Формовочная машина для выдувания пластиковых бутылок
US $20000-$50000
300 мл 700 900 до 3л пол-автоматическая бутылка выдувная формовочная машина на 2 полости 5л 7л для выдувания бутылок
- Категория: Stretch Blow Moulding Machines >>>
- Поставщик: Luohe,Juyou,Commercial,&,Trading,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.7 $* | 0.49 $* |
| Aug-19-2025 | 0.15 $* | 0.24 $* |
| Jul-19-2025 | 0.75 $* | 0.58 $* |
| Jun-19-2025 | 0.94 $* | 0.10 $* |
| May-19-2025 | 0.32 $* | 0.5 $* |
| Apr-19-2025 | 0.48 $* | 0.54 $* |
| Mar-19-2025 | 0.95 $* | 0.40 $* |
| Feb-19-2025 | 0.26 $* | 0.78 $* |
| Jan-19-2025 | 0.42 $* | 0.25 $* |
Характеристики
Product Description
1. Using the new clamping system with double crank four tie-bars,the cross balanced fixed glide.
2. The seal,the stretch use the parallel bars union and combined design,which is advantageous to the product formation.
3. The advanced air course design,the single-channel or single-channel air admission;low pressure for clamping,sealing and
stretching;the high pressre for blowing the bottle.
4. PLC control system,the operaton is easy.
5. With infrared heating,controllable constant pressure control,frequency conversion,thus achieves blows the perfect bottle.
2. The seal,the stretch use the parallel bars union and combined design,which is advantageous to the product formation.
3. The advanced air course design,the single-channel or single-channel air admission;low pressure for clamping,sealing and
stretching;the high pressre for blowing the bottle.
4. PLC control system,the operaton is easy.
5. With infrared heating,controllable constant pressure control,frequency conversion,thus achieves blows the perfect bottle.
Exhibition
Specification
output | According to bottle type | 80-100PCS/H |
Product species | Bottle diameter | 150mm-300mm |
bottle height | 250mm-550mm | |
Bottle mouth diameter | 15mm-100mm | |
mould | cavity | 2 cavities |
mould thickness | 200~450mm | |
Effective area of mold | 600*600mm | |
main power | Power | 380v 4Phase /220v 2Phase 50/60HZ |
install power/actual power | 26kw/11kw | |
High pressure air compressor | 1.2m3/min 3.0MPa | |
Cold dry machine | 2.0m3/min 3.0MPa 1set | |
cooling water | Cooling water quantity | 15L/min |
Main machine size | Length width height/weight | 2150*730*1700mm/950kg |
Oven size | Length width height /weight | 2450*680*1580mm/650kg |
Packing & Delivery
wooden case
Company Profile
LUOHE JUYOU COMMERCIAL & TRADING CO., LTD
is specialized in the production and selling of nuts machine,corn machine,vegetables machine,fruits machine and all kinds of pet toys,pets cages so on.
Our factories have more than ten years experience in the industry.So we are be sure of the good quality and competitive price.And our products sell all of the world every month. We have won a high reputation among clients.
Our company regards "reasonable prices, efficient production time and good after-sales service" as our tenet. We hope to cooperate with more customers for mutual development and benefits. We welcome potential buyers to contact us.
is specialized in the production and selling of nuts machine,corn machine,vegetables machine,fruits machine and all kinds of pet toys,pets cages so on.
Our factories have more than ten years experience in the industry.So we are be sure of the good quality and competitive price.And our products sell all of the world every month. We have won a high reputation among clients.
Our company regards "reasonable prices, efficient production time and good after-sales service" as our tenet. We hope to cooperate with more customers for mutual development and benefits. We welcome potential buyers to contact us.
FAQ
