Дуплексная машина для производства бумаги 4 слоя серая ламинирования

1. Designed speed: 100 m/min

2. Available width: 1400 mm 1800 mm.

3. Flute type: A, C, B, E, for option

4. Suction blower type paper delivering with air speed adjusting device, to keep good flute shape under high speed running

5. Gluing section applies with automatic, self-circulating glue supply

6. Immersed / closed gear box lubricating to reduce noise, universal joint power transmission, to insulate vibration, frequency-changing main motor drive

7. Surface treatment of gluing rollerlxc280s: Engrave reticulate and chrome plated .

8. Adjustment of upper corrugating roller, pressure roller, and glue roller, is controlled by pneumatic system

9. Bearings of upper/lower corrugating roller, and pressure roller, use high-temperature-resist lubrication to keep running smoothly and durably

10. Upper and lower corrugating rollers are made of 48CrMo alloy steel, with heated-treatment for hardness HRC56-60, and the surface is well treated by grind , also be well treated with slitting machine, carton box making machine corrugated cardboard machine.

Technical Parameters
