Наружный Wi-Fi ретранслятор с разъемом для скрытой камеры продажи Lte длинная Беспроводная цепь Ac Km оптовая продажа 4g 5g 10 км

Band&Frequency

FDD LTE:

B1/B3/B4/B5/B7/B8/B28

TDD LTE:

B40

WCDMA:

B1/B2/B5/B8

GSM:

B2/B3/B5/B8

Hardware

Main Chipset

MT7620A

RAM

DDR2 128MB (MAX DDR2 256MB)

 SPI FLASH

16MB (MAX 32MB)

Protocol

IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE802.11ac, IEEE802.11a,
IEEE 802.3, IEEE 802.3u

RT Power

802.11b   18dBm±2dBm;

802.11g   15dBm±2dBm;

802.11n   15dBm±2dBm;

Reception Sensitivity

802.11b: -83dBm@10% PER

802.11g: -74dBm@10% PER

802.11n: -68dBm@10% PER

Work Channel

2.4GHz choose: 1-13

Wireless Rate

Max. 300Mbps

Work Frequency

2.4GHz

Antenna

2* 5dBi antenna or 4*5dbi external antenna (With 3G/4G)

Interface

1*PCI-E slot

1*SIM card slot

1*USB 2.0 port

1*Micro SD card slot

1*10/100/100M WAN port (Auto MDI/MDIX)
4*10/100/100M LAN port (Auto MDI/MDIX)

LED

Power, USB, 2.4G, WAN, LAN1, LAN2, LAN3, LAN4

Button

Reset

Max Power consumption

< 12W

Others

Work Environments

Operating Temperature:0℃ ~ 40℃;
Storage Temperature:-40℃~ 70℃;

Operating Humidity:10%~90% non-condensing
Storage Humidity:10%~90% non-condensing

Adapter

12V 1A

Authentication

CE, FCC, RoHs

Other accessories

Power adapter, Ethernet cable
