Заводские пользовательские 8 1/2 рейтинг Trenchless одиночные конусные роликовые биты для
- Категория: Oil Field Equipment >>>
- Поставщик: Langfang,Uqier,Drill,Bit,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 0.84 $* | 0.10 $* |
| Aug-20-2025 | 0.56 $* | 0.6 $* |
| Jul-20-2025 | 0.44 $* | 0.77 $* |
| Jun-20-2025 | 0.46 $* | 0.43 $* |
| May-20-2025 | 0.43 $* | 0.66 $* |
| Apr-20-2025 | 0.88 $* | 0.20 $* |
| Mar-20-2025 | 0.69 $* | 0.51 $* |
| Feb-20-2025 | 0.80 $* | 0.61 $* |
| Jan-20-2025 | 0.65 $* | 0.71 $* |
Характеристики
Product Overview
Application
Facing the complicated and changeable market situation of rotary drilling bit, UQR has developed single cone and two cone series rotary drilling bit, which can be applied in various rock layers from strongly weathered rock to slightly weathered rock, and adapt to the formation compressive strength of 50MPa to 150MPa or above.
Our R&D personnel optimized the steel ball locking sliding bearing in the bearing structure, and adopted the high saturated NBR O-ring and flat composite seal ring in the high-performance sealing process, ensuring the working stability of the lubrication system. These measures effectively improve the life and reliability of the bit under the conditions of high WOB or high speed drilling technology. At the same time, the optimized cutting structure gives full play to the high wear resistance of the rotary drilling bit and shows excellent cutting ability in practical application.
1. Cutting Structure :
The durability of premium tungsten carbide insert is improved with new formulas and new techniques for insert bit;
2. Gauge Structure:
Multiple gauge protection with gauge trimmers on the heel of cone,tungsten carbide inserts and hardfacing on the shirttail increases gauge holding capability and bearing life.
3. Bearing Structure :
High precision bearing with two thrust faces. Ball lock the cone. Hardfaced head bearing surface. Cone bearing inlaid with friction-reducing alloy and then silver -plated. Abrasion resistance and seizure resistance
of the bearing are improved.
4. Seal and Lubrication :
Premium O-ring,Optimal seal compression and curved seal structure can enhance the seal performance.The
pressure compensator system and advanced grease can greatly increase the lubricating reliability.
5.Product Application:
It can receive high WOB in the conventional drilling. It is suitable for various formations by matching cutting
structure with different tooth shape,tooth density and tooth exposure height.
Our R&D personnel optimized the steel ball locking sliding bearing in the bearing structure, and adopted the high saturated NBR O-ring and flat composite seal ring in the high-performance sealing process, ensuring the working stability of the lubrication system. These measures effectively improve the life and reliability of the bit under the conditions of high WOB or high speed drilling technology. At the same time, the optimized cutting structure gives full play to the high wear resistance of the rotary drilling bit and shows excellent cutting ability in practical application.
1. Cutting Structure :
The durability of premium tungsten carbide insert is improved with new formulas and new techniques for insert bit;
2. Gauge Structure:
Multiple gauge protection with gauge trimmers on the heel of cone,tungsten carbide inserts and hardfacing on the shirttail increases gauge holding capability and bearing life.
3. Bearing Structure :
High precision bearing with two thrust faces. Ball lock the cone. Hardfaced head bearing surface. Cone bearing inlaid with friction-reducing alloy and then silver -plated. Abrasion resistance and seizure resistance
of the bearing are improved.
4. Seal and Lubrication :
Premium O-ring,Optimal seal compression and curved seal structure can enhance the seal performance.The
pressure compensator system and advanced grease can greatly increase the lubricating reliability.
5.Product Application:
It can receive high WOB in the conventional drilling. It is suitable for various formations by matching cutting
structure with different tooth shape,tooth density and tooth exposure height.
FEATURES AT A GLANCE
Front elevation
Side elevation
Teeth elevation
PRODUCT SPECIFICATIONS
No | Item | Data | ||
1 | Brand | KingDream | ||
2 | IADC | 537/637 | ||
3 | Inch | 8 1/2 | ||
4 | N.W | 13kg | ||
5 | WOB | 0.4-1.05 kN/mm | ||
6 | RPM | 40-110 | ||
7 | Sales scope | Global | ||
8 | Place of origin | China |
SIMILAR PRODUCTS
Successful Project
Project in USA
Project in India
Project in Russia
FAQ
1. How to get an accurate quote?
Answer: A simple way is sending us photos .
