Барабанная катушка/кабельная катушка с индивидуальным логотипом и размером может быть покрыта защищена полиэтиленовым
- Категория: Cable Manufacturing Equipment >>>
- Поставщик: Changzhou,Shineworld,Industry,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 1.31 $* | 1.84 $* |
| Jul-16-2025 | 1.80 $* | 1.89 $* |
| Jun-16-2025 | 1.77 $* | 1.32 $* |
| May-16-2025 | 1.43 $* | 1.98 $* |
| Apr-16-2025 | 1.10 $* | 1.56 $* |
| Mar-16-2025 | 1.45 $* | 1.63 $* |
| Feb-16-2025 | 1.26 $* | 1.63 $* |
| Jan-16-2025 | 1.11 $* | 1.60 $* |
Характеристики
Product Introduction
| 1. Standard product size specifications are as follows, can be customized according to the size and width of the user's cable drum | ||||||||||
| (mm) | CSW-FHB-350 | CSW-FHB-900 | CSW-FHB-1200 | CSW-FHB-1400 | CSW-FHB-1600 | |||||
| Thickness(mm) | 1.5 | 1.7 | 1.7 | 1.9 | 1.9 | 2.5 | 2 | 2.5 | 2.2 | 3 |
| Kg/m² | 1.35 | 1.5 | 1.5 | 1.65 | 1.65 | 2.25 | 1.75 | 2.25 | 1.9 | 2.7 |
| Client LOGO and text sample with Hi-Fi color | ||||||||||
| Color | Customer specified(red,white,blue,black etc.) | |||||||||
| 2. Environmentally friendly and recyclable solution with 100% PE material | ||||||||||
| 3.Simple, low cost and labor saving compared with the traditional wood packaging. | ||||||||||
| 4.Double layer substrate design, smooth and soft inside, protect the cables rigorously, adhered to the circular surface perfectly. | ||||||||||
| 5.The external sheet is formed by high strength PE lamination technology, which is equipped with compression resistance. Moreover, fabulous printing logo could be customized to increases the corporate image! | ||||||||||
1. APPLICATION:
Soft protective UV resistant PE plastic composite sheet. Which is a new packaging material substituting for traditional wood and normal packaging. The design and development cater to the needs of major telecom cable, power cable, optical fiber cable, communication cable, special cable conductor and steel coil manufacturers around the world, which has been proved worldwide.
2. FEATURES:
| Ø 100% recyclable performance. | Ø 40s Fast Packaging. | Ø Low cost and labor saving compared with the traditional wood packaging |
 | ||
| Ø Smooth and Flexible, adhered to the cable surface perfectly. | Ø Logo customized with fabulous printing to promote the corporate image! | Ø Heat insulation, rain proof, sand dust proof, anti-UV, anticollision during transportation. |
 | ||
3. Structure:
Mechanical Properties | |
Impact Strength | Non-break |
Tear strength | ≥70kN/m |
Tensile Strength | ≥15Mpa |
Elongation at break | ≥1000% |
4. General Dimensions
We provide the following sizes, special requirements can be customized
Thickness mm | Weight Kg/M² | Bobbin mm | Width mm | Layer | Color | Logo |
1.9 | 1.6 | 400-800 | 250-500 | 1 | All color | Customized |
2.2 | 1.9 | 800-1600 | 500-1000 | 1 | ||
2.6 | 2.25 | 1400-2500 | 710-1220 | 1~2 | ||
3.0 | 2.6 | 1600-2800 | 900-1600 | 1~2 |
Ø Super high voltage and medium voltage shield is designed and customized according to requirements!
Ø Width tolerance ±2mm, thickness ± 0.2mm.
5. Packaging and delivery:
A:50 meters per package;
B:100 meters per package;
Related Products
Company Information
Customer Photos
Our Certificates
Packaging & Shipping
FAQ
Q1: Are you a trading company or manufacturer?
A1: We are manufacturer.
Q2: What about the MOQ?
A2: Generally, the MOQ is one ton.
Q3: How long is your delivery time?
A3: Generally, 3-7 days for goods in stock and 10-30 days for goods make-to-order. And we will make the delivery ASAP with guaranteed quality.
Q4: Do you provide samples? is it free or extra?
A4: Yes, we could offer the sample for free. Customer just need to bear the freight cost which will also be returned in formal order.
Q5: How can you guarantee the quality of mass production is same with the sample sent to me before?
A5: We will keep a sample the same as yours, which will be based on during mass production.
Q6: Can the price be negotiated?
A6: Yes, the price is negotiable. It can be adjusted according to your quantity or package.
Q7: Can you give me a discount price?
A7: It is depending on the volume. The larger the volume is, the more discount you can enjoy.
Q8: Where is your factory located? How can I visit there?
A8: Our headquarters is in Shanghai and factory in Changzhou where is one hour’s way east to Shanghai by high-speed railway.
