | ||
Max. Water Pressure | MPa | 1 | 1 | 1 | ||
Electric Heater | kW | 3 | 3 | 3 | ||
Water Pipe Connection | inch | RC3/4" | RC3/4" | RC3/4" | ||
Noise | dB(A) | ≤30 | ≤30 | ≤30 | ||
Net Weight | kg | 55 | 55 | 55 | ||
Net Dimension(L*W*H) | mm | 515*837*287 | 515*837*287 | 515*837*287 | ||
Packing Dimension(L*W*H) | mm | 594*1080*351 | 594*1080*351 | 594*1080*351 | ||
Outdoor Unit | Noise | dB(A) | 58 | 60 | 60 | |
Net Weight | kg | 80 | 85 | 85 | ||
Net Dimension(L*W*H) | mm | 1036*406*740 | 1036*406*740 | 1036*406*740 | ||
Packing Dimension(L*W*H) | mm | 1086*446*820 | 1086*446*820 | 1086*446*820 | ||
Connecting Pipe | Gas | mm | Ø12.7 | Ø12.7 | Ø12.7 | |
Liquid | mm | Ø6.35 | Ø6.35 | Ø6.35 | ||
PRODUCT SPEC.
Successful Project
Projects
Projects
Projects
SIMILAR PRODUCTS
About us
Zhejiang Zhongguang Electrical Co., Ltd. (OUTES) is a national high-tech factory manufacturing/Researching & Developing/Sales & Service 5C Comfort Home products including Central floor heating Heat Pump, Central Air Conditioning, Central Hot Water Heat Pump, Central Water Purification, Central Air Ventilation Units.
OUTES provides safe, healthy, comfortable and intelligent products for global users with high quality and considerate service!
OUTES provides safe, healthy, comfortable and intelligent products for global users with high quality and considerate service!
Testing Central
2007,we set up the 1st testing room, until now, we have 15 testing rooms and 30 test station. The Testing Center is covered 5400㎡(six thousand four hundred square meters) and the total investment reach to 50,000,000(fifty million) RMB. We have 40 engineers working here now.
2019, we got the approval from CNAS, TUV and BV. So it’s more easy for us to test the products exporting to different countries now!
We can test the performance, safety, life, noises, stress, transportation and all the other test we need for our products.
The products we can test including Hot Water Heat Pump, Chillers, gas system Central Air conditioners, water system Central Air Conditioners, Swimming Pool Heat Pump, Dryers, Air Ventilation Unit and Water Purification Unit.
The test capacity from 1 Horse Power to 200 Horse Power for a single Module Machine.
The ambient test condition can be from -35℃ to 60℃。
The products we can test including Hot Water Heat Pump, Chillers, gas system Central Air conditioners, water system Central Air Conditioners, Swimming Pool Heat Pump, Dryers, Air Ventilation Unit and Water Purification Unit.
The test capacity from 1 Horse Power to 200 Horse Power for a single Module Machine.
The ambient test condition can be from -35℃ to 60℃。
Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
FAQ
Q1: How about your delivery time ?
A1: Generally, it will take 35 to 40 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q2: How about your delivery time ?
A2: EXW, FOB,...etc.
Q3: How about your delivery time ?
A3: Generally, we pack the heat pump in brown cartons or plywood. If you have legally registered patent, we can pack the heat pump in your branded boxes after getting your authorization letters.
Q4: What is your sample policy?
A4: We accept the sample order, but the customers have to pay the sample cost and the courier cost.
Q5: Do you test all your goods before delivery?
A5: Yes, we have 100% test before we pack the goods for delivery.
Q6: How about your delivery time ?
A6: 2 years warranty on the whole unit. The spare parts must be non-humanly damaged, usually we give to customer 1% spare parts free of charge for maintenance according to order cost during the warranty period.
A1: Generally, it will take 35 to 40 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q2: How about your delivery time ?
A2: EXW, FOB,...etc.
Q3: How about your delivery time ?
A3: Generally, we pack the heat pump in brown cartons or plywood. If you have legally registered patent, we can pack the heat pump in your branded boxes after getting your authorization letters.
Q4: What is your sample policy?
A4: We accept the sample order, but the customers have to pay the sample cost and the courier cost.
Q5: Do you test all your goods before delivery?
A5: Yes, we have 100% test before we pack the goods for delivery.
Q6: How about your delivery time ?
A6: 2 years warranty on the whole unit. The spare parts must be non-humanly damaged, usually we give to customer 1% spare parts free of charge for maintenance according to order cost during the warranty period.