Besides above, if possible please provide more information as below:
Drilling depth in vertical well drilling, Drilling length in HDD, hardness of rocks, Capacity of drill rigs, application(oil/gas well drilling, or water well drilling, or HDD, or foundation).
The more information provided, the more exact quotation will be offered.
2. What is the quality control for your products?
Answer: All of our production are in lines of API rules and ISO9001:2015 strictly, from signing contract , to raw materials, to each production processes, to product finish, to after-sale service, each processes and sections are in accordant with standard.
3. About lead time?
Answer: We always have regular models available in stock, prompt delivery is one of our advantages. Mass production depends on quantity of order.
4. About payment terms?
Answer:We accept all regular payment terms including L/C, T/T, etc.
5. About delivery?
We are near from Tianjin(Xingang) seaport, transportation from our factory to Tianjin only takes one day, fast and very economical inland charges.
6. What is the history of UQR?
Answer: The drilling bits business was started at year 2007 only for China domestic requirement, now UQR has exported to more than 30 countries and areas.
7. How do you guarantee your quality?
Answer:We select the advanced production technology and equipment, strictly control the whole production process,and we inspected the finished drill bits,we can also make several design changes according to the customer's feedback, and finally ensure the customer's excellent drilling effect. Each of the drill bits sold will be quality-tracked, detailing the usage feedback to improve our deficiencies.
Answer: A simple way is sending us photos .
Besides above, if possible please provide more information as below:
Drilling depth in vertical well drilling, Drilling length in HDD, hardness of rocks, Capacity of drill rigs, application(oil/gas well drilling, or water well drilling, or HDD, or foundation).
The more information provided, the more exact quotation will be offered.
2. What is the quality control for your products?
Answer: All of our production are in lines of API rules and ISO9001:2015 strictly, from signing contract , to raw materials, to each production processes, to product finish, to after-sale service, each processes and sections are in accordant with standard.
3. About lead time?
Answer: We always have regular models available in stock, prompt delivery is one of our advantages. Mass production depends on quantity of order.
4. About payment terms?
Answer:We accept all regular payment terms including L/C, T/T, etc.
5. About delivery?
We are near from Tianjin(Xingang) seaport, transportation from our factory to Tianjin only takes one day, fast and very economical inland charges.
6. What is the history of UQR?
Answer: The drilling bits business was started at year 2007 only for China domestic requirement, now UQR has exported to more than 30 countries and areas.
7. How do you guarantee your quality?
Answer:We select the advanced production technology and equipment, strictly control the whole production process,and we inspected the finished drill bits,we can also make several design changes according to the customer's feedback, and finally ensure the customer's excellent drilling effect. Each of the drill bits sold will be quality-tracked, detailing the usage feedback to improve our deficiencies.
LANGFANG UQIER DRLL BIT CO.,LTD.as a leading manufacturer of tricone bit s and PDC bits, our products are made strictly complying
with API specifications and ISO9001 LANGFANG UQIER DRLL BIT CO.,LTD.was established in 1990. We have kept our clients ahead of schedule and under budget by providing the highest quality tools at the best possible prices. Our products are sold in more than 30 countries and serve the oil and gas, well and other industries.Construction, Mining, Horizontal Directional Drilling (HDD) Geothermal and Environmental. Our experienced staff is here to asslst you with everything from choosing the right bit to
shipping around the global. Our goal is to provide our customers with the best quality tools, accessories and service in the
industry. We are supported by many years of experience, trained professionals and a full machine shop. Reduce the cost .Speed the
drilling ,Guarantee the safety is always our aim.
with API specifications and ISO9001 LANGFANG UQIER DRLL BIT CO.,LTD.was established in 1990. We have kept our clients ahead of schedule and under budget by providing the highest quality tools at the best possible prices. Our products are sold in more than 30 countries and serve the oil and gas, well and other industries.Construction, Mining, Horizontal Directional Drilling (HDD) Geothermal and Environmental. Our experienced staff is here to asslst you with everything from choosing the right bit to
shipping around the global. Our goal is to provide our customers with the best quality tools, accessories and service in the
industry. We are supported by many years of experience, trained professionals and a full machine shop. Reduce the cost .Speed the
drilling ,Guarantee the safety is always our aim.
