Характеристики
500w 700va 700w 1kva 1000w 1.5kva Split Phase Off Grid Solar System 6kw 30A PWM Hybrid Solar Inverter
Product Description
Product Paramenters
Modle | HB-L-PWM-700VA | HB-L-PWM-1KVA | HB-L-PWM-1.5KVA | HB-L-PWM-2KVA | ||||
Rated power | 500W | 700W | 1000W | 1500W | ||||
Battery voltage | 12/24V | |||||||
N.W./G.W | 6KG | 8KG | 10KG | 13KG | ||||
Package size L×W×H（mm） | 570X340X240(mm) | |||||||
Package size L×W×H（mm） | 290X300X122(mm) | |||||||
Inverter | ||||||||
AC Input voltage range(VAC) | 170-275VAC（220V) 85-138VAC(110V) | |||||||
Input frequency(Hz) | 45-65HZ | |||||||
Battery voltage range | 10.5-15VDC (Single battery voltage) | |||||||
Output voltage range(VAC) | Inverter mode 110V/220V/230V/240V±2% | |||||||
Utility output voltage range | constant voltage output 220VAC±10% 110VAC±10% | |||||||
Output frequency(Hz) | 50/60±1%. | |||||||
Utility output frequency range | 50Hz 60Hz automatic tracking | |||||||
Output waveform | Pure sine wave | |||||||
Efficiency | 90% | |||||||
THD | ≤3% | |||||||
Transfer time(ms) | ≤4ms | |||||||
Charging type | U0-U7 | |||||||
charging current | C0=0A,C1=5A,C2=10A,C3=15,C4=20A,C5=25A,C6=30A | |||||||
Overload protection | rated power≥110％，60S power off；≥130％，10S power off； | |||||||
Temperature protection | ≥85℃ alarm，≥90℃ shutdown the machine | |||||||
Protection type | Solar cells, anti-anti-charge protection, battery open-circuit protection, battery reversal protection | |||||||
Send your inquiry to us!
------More than 10 Years Industry Experience, OEM/ODM available, for more any information, please feel free to contact us by click here.
Client feedback
Company Introduction
Certifications
Packaging & Delivery
FAQ
1. How does a power inverter work?
A power inverter converts DC power into conventional AC power, when an AC outlet is not available. Simply connect an inverter to a battery source, plug your appliance into the inverter.
2. What is the difference between a modified sine inverter and pure sine wave inverter?
Modified sine wave power inverter is more portable than pure sine wave power inverter, lighter, and lower in cost. If the device handles voltage fluctuations, a modified sine wave inverter should be considered.Most devices that people typically wish to power will work fine with a modified sine wave inverter.
Pure sine wave power inverter allows motors to run cooler, last longer and provide very clean power that is same quality with State Grid . Devices such as air conditioner, Freezer and most medical equipment require a pure sine wave inverter to run.
3. What type of batteries do you recommend?
Most of people choose to use deep cycle marine batteries with their inverters. Also can use Acid battery, Lithium battery.
4. Do you accept OEM and ODM service?
Yes, we accept OEM and ODM service.
5. How long of the delivery time, sample order and wholesale order?
For Sample order, within 3 days; For 1000pcs wholesale order, 7-15 working days.
6. How do I know which inverter to buy?
Different devices require specific wattages to run. Please check the following formula to determine the correct watt model:
AMPS x 120 = Watts
For Example: 20 Amp Freezer Unit * 120 = 2400 Watts
A power inverter converts DC power into conventional AC power, when an AC outlet is not available. Simply connect an inverter to a battery source, plug your appliance into the inverter.
2. What is the difference between a modified sine inverter and pure sine wave inverter?
Modified sine wave power inverter is more portable than pure sine wave power inverter, lighter, and lower in cost. If the device handles voltage fluctuations, a modified sine wave inverter should be considered.Most devices that people typically wish to power will work fine with a modified sine wave inverter.
Pure sine wave power inverter allows motors to run cooler, last longer and provide very clean power that is same quality with State Grid . Devices such as air conditioner, Freezer and most medical equipment require a pure sine wave inverter to run.
3. What type of batteries do you recommend?
Most of people choose to use deep cycle marine batteries with their inverters. Also can use Acid battery, Lithium battery.
4. Do you accept OEM and ODM service?
Yes, we accept OEM and ODM service.
5. How long of the delivery time, sample order and wholesale order?
For Sample order, within 3 days; For 1000pcs wholesale order, 7-15 working days.
6. How do I know which inverter to buy?
Different devices require specific wattages to run. Please check the following formula to determine the correct watt model:
AMPS x 120 = Watts
For Example: 20 Amp Freezer Unit * 120 = 2400 Watts
