Формовочная машина для выдувания пластиковых бутылок
US $20000-$50000
Automatic PET plastic bottle injection stretch blow blowing molding moulding
- Категория: Stretch Blow Moulding Machines >>>
- Поставщик: Liuzhou,Jingye,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 104125.13 $* | 109331.29 $* |
| Aug-17-2025 | 103250.33 $* | 108413.11 $* |
| Jul-17-2025 | 86625.34 $* | 90956.81 $* |
| Jun-17-2025 | 101500.35 $* | 106575.73 $* |
| May-17-2025 | 88375.57 $* | 92794.13 $* |
| Apr-17-2025 | 99750.44 $* | 104738.63 $* |
| Mar-17-2025 | 98875.97 $* | 103819.7 $* |
| Feb-17-2025 | 98000.24 $* | 102900.64 $* |
| Jan-17-2025 | 97125.26 $* | 101981.81 $* |
Характеристики
Product Description
Injection Stretch Blow Molding Machine
This is a single stage injection stretch blow molding (ISBM) machine with three station.
Injection station - for injection preform from raw material.
Stretch & blow station - for stretching & blowing preform to finished bottle.
Ejection station - for releasing finished bottle from molds.
We provide turn-key solution for you, ISBM machine, molds and auxiliary machines. Get more details, contact us now!
Technical Data Sheet
| Item | Data |
| Machine Model | WISBIII-88AS |
| Screw Diameter | 50 mm |
| Theoretical Injection Capacity | 390 cm3 |
| Injection Clamping Force | 406.9 kN |
| Blow Clamping Force | 203.4 kN |
| Motor Power | 26 + 26 kW |
| Heater Capacity | 11 kW |
| Blow Air Pressure | 2.5 - 3.0 MPa |
| Cooling Water Pressure | 0.2 - 0.3 MPa |
| Machine Size | 4850 * 1850 * 3380 mm |
| Machine Weight | 10000 kg |
High Standard Configuration
All key parts, we use high standard configuration on this machine to keep machine running stable, saving power & human resources and long service life.
Sample
Packaging & Shipping
To get a turn-key solution for your project, contact us now!
Customer Factory Display
Company Information
Liuzhou Jingye Machinery Co.,Ltd is the manufacturer of single stage injection stretch blow molding (ISBM) and injection blow molding (IBM) machine in China since 1997.
We provide turn-key solution, ISBM machine, molds and auxiliary machines.
Online installion & technical services is available now. Contact us now, please!
